merge with master

.gitignore

@@ -104,4 +104,6 @@ tools/unity-avatar-exporter/Logs
 tools/unity-avatar-exporter/Packages
 tools/unity-avatar-exporter/ProjectSettings
 tools/unity-avatar-exporter/Temp
-
+server-console/package-lock.json
+vcpkg/
+/tools/nitpick/compiledResources

CMakeLists.txt

@@ -108,8 +108,10 @@ set(PLATFORM_QT_GL OpenGL)

 if (USE_GLES)
   add_definitions(-DUSE_GLES)
+  add_definitions(-DGPU_POINTER_STORAGE_SHARED)
   set(PLATFORM_GL_BACKEND gpu-gl-common gpu-gles)
 else()
+  add_definitions(-DGPU_POINTER_STORAGE_RAW)
   set(PLATFORM_GL_BACKEND gpu-gl-common gpu-gl)
 endif()


INSTALL.md

@@ -4,7 +4,8 @@ During generation, CMake should produce an `install` target and a `package` targ

 ### Install

-The `install` target will copy the High Fidelity targets and their dependencies to your `CMAKE_INSTALL_PREFIX`.
+The `install` target will copy the High Fidelity targets and their dependencies to your `CMAKE_INSTALL_PREFIX`.
+This variable is set by the `project(hifi)` command in `CMakeLists.txt` to `C:/Program Files/hifi` and stored in `build/CMakeCache.txt`

 ### Packaging

@@ -14,17 +15,67 @@ To produce an installer, run the `package` target.

 To produce an executable installer on Windows, the following are required:

-- [Nullsoft Scriptable Install System](http://nsis.sourceforge.net/Download) - 3.0b3
-- [UAC Plug-in for Nullsoft](http://nsis.sourceforge.net/UAC_plug-in) - 0.2.4c
-- [nsProcess Plug-in for Nullsoft](http://nsis.sourceforge.net/NsProcess_plugin) - 1.6
-- [Inetc Plug-in for Nullsoft](http://nsis.sourceforge.net/Inetc_plug-in) - 1.0
-- [NSISpcre Plug-in for Nullsoft](http://nsis.sourceforge.net/NSISpcre_plug-in) - 1.0
-- [nsisSlideshow Plug-in for Nullsoft](http://nsis.sourceforge.net/NsisSlideshow_plug-in) - 1.7
-- [Nsisunz plug-in for Nullsoft](http://nsis.sourceforge.net/Nsisunz_plug-in)
-- [ApplicationID plug-in for Nullsoft](http://nsis.sourceforge.net/ApplicationID_plug-in) - 1.0
+1.  [7-zip](<https://www.7-zip.org/download.html>)

-Run the `package` target to create an executable installer using the Nullsoft Scriptable Install System.
+1. [Nullsoft Scriptable Install System](http://nsis.sourceforge.net/Download) - 3.04
+  Install using defaults (will install to `C:\Program Files (x86)\NSIS`)
+1. [UAC Plug-in for Nullsoft](http://nsis.sourceforge.net/UAC_plug-in) - 0.2.4c
+    1. Extract Zip
+    1. Copy `UAC.nsh` to `C:\Program Files (x86)\NSIS\Include\`
+    1. Copy `Plugins\x86-ansi\UAC.dll` to `C:\Program Files (x86)\NSIS\Plugins\x86-ansi\`
+    1. Copy `Plugins\x86-unicode\UAC.dll` to `C:\Program Files (x86)\NSIS\Plugins\x86-unicode\`
+1. [nsProcess Plug-in for Nullsoft](http://nsis.sourceforge.net/NsProcess_plugin) - 1.6 (use the link marked **nsProcess_1_6.7z**)
+    1. Extract Zip
+    1. Copy `Include\nsProcess.nsh` to `C:\Program Files (x86)\NSIS\Include\`
+    1. Copy `Plugins\nsProcess.dll` to `C:\Program Files (x86)\NSIS\Plugins\x86-ansi\`
+    1. Copy `Plugins\nsProcessW.dll` to `C:\Program Files (x86)\NSIS\Plugins\x86-unicode\`
+
+1. [InetC Plug-in for Nullsoft](http://nsis.sourceforge.net/Inetc_plug-in) - 1.0
+    1. Extract Zip
+    1. Copy `Plugin\x86-ansi\InetC.dll` to `C:\Program Files (x86)\NSIS\Plugins\x86-ansi\`
+    1. Copy `Plugin\x86-unicode\InetC.dll` to `C:\Program Files (x86)\NSIS\Plugins\x86-unicode\`
+
+1. [NSISpcre Plug-in for Nullsoft](http://nsis.sourceforge.net/NSISpcre_plug-in) - 1.0
+    1. Extract Zip
+    1. Copy `NSISpre.nsh` to `C:\Program Files (x86)\NSIS\Include\`
+    1. Copy `NSISpre.dll` to `C:\Program Files (x86)\NSIS\Plugins\x86-ansi\`
+
+1. [nsisSlideshow Plug-in for Nullsoft](<http://wiz0u.free.fr/prog/nsisSlideshow/>) - 1.7
+   1.  Extract Zip
+   1.  Copy `bin\nsisSlideshow.dll` to `C:\Program Files (x86)\NSIS\Plugins\x86-ansi\`
+   1.  Copy `bin\nsisSlideshowW.dll` to `C:\Program Files (x86)\NSIS\Plugins\x86-unicode\`
+
+1. [Nsisunz plug-in for Nullsoft](http://nsis.sourceforge.net/Nsisunz_plug-in)
+   1.  Download both Zips and unzip
+   1.  Copy `nsisunz\Release\nsisunz.dll` to `C:\Program Files (x86)\NSIS\Plugins\x86-ansi\`
+   1.  Copy `NSISunzU\Plugin unicode\nsisunz.dll` to `C:\Program Files (x86)\NSIS\Plugins\x86-unicode\`
+
+1. [ApplicationID plug-in for Nullsoft]() - 1.0
+   1.  Download [`Pre-built DLLs`](<https://github.com/connectiblutz/NSIS-ApplicationID/releases/download/1.1/NSIS-ApplicationID.zip>)
+   1.  Extract Zip
+   1.  Copy `Release\ApplicationID.dll` to `C:\Program Files (x86)\NSIS\Plugins\x86-ansi\`
+   1.  Copy `ReleaseUnicode\ApplicationID.dll` to `C:\Program Files (x86)\NSIS\Plugins\x86-unicode\`
+
+1. [npm](<https://www.npmjs.com/get-npm>)
+    1.  Install version 10.15.0 LTS
+
+1.  Perform a clean cmake from a new terminal.
+1.  Open the `hifi.sln` Solution and select the Release configuration.
+1.  Build the Solution.
+1.  Build `packaged-server-console` (found under **Server Console**)
+    This will add 2 folders to `build\server-console\` -
+    `server-console-win32-x64` and `x64`
+1.  Build CMakeTargets->PACKAGE
+    Installer is now available in `build\_CPack_Packages\win64\NSIS`

 #### OS X
-
-Run the `package` target to create an Apple Disk Image (.dmg).
+1.   [npm](<https://www.npmjs.com/get-npm>)
+      Install version 10.15.0 LTS
+
+1.  Perform a clean cmake.
+1.  Perform a Release build of ALL_BUILD
+1.  Perform a Release build of `packaged-server-console`
+     This will add a folder to `build\server-console\` -
+     Sandbox-darwin-x64
+1.  Perform a Release build of `package`
+      Installer is now available in `build/_CPack_Packages/Darwin/DragNDrop

android/apps/framePlayer/CMakeLists.txt

@@ -0,0 +1,5 @@
+set(TARGET_NAME framePlayer)
+setup_hifi_library(AndroidExtras)
+link_hifi_libraries(shared ktx shaders qml gpu gl ${PLATFORM_GL_BACKEND})
+target_link_libraries(${TARGET_NAME} android log m)
+target_opengl()

android/apps/framePlayer/build.gradle

@@ -0,0 +1,50 @@
+apply plugin: 'com.android.application'
+
+android {
+    signingConfigs {
+        release {
+            keyAlias 'key0'
+            keyPassword 'password'
+            storeFile file('C:/android/keystore.jks')
+            storePassword 'password'
+        }
+    }
+
+    compileSdkVersion 28
+    defaultConfig {
+        applicationId "io.highfidelity.frameplayer"
+        minSdkVersion 25
+        targetSdkVersion 28
+        ndk { abiFilters 'arm64-v8a' }
+        externalNativeBuild {
+            cmake {
+                arguments '-DHIFI_ANDROID=1',
+                    '-DHIFI_ANDROID_APP=framePlayer',
+                    '-DANDROID_TOOLCHAIN=clang',
+                    '-DANDROID_STL=c++_shared',
+                    '-DCMAKE_VERBOSE_MAKEFILE=ON'
+                targets = ['framePlayer']
+            }
+        }
+    }
+    compileOptions {
+        sourceCompatibility JavaVersion.VERSION_1_8
+        targetCompatibility JavaVersion.VERSION_1_8
+    }
+
+    buildTypes {
+        release {
+            minifyEnabled false
+            proguardFiles getDefaultProguardFile('proguard-android.txt'), 'proguard-rules.pro'
+            signingConfig signingConfigs.release
+        }
+    }
+
+    externalNativeBuild.cmake.path '../../../CMakeLists.txt'
+}
+
+dependencies {
+    implementation fileTree(include: ['*.jar'], dir: '../../libraries/qt/libs')
+    //implementation project(':oculus')
+    implementation project(':qt')
+}

android/apps/framePlayer/proguard-rules.pro

@@ -0,0 +1,25 @@
+# Add project specific ProGuard rules here.
+# By default, the flags in this file are appended to flags specified
+# in C:\Android\SDK/tools/proguard/proguard-android.txt
+# You can edit the include path and order by changing the proguardFiles
+# directive in build.gradle.
+#
+# For more details, see
+#   http://developer.android.com/guide/developing/tools/proguard.html
+
+# Add any project specific keep options here:
+
+# If your project uses WebView with JS, uncomment the following
+# and specify the fully qualified class name to the JavaScript interface
+# class:
+#-keepclassmembers class fqcn.of.javascript.interface.for.webview {
+#   public *;
+#}
+
+# Uncomment this to preserve the line number information for
+# debugging stack traces.
+#-keepattributes SourceFile,LineNumberTable
+
+# If you keep the line number information, uncomment this to
+# hide the original source file name.
+#-renamesourcefileattribute SourceFile

android/apps/framePlayer/src/main/AndroidManifest.xml

@@ -0,0 +1,38 @@
+<?xml version="1.0" encoding="utf-8"?>
+<manifest xmlns:android="http://schemas.android.com/apk/res/android"
+    xmlns:tools="http://schemas.android.com/tools"
+    package="io.highfidelity.frameplayer"
+    android:versionCode="1"
+    android:versionName="1.0"
+    android:installLocation="auto">
+    <uses-feature android:glEsVersion="0x00030002" android:required="true" />
+    <uses-permission android:name="android.permission.INTERNET" />
+    <uses-permission android:name="android.permission.READ_EXTERNAL_STORAGE"/>
+    <uses-permission android:name="android.permission.WRITE_EXTERNAL_STORAGE" />
+    <uses-permission android:name="android.permission.ACCESS_NETWORK_STATE" />
+    <application android:label="Frame Viewer"
+        android:allowBackup="false"
+        android:name="org.qtproject.qt5.android.bindings.QtApplication"
+        tools:ignore="GoogleAppIndexingWarning,MissingApplicationIcon">
+        <meta-data android:name="com.samsung.android.vr.application.mode" android:value="vr_only"/>
+        <activity
+            android:name="org.qtproject.qt5.android.bindings.QtActivity"
+            android:theme="@android:style/Theme.Black.NoTitleBar.Fullscreen"
+            android:launchMode="singleTask"
+            android:screenOrientation="landscape"
+            android:excludeFromRecents="false"
+            android:configChanges="screenSize|screenLayout|orientation|keyboardHidden|keyboard|navigation|uiMode">
+            <!-- JNI nonsense -->
+            <meta-data android:name="android.app.lib_name" android:value="framePlayer"/>
+            <!-- Qt nonsense -->
+            <meta-data android:name="android.app.qt_libs_resource_id" android:resource="@array/qt_libs"/>
+            <meta-data android:name="android.app.bundled_in_lib_resource_id" android:resource="@array/bundled_in_lib"/>
+            <meta-data android:name="android.app.bundled_in_assets_resource_id" android:resource="@array/bundled_in_assets"/>
+            <meta-data android:name="android.app.load_local_libs" android:value="plugins/platforms/android/libqtforandroid.so:plugins/bearer/libqandroidbearer.so"/>
+            <intent-filter>
+                <action android:name="android.intent.action.MAIN" />
+                <category android:name="android.intent.category.LAUNCHER" />
+            </intent-filter>
+        </activity>
+    </application>
+</manifest>

android/apps/framePlayer/src/main/cpp/FramePlayer.qrc

@@ -0,0 +1,6 @@
+<!DOCTYPE RCC>
+<RCC version="1.0">
+  <qresource prefix="/">
+    <file>qml/main.qml</file>
+  </qresource>
+</RCC>

android/apps/framePlayer/src/main/cpp/PlayerWindow.cpp

@@ -0,0 +1,91 @@
+//
+//  Created by Bradley Austin Davis on 2018/10/21
+//  Copyright 2014 High Fidelity, Inc.
+//
+//  Distributed under the Apache License, Version 2.0.
+//  See the accompanying file LICENSE or http://www.apache.org/licenses/LICENSE-2.0.html
+//
+
+#include "PlayerWindow.h"
+
+#include <QtCore/QFileInfo>
+#include <QtGui/QImageReader>
+#include <QtQml/QQmlContext>
+#include <QtQuick/QQuickItem>
+
+#include <gpu/Frame.h>
+#include <gpu/FrameIO.h>
+
+PlayerWindow::PlayerWindow() {
+    setFlags(Qt::MSWindowsOwnDC | Qt::Window | Qt::Dialog | Qt::WindowMinMaxButtonsHint | Qt::WindowTitleHint);
+    setSurfaceType(QSurface::OpenGLSurface);
+    create();
+    showFullScreen();
+
+    // Make sure the window has been created by processing events
+    QCoreApplication::processEvents();
+
+    // Start the rendering thread
+    _renderThread.initialize(this, &_surface);
+
+    // Start the UI
+    _surface.resize(size());
+    connect(&_surface, &hifi::qml::OffscreenSurface::rootContextCreated, this, [](QQmlContext* context){
+        context->setContextProperty("FRAMES_FOLDER", "file:assets:/frames");
+    });
+    _surface.load("qrc:///qml/main.qml");
+
+    // Connect the UI handler
+    QObject::connect(_surface.getRootItem(), SIGNAL(loadFile(QString)),
+        this, SLOT(loadFile(QString))
+    );
+
+    // Turn on UI input events
+    installEventFilter(&_surface);
+}
+
+PlayerWindow::~PlayerWindow() {
+}
+
+// static const char* FRAME_FILE = "assets:/frames/20190110_1635.json";
+
+static void textureLoader(const std::string& filename, const gpu::TexturePointer& texture, uint16_t layer) {
+    QImage image;
+    QImageReader(filename.c_str()).read(&image);
+    if (layer > 0) {
+        return;
+    }
+    texture->assignStoredMip(0, image.byteCount(), image.constBits());
+}
+
+void PlayerWindow::loadFile(QString filename) {
+    QString realFilename = QUrl(filename).toLocalFile();
+    if (QFileInfo(realFilename).exists()) {
+        auto frame = gpu::readFrame(realFilename.toStdString(), _renderThread._externalTexture, &textureLoader);
+        _surface.pause();
+        _renderThread.submitFrame(frame);
+    }
+}
+
+void PlayerWindow::touchEvent(QTouchEvent* event) {
+    // Super basic input handling when the 3D scene is active.... tap with two finders to return to the
+    // QML UI
+    static size_t touches = 0;
+    switch (event->type()) {
+        case QEvent::TouchBegin:
+        case QEvent::TouchUpdate:
+            touches = std::max<size_t>(touches, event->touchPoints().size());
+            break;
+
+        case QEvent::TouchEnd:
+            if (touches >= 2) {
+                _renderThread.submitFrame(nullptr);
+                _surface.resume();
+            }
+            touches = 0;
+            break;
+
+        default:
+            break;
+    }
+}

android/apps/framePlayer/src/main/cpp/PlayerWindow.h

@@ -0,0 +1,35 @@
+//
+//  Created by Bradley Austin Davis on 2018/10/21
+//  Copyright 2014 High Fidelity, Inc.
+//
+//  Distributed under the Apache License, Version 2.0.
+//  See the accompanying file LICENSE or http://www.apache.org/licenses/LICENSE-2.0.html
+//
+
+#pragma once
+#include <QtGui/QWindow>
+#include <QtCore/QSettings>
+
+#include <qml/OffscreenSurface.h>
+#include <gpu/Forward.h>
+#include "RenderThread.h"
+
+// Create a simple OpenGL window that renders text in various ways
+class PlayerWindow : public QWindow {
+    Q_OBJECT
+
+public:
+    PlayerWindow();
+    virtual ~PlayerWindow();
+
+protected:
+    void touchEvent(QTouchEvent *ev) override;
+
+public slots:
+    void loadFile(QString filename);
+
+private:
+    hifi::qml::OffscreenSurface _surface;
+    QSettings _settings;
+    RenderThread _renderThread;
+};

android/apps/framePlayer/src/main/cpp/RenderThread.cpp

@@ -0,0 +1,162 @@
+//
+//  Created by Bradley Austin Davis on 2018/10/21
+//  Copyright 2014 High Fidelity, Inc.
+//
+//  Distributed under the Apache License, Version 2.0.
+//  See the accompanying file LICENSE or http://www.apache.org/licenses/LICENSE-2.0.html
+//
+
+#include "RenderThread.h"
+
+#include <QtGui/QWindow>
+
+void RenderThread::submitFrame(const gpu::FramePointer& frame) {
+    std::unique_lock<std::mutex> lock(_frameLock);
+    _pendingFrames.push(frame);
+}
+
+void RenderThread::move(const glm::vec3& v) {
+    std::unique_lock<std::mutex> lock(_frameLock);
+    _correction = glm::inverse(glm::translate(mat4(), v)) * _correction;
+}
+
+void RenderThread::setup() {
+    // Wait until the context has been moved to this thread
+    { std::unique_lock<std::mutex> lock(_frameLock); }
+
+    makeCurrent();
+    // Disable vsync for profiling
+    ::gl::setSwapInterval(0);
+
+    glClearColor(1, 1, 0, 1);
+    glClear(GL_COLOR_BUFFER_BIT);
+    _glContext.swapBuffers();
+
+    // GPU library init
+    gpu::Context::init<gpu::gl::GLBackend>();
+    _gpuContext = std::make_shared<gpu::Context>();
+    _backend = _gpuContext->getBackend();
+    _gpuContext->beginFrame();
+    _gpuContext->endFrame();
+    makeCurrent();
+
+
+    glGenFramebuffers(1, &_uiFbo);
+    glGenTextures(1, &_externalTexture);
+    glBindTexture(GL_TEXTURE_2D, _externalTexture);
+    static const glm::u8vec4 color{ 0 };
+    glTexImage2D(GL_TEXTURE_2D, 0, GL_RGBA8, 1, 1, 0, GL_RGBA, GL_UNSIGNED_BYTE, &color);
+
+    glClearColor(0, 1, 1, 1);
+    glClear(GL_COLOR_BUFFER_BIT);
+    _glContext.swapBuffers();
+}
+
+void RenderThread::initialize(QWindow* window, hifi::qml::OffscreenSurface* offscreen) {
+    std::unique_lock<std::mutex> lock(_frameLock);
+    setObjectName("RenderThread");
+    Parent::initialize();
+
+    _offscreen = offscreen;
+    _window = window;
+    _glContext.setWindow(_window);
+    _glContext.create();
+    _glContext.makeCurrent();
+
+    hifi::qml::OffscreenSurface::setSharedContext(_glContext.qglContext());
+    glClearColor(1, 0, 0, 1);
+    glClear(GL_COLOR_BUFFER_BIT);
+    _glContext.swapBuffers();
+    _glContext.doneCurrent();
+    _glContext.moveToThread(_thread);
+    _thread->setObjectName("RenderThread");
+}
+
+void RenderThread::shutdown() {
+    _activeFrame.reset();
+    while (!_pendingFrames.empty()) {
+        _gpuContext->consumeFrameUpdates(_pendingFrames.front());
+        _pendingFrames.pop();
+    }
+    _gpuContext->shutdown();
+    _gpuContext.reset();
+}
+
+void RenderThread::renderFrame() {
+    auto windowSize = _window->geometry().size();
+    uvec2 readFboSize;
+    uint32_t readFbo{ 0 };
+
+    if (_activeFrame) {
+        const auto &frame = _activeFrame;
+        _backend->recycle();
+        _backend->syncCache();
+        _gpuContext->enableStereo(frame->stereoState._enable);
+        if (frame && !frame->batches.empty()) {
+            _gpuContext->executeFrame(frame);
+        }
+        auto &glBackend = static_cast<gpu::gl::GLBackend&>(*_backend);
+        readFbo = glBackend.getFramebufferID(frame->framebuffer);
+        readFboSize = frame->framebuffer->getSize();
+        CHECK_GL_ERROR();
+    } else {
+        hifi::qml::OffscreenSurface::TextureAndFence newTextureAndFence;
+        if (_offscreen->fetchTexture(newTextureAndFence)) {
+            if (_uiTexture != 0) {
+                auto readFence = glFenceSync(GL_SYNC_GPU_COMMANDS_COMPLETE, 0);
+                glFlush();
+                _offscreen->getDiscardLambda()(_uiTexture, readFence);
+                _uiTexture = 0;
+            }
+
+            glWaitSync((GLsync)newTextureAndFence.second, 0, GL_TIMEOUT_IGNORED);
+            glDeleteSync((GLsync)newTextureAndFence.second);
+            _uiTexture = newTextureAndFence.first;
+            glBindFramebuffer(GL_READ_FRAMEBUFFER, _uiFbo);
+            glFramebufferTexture2D(GL_READ_FRAMEBUFFER, GL_COLOR_ATTACHMENT0, GL_TEXTURE_2D, _uiTexture, 0);
+        }
+
+        if (_uiTexture != 0) {
+            readFbo = _uiFbo;
+            readFboSize = { windowSize.width(), windowSize.height() };
+        }
+    }
+
+    if (readFbo) {
+        glBindFramebuffer(GL_DRAW_FRAMEBUFFER, 0);
+        glBindFramebuffer(GL_READ_FRAMEBUFFER, readFbo);
+        glBlitFramebuffer(
+            0, 0, readFboSize.x, readFboSize.y,
+            0, 0, windowSize.width(), windowSize.height(),
+            GL_COLOR_BUFFER_BIT, GL_NEAREST);
+        glBindFramebuffer(GL_READ_FRAMEBUFFER, 0);
+    } else {
+        glClearColor(1, 0, 0, 1);
+        glClear(GL_COLOR_BUFFER_BIT);
+    }
+
+    _glContext.swapBuffers();
+}
+
+void RenderThread::updateFrame() {
+    std::queue<gpu::FramePointer> pendingFrames;
+    {
+        std::unique_lock<std::mutex> lock(_frameLock);
+        pendingFrames.swap(_pendingFrames);
+    }
+
+    while (!pendingFrames.empty()) {
+        _activeFrame = pendingFrames.front();
+        pendingFrames.pop();
+        if (_activeFrame) {
+            _gpuContext->consumeFrameUpdates(_activeFrame);
+        }
+    }
+}
+
+bool RenderThread::process() {
+    updateFrame();
+    makeCurrent();
+    renderFrame();
+    return true;
+}

android/apps/framePlayer/src/main/cpp/RenderThread.h

@@ -0,0 +1,54 @@
+//
+//  Created by Bradley Austin Davis on 2018/10/21
+//  Copyright 2014 High Fidelity, Inc.
+//
+//  Distributed under the Apache License, Version 2.0.
+//  See the accompanying file LICENSE or http://www.apache.org/licenses/LICENSE-2.0.html
+//
+
+#pragma once
+
+#include <GenericThread.h>
+
+#include <gl/Context.h>
+#include <gpu/gl/GLBackend.h>
+#include <qml/OffscreenSurface.h>
+
+class RenderThread : public GenericThread {
+    using Parent = GenericThread;
+public:
+    QWindow* _window{ nullptr };
+    std::mutex _mutex;
+    gpu::ContextPointer _gpuContext;  // initialized during window creation
+    std::shared_ptr<gpu::Backend> _backend;
+    std::atomic<size_t> _presentCount{ 0 };
+    std::mutex _frameLock;
+    std::queue<gpu::FramePointer> _pendingFrames;
+    gpu::FramePointer _activeFrame;
+    uint32_t _externalTexture{ 0 };
+    glm::mat4 _correction;
+    hifi::qml::OffscreenSurface* _offscreen{ nullptr };
+
+    gl::Context _glContext;
+    uint32_t _uiTexture{ 0 };
+    uint32_t _uiFbo{ 0 };
+
+    void move(const glm::vec3& v);
+    void setup() override;
+    bool process() override;
+    void shutdown() override;
+
+    void initialize(QWindow* window, hifi::qml::OffscreenSurface* offscreen);
+
+    void submitFrame(const gpu::FramePointer& frame);
+    void updateFrame();
+    void renderFrame();
+
+    bool makeCurrent() {
+        return _glContext.makeCurrent();
+    }
+
+    void doneCurrent() {
+        _glContext.doneCurrent();
+    }
+};

android/apps/framePlayer/src/main/cpp/main.cpp

@@ -0,0 +1,54 @@
+//
+//  Created by Bradley Austin Davis on 2018/11/22
+//  Copyright 2014 High Fidelity, Inc.
+//
+//  Distributed under the Apache License, Version 2.0.
+//  See the accompanying file LICENSE or http://www.apache.org/licenses/LICENSE-2.0.html
+//
+
+#include <android/log.h>
+
+#include <QtGui/QGuiApplication>
+#include <QtCore/QTimer>
+#include <QtCore/QFileInfo>
+
+#include <Trace.h>
+
+#include "PlayerWindow.h"
+
+void messageHandler(QtMsgType type, const QMessageLogContext& context, const QString& message) {
+    if (!message.isEmpty()) {
+        const char * local=message.toStdString().c_str();
+        switch (type) {
+            case QtDebugMsg:
+                __android_log_write(ANDROID_LOG_DEBUG,"Interface",local);
+                break;
+            case QtInfoMsg:
+                __android_log_write(ANDROID_LOG_INFO,"Interface",local);
+                break;
+            case QtWarningMsg:
+                __android_log_write(ANDROID_LOG_WARN,"Interface",local);
+                break;
+            case QtCriticalMsg:
+                __android_log_write(ANDROID_LOG_ERROR,"Interface",local);
+                break;
+            case QtFatalMsg:
+            default:
+                __android_log_write(ANDROID_LOG_FATAL,"Interface",local);
+                abort();
+        }
+    }
+}
+
+int main(int argc, char** argv) {
+    setupHifiApplication("gpuFramePlayer");
+    QGuiApplication app(argc, argv);
+    auto oldMessageHandler = qInstallMessageHandler(messageHandler);
+    DependencyManager::set<tracing::Tracer>();
+    PlayerWindow window;
+    app.exec();
+    qInstallMessageHandler(oldMessageHandler);
+    return 0;
+}
+
+

android/apps/framePlayer/src/main/cpp/qml/main.qml

@@ -0,0 +1,36 @@
+import QtQuick 2.2
+import QtQuick.Dialogs 1.1
+import Qt.labs.folderlistmodel 2.11
+
+Item {
+    id: root
+    width: 640
+    height: 480
+
+    ListView {
+        anchors.fill: parent
+
+        FolderListModel {
+            id: folderModel
+            folder: FRAMES_FOLDER
+            nameFilters: ["*.json"]
+        }
+
+        Component {
+            id: fileDelegate
+            Text {
+                text: fileName
+                font.pointSize: 36
+                MouseArea {
+                    anchors.fill: parent
+                    onClicked: root.loadFile(folderModel.folder + "/" + fileName);
+                }
+            }
+        }
+
+        model: folderModel
+        delegate: fileDelegate
+    }
+
+    signal loadFile(string filename);
+}

android/apps/framePlayer/src/main/res/drawable/ic_launcher.xml

@@ -0,0 +1,17 @@
+<?xml version="1.0" encoding="utf-8"?>
+<!--suppress AndroidUnknownAttribute -->
+<vector xmlns:api24="http://schemas.android.com/apk/res/android" xmlns:android="http://schemas.android.com/apk/res/android"
+    android:viewportWidth="192"
+    android:viewportHeight="192"
+    android:width="192dp"
+    android:height="192dp">
+    <path
+        android:pathData="M189.5 96.5A93.5 93.5 0 0 1 96 190 93.5 93.5 0 0 1 2.5 96.5 93.5 93.5 0 0 1 96 3 93.5 93.5 0 0 1 189.5 96.5Z"
+        android:fillColor="#333333" />
+    <path
+        android:pathData="M96.2 173.1c-10.3 0 -20.4 -2.1 -29.8 -6 -9.2 -3.8 -17.3 -9.4 -24.3 -16.4 -7 -7 -12.6 -15.2 -16.4 -24.3 -4.1 -9.6 -6.2 -19.6 -6.2 -30 0 -10.3 2.1 -20.4 6 -29.8 3.8 -9.2 9.4 -17.3 16.4 -24.3 7 -7 15.2 -12.6 24.3 -16.4 9.5 -4 19.5 -6 29.8 -6 10.3 0 20.4 2.1 29.8 6 9.2 3.8 17.3 9.4 24.3 16.4 7 7 12.6 15.2 16.4 24.3 4 9.5 6 19.5 6 29.8 0 10.3 -2.1 20.4 -6 29.8 -3.8 9.2 -9.4 17.3 -16.4 24.3 -7 7 -15.2 12.6 -24.3 16.4 -9.2 4.1 -19.3 6.2 -29.6 6.2zm0 -145.3c-37.8 0 -68.6 30.8 -68.6 68.6 0 37.8 30.8 68.6 68.6 68.6 37.8 0 68.6 -30.8 68.6 -68.6 0 -37.8 -30.8 -68.6 -68.6 -68.6z"
+        android:fillColor="#00b4f0" />
+    <path
+        android:pathData="M119.6 129l0 -53.8c3.4 -1.1 5.8 -4.3 5.8 -8 0 -4.6 -3.8 -8.4 -8.4 -8.4 -4.6 0 -8.4 3.8 -8.4 8.4 0 3.6 2.2 6.6 5.4 7.9l0 25L79 83.8 79 64c3.4 -1.1 5.8 -4.3 5.8 -8 0 -4.6 -3.8 -8.4 -8.4 -8.4 -4.6 0 -8.4 3.8 -8.4 8.4 0 3.6 2.2 6.6 5.4 7.9l0 54.1c-3.1 1.2 -5.4 4.3 -5.4 7.9 0 4.6 3.8 8.4 8.4 8.4 4.6 0 8.4 -3.8 8.4 -8.4 0 -3.7 -2.4 -6.9 -5.8 -8l0 -27.3 35 16.3 0 22.2c-3.1 1.2 -5.4 4.3 -5.4 7.9 0 4.6 3.8 8.4 8.4 8.4 4.6 0 8.4 -3.8 8.4 -8.4 0 -3.8 -2.4 -6.9 -5.8 -8z"
+        android:fillColor="#00b4f0" />
+</vector>

android/apps/framePlayer/src/main/res/values/strings.xml

@@ -0,0 +1,3 @@
+<resources>
+    <string name="app_name" translatable="false">GPU Frame Player</string>
+</resources>

android/settings.gradle

@@ -3,3 +3,6 @@ project(':qt').projectDir = new File(settingsDir, 'libraries/qt')

 include ':interface'
 project(':interface').projectDir = new File(settingsDir, 'apps/interface')
+
+//include ':framePlayer'
+//project(':framePlayer').projectDir = new File(settingsDir, 'apps/framePlayer')

assignment-client/src/audio/AudioMixer.cpp

@@ -68,6 +68,13 @@ AudioMixer::AudioMixer(ReceivedMessage& message) :
     // hash the available codecs (on the mixer)
     _availableCodecs.clear(); // Make sure struct is clean
     auto pluginManager = DependencyManager::set<PluginManager>();
+    // Only load codec plugins; for now assume codec plugins have 'codec' in their name.
+    auto codecPluginFilter = [](const QJsonObject& metaData) {
+        QJsonValue nameValue = metaData["MetaData"]["name"];
+        return nameValue.toString().contains("codec", Qt::CaseInsensitive);
+    };
+    pluginManager->setPluginFilter(codecPluginFilter);
+
     auto codecPlugins = pluginManager->getCodecPlugins();
     for_each(codecPlugins.cbegin(), codecPlugins.cend(),
         [&](const CodecPluginPointer& codec) {

cmake/macros/TargetGlad.cmake

@@ -7,6 +7,7 @@
 #
 macro(TARGET_GLAD)
     if (ANDROID)
+        include(SelectLibraryConfigurations)
         set(INSTALL_DIR ${HIFI_ANDROID_PRECOMPILED}/glad)
         set(GLAD_INCLUDE_DIRS "${INSTALL_DIR}/include")
         set(GLAD_LIBRARY_DEBUG ${INSTALL_DIR}/lib/libglad_d.a)
@@ -31,8 +32,8 @@ macro(TARGET_GLAD)
         set(GLAD_INCLUDE_DIRS ${${GLAD_UPPER}_INCLUDE_DIRS})
         set(GLAD_LIBRARY ${${GLAD_UPPER}_LIBRARY})
     endif()
-
+
     target_include_directories(${TARGET_NAME} PUBLIC ${GLAD_INCLUDE_DIRS})
     target_link_libraries(${TARGET_NAME} ${GLAD_LIBRARY})
-    target_link_libraries(${TARGET_NAME} ${GLAD_EXTRA_LIBRARIES})
+    target_link_libraries(${TARGET_NAME} ${GLAD_EXTRA_LIBRARIES})
 endmacro()

cmake/macros/TargetZlib.cmake

@@ -6,8 +6,13 @@
 #  See the accompanying file LICENSE or http://www.apache.org/licenses/LICENSE-2.0.html
 #
 macro(TARGET_ZLIB)
-   	# using VCPKG for zlib
-    find_package(ZLIB REQUIRED)
-    target_include_directories(${TARGET_NAME} SYSTEM PRIVATE ${ZLIB_INCLUDE_DIRS})
-    target_link_libraries(${TARGET_NAME} ${ZLIB_LIBRARIES})
+    if (ANDROID)
+        # zlib is part of the NDK
+        target_link_libraries(${TARGET_NAME} z)
+    else()
+        # using VCPKG for zlib
+        find_package(ZLIB REQUIRED)
+        target_include_directories(${TARGET_NAME} SYSTEM PRIVATE ${ZLIB_INCLUDE_DIRS})
+        target_link_libraries(${TARGET_NAME} ${ZLIB_LIBRARIES})
+    endif()
 endmacro()

cmake/ports/nvtt/CONTROL

@@ -1,3 +1,3 @@
 Source: nvtt
-Version: 8c7e6b40ee5095f227b75880fabd89c99d6f34c0
+Version: 330c4d56274a0f602a5c70596e2eb670a4ed56c2
 Description: Texture processing tools with support for Direct3D 10 and 11 formats.

cmake/ports/nvtt/portfile.cmake

@@ -10,8 +10,8 @@ include(vcpkg_common_functions)
 vcpkg_from_github(
     OUT_SOURCE_PATH SOURCE_PATH
     REPO highfidelity/nvidia-texture-tools
-    REF 8c7e6b40ee5095f227b75880fabd89c99d6f34c0
-    SHA512 f107d19dbbd6651ef2126b1422a5db8db291bf70311ac4fb1dbacb5ceaa8752fee38becbd32964f57596f0b84e1223bb2c3ff9d9c4fdc65c3e77a47836657cef
+    REF 330c4d56274a0f602a5c70596e2eb670a4ed56c2
+    SHA512 4c0bc2f369120d696cc27710b6d33086b27eef55f537ec66b9a5c8b1839bc2426c0413670b0f65be52c5d353468f0126dfe024be1f0690611d4d7e33ac530127
     HEAD_REF master
 )


domain-server/src/AssetsBackupHandler.cpp

@@ -246,6 +246,7 @@ void AssetsBackupHandler::createBackup(const QString& backupName, QuaZip& zip) {

     if (_assetServerEnabled && _lastMappingsRefresh.time_since_epoch().count() == 0) {
         qCWarning(asset_backup) << "Current mappings not yet loaded.";
+        _backups.emplace_back(backupName, AssetUtils::Mappings(), true);
         return;
     }


interface/resources/qml/LoginDialog.qml

@@ -54,7 +54,8 @@ FocusScope {
     Image {
         z: -10
         id: loginDialogBackground
-        source: "LoginDialog/images/background.jpg"
+        fillMode: Image.PreserveAspectCrop
+        source: "LoginDialog/images/background.png"
         anchors.fill: parent
     }

@@ -119,6 +120,6 @@ FocusScope {
     }

     Component.onCompleted: {
-        bodyLoader.setSource("LoginDialog/LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "linkSteam": false });
+        bodyLoader.setSource("LoginDialog/LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "linkSteam": false, "linkOculus": false });
     }
 }

interface/resources/qml/LoginDialog/CompleteProfileBody.qml

@@ -22,11 +22,16 @@ Item {
     width: root.width
     height: root.height
     readonly property string termsContainerText: qsTr("By creating this user profile, you agree to High Fidelity's Terms of Service")
+    readonly property string termsContainerOculusText: qsTr("By signing up, you agree to High Fidelity's Terms of Service")
+    readonly property int textFieldHeight: 31
     readonly property string fontFamily: "Raleway"
     readonly property int fontSize: 15
     readonly property bool fontBold: true
+    readonly property int textFieldFontSize: 18
+    readonly property var passwordImageRatio: 16 / 23

-    readonly property bool withSteam: withSteam
+    property bool withOculus: withOculus
+    property bool withSteam: withSteam
     property string errorString: errorString

     readonly property bool loginDialogPoppedUp: loginDialog.getLoginDialogPoppedUp()
@@ -61,15 +66,20 @@ Item {

         Item {
             id: contentItem
-            anchors.fill: parent
+            width: parent.width
+            height: errorContainer.height + fields.height + buttons.height + additionalTextContainer.height +
+                termsContainer.height
+            anchors.top: parent.top
+            anchors.topMargin: root.bannerHeight + 0.25 * parent.height
+            anchors.left: parent.left

             Item {
                 id: errorContainer
-                width: parent.width
+                width: root.bannerWidth
                 height: loginErrorMessageTextMetrics.height
                 anchors {
-                    bottom: buttons.top;
-                    bottomMargin: hifi.dimensions.contentSpacing.y;
+                    bottom: completeProfileBody.withOculus ? fields.top : buttons.top;
+                    bottomMargin: 1.5 * hifi.dimensions.contentSpacing.y;
                     left: buttons.left;
                 }
                 TextMetrics {
@@ -79,8 +89,8 @@ Item {
                 }
                 Text {
                     id: loginErrorMessage;
-                    width: root.bannerWidth
                     color: "red";
+                    width: root.bannerWidth;
                     font.family: completeProfileBody.fontFamily
                     font.pixelSize: 18
                     font.bold: completeProfileBody.fontBold
@@ -88,13 +98,196 @@ Item {
                     horizontalAlignment: Text.AlignHCenter
                     text: completeProfileBody.errorString
                     visible: true
+                    onTextChanged: {
+                        mainContainer.recalculateErrorMessage();
+                    }
+                    Component.onCompleted: {
+                        mainContainer.recalculateErrorMessage();
+                    }
                 }
-                Component.onCompleted: {
-                    if (loginErrorMessageTextMetrics.width > root.bannerWidth && root.isTablet) {
-                        loginErrorMessage.wrapMode = Text.WordWrap;
-                        loginErrorMessage.verticalAlignment = Text.AlignLeft;
-                        loginErrorMessage.horizontalAlignment = Text.AlignLeft;
-                        errorContainer.height = 3 * loginErrorMessageTextMetrics.height;
+            }
+
+            Item {
+                id: fields
+                width: root.bannerWidth
+                height: 3 * completeProfileBody.textFieldHeight + 2 * hifi.dimensions.contentSpacing.y
+                visible: completeProfileBody.withOculus
+                anchors {
+                    left: parent.left
+                    leftMargin: (parent.width - root.bannerWidth) / 2
+                    bottom: buttons.top
+                    bottomMargin: hifi.dimensions.contentSpacing.y
+                }
+
+                HifiControlsUit.TextField {
+                    id: usernameField
+                    width: root.bannerWidth
+                    height: completeProfileBody.textFieldHeight
+                    placeholderText: "Username"
+                    font.pixelSize: completeProfileBody.textFieldFontSize
+                    styleRenderType: Text.QtRendering
+                    anchors {
+                        top: parent.top
+                    }
+                    Keys.onPressed: {
+                        if (!usernameField.visible) {
+                            return;
+                        }
+                        switch (event.key) {
+                            case Qt.Key_Tab:
+                                event.accepted = true;
+                                if (event.modifiers === Qt.ShiftModifier) {
+                                    passwordField.focus = true;
+                                } else {
+                                    emailField.focus = true;
+                                }
+                                break;
+                            case Qt.Key_Backtab:
+                                event.accepted = true;
+                                passwordField.focus = true;
+                                break;
+                            case Qt.Key_Enter:
+                            case Qt.Key_Return:
+                                event.accepted = true;
+                                loginDialog.createAccountFromOculus(emailField.text, usernameField.text, passwordField.text);
+                                bodyLoader.setSource("LoggingInBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": completeProfileBody.withSteam,
+                                    "linkSteam": false, "withOculus": completeProfileBody.withOculus, "linkOculus": false, "createOculus": true });
+                                break;
+                        }
+                    }
+                    onFocusChanged: {
+                        root.text = "";
+                        if (focus) {
+                            root.isPassword = false;
+                        }
+                    }
+                    Component.onCompleted: {
+                        var userID = "";
+                        if (completeProfileBody.withOculus) {
+                            userID = loginDialog.oculusUserID();
+                        }
+                        usernameField.text = userID;
+                    }
+                }
+                HifiControlsUit.TextField {
+                    id: emailField
+                    width: root.bannerWidth
+                    height: completeProfileBody.textFieldHeight
+                    anchors {
+                        top: usernameField.bottom
+                        topMargin: hifi.dimensions.contentSpacing.y
+                    }
+                    placeholderText: "Email"
+                    font.pixelSize: completeProfileBody.textFieldFontSize
+                    styleRenderType: Text.QtRendering
+                    activeFocusOnPress: true
+                    Keys.onPressed: {
+                        switch (event.key) {
+                            case Qt.Key_Tab:
+                                event.accepted = true;
+                                if (event.modifiers === Qt.ShiftModifier) {
+                                    usernameField.focus = true;
+                                } else {
+                                    passwordField.focus = true;
+                                }
+                                break;
+                            case Qt.Key_Backtab:
+                                event.accepted = true;
+                                usernameField.focus = true;
+                                break;
+                            case Qt.Key_Enter:
+                            case Qt.Key_Return:
+                                event.accepted = true;
+                                loginDialog.createAccountFromOculus(emailField.text, usernameField.text, passwordField.text);
+                                bodyLoader.setSource("LoggingInBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": completeProfileBody.withSteam,
+                                    "linkSteam": false, "withOculus": completeProfileBody.withOculus, "linkOculus": false, "createOculus": true });
+                                break;
+                        }
+                    }
+                    onFocusChanged: {
+                        root.text = "";
+                        if (focus) {
+                            root.isPassword = false;
+                        }
+                    }
+                }
+                HifiControlsUit.TextField {
+                    id: passwordField
+                    width: root.bannerWidth
+                    height: completeProfileBody.textFieldHeight
+                    placeholderText: "Password (optional)"
+                    font.pixelSize: completeProfileBody.textFieldFontSize
+                    styleRenderType: Text.QtRendering
+                    activeFocusOnPress: true
+                    echoMode: passwordFieldMouseArea.showPassword ? TextInput.Normal : TextInput.Password
+                    anchors {
+                        top: emailField.bottom
+                        topMargin: hifi.dimensions.contentSpacing.y
+                    }
+
+                    onFocusChanged: {
+                        root.text = "";
+                        root.isPassword = focus;
+                    }
+
+                    Item {
+                        id: showPasswordContainer
+                        z: 10
+                        // width + image's rightMargin
+                        width: showPasswordImage.width + 8
+                        height: parent.height
+                        anchors {
+                            right: parent.right
+                        }
+
+                        Image {
+                            id: showPasswordImage
+                            width: passwordField.height * passwordImageRatio
+                            height: passwordField.height * passwordImageRatio
+                            anchors {
+                                right: parent.right
+                                rightMargin: 8
+                                top: parent.top
+                                topMargin: passwordFieldMouseArea.showPassword ? 6 : 8
+                                bottom: parent.bottom
+                                bottomMargin: passwordFieldMouseArea.showPassword ? 5 : 8
+                            }
+                            source: passwordFieldMouseArea.showPassword ?  "../../images/eyeClosed.svg" : "../../images/eyeOpen.svg"
+                            MouseArea {
+                                id: passwordFieldMouseArea
+                                anchors.fill: parent
+                                acceptedButtons: Qt.LeftButton
+                                property bool showPassword: false
+                                onClicked: {
+                                    showPassword = !showPassword;
+                                }
+                            }
+                        }
+                    }
+                    Keys.onPressed: {
+                        switch (event.key) {
+                            case Qt.Key_Tab:
+                                event.accepted = true;
+                                if (event.modifiers === Qt.ShiftModifier) {
+                                    emailField.focus = true;
+                                } else if (usernameField.visible) {
+                                    usernameField.focus = true;
+                                } else {
+                                    emailField.focus = true;
+                                }
+                                break;
+                            case Qt.Key_Backtab:
+                                event.accepted = true;
+                                emailField.focus = true;
+                                break;
+                        case Qt.Key_Enter:
+                        case Qt.Key_Return:
+                            event.accepted = true;
+                            loginDialog.createAccountFromOculus(emailField.text, usernameField.text, passwordField.text);
+                            bodyLoader.setSource("LoggingInBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": completeProfileBody.withSteam,
+                                "linkSteam": false, "withOculus": completeProfileBody.withOculus, "linkOculus": false, "createOculus": true });
+                            break;
+                        }
                     }
                 }
             }
@@ -105,7 +298,7 @@ Item {
                 height: d.minHeightButton
                 anchors {
                     top: parent.top
-                    topMargin: (parent.height - additionalTextContainer.height) / 2 - hifi.dimensions.contentSpacing.y
+                    topMargin: (parent.height - additionalTextContainer.height + fields.height) / 2 - hifi.dimensions.contentSpacing.y
                     left: parent.left
                     leftMargin: (parent.width - root.bannerWidth) / 2
                 }
@@ -144,7 +337,7 @@ Item {
                     width: (parent.width - hifi.dimensions.contentSpacing.x) / 2
                     height: d.minHeightButton

-                    text: qsTr("Create your profile")
+                    text: completeProfileBody.withOculus ? qsTr("Sign Up") : qsTr("Create your profile")
                     color: hifi.buttons.blue

                     fontFamily: completeProfileBody.fontFamily
@@ -158,55 +351,12 @@ Item {
                             UserActivityLogger.logAction("encourageLoginDialog", data);
                         }
                         loginErrorMessage.visible = false;
-                        loginDialog.createAccountFromSteam();
-                    }
-                }
-            }
-
-            Item {
-                id: additionalTextContainer
-                width: parent.width
-                height: additionalTextMetrics.height
-                anchors {
-                    top: buttons.bottom
-                    horizontalCenter: parent.horizontalCenter
-                    topMargin: hifi.dimensions.contentSpacing.y
-                    left: parent.left
-                }
-
-                TextMetrics {
-                    id: additionalTextMetrics
-                    font: additionalText.font
-                    text: "Already have a High Fidelity profile? Link to an existing profile here."
-                }
-
-                HifiStylesUit.ShortcutText {
-                    id: additionalText
-                    text: "<a href='https://fake.link'>Already have a High Fidelity profile? Link to an existing profile here.</a>"
-
-                    font.family: completeProfileBody.fontFamily
-                    font.pixelSize: completeProfileBody.fontSize
-                    font.bold: completeProfileBody.fontBold
-                    wrapMode: Text.NoWrap
-                    lineHeight: 1
-                    lineHeightMode: Text.ProportionalHeight
-                    horizontalAlignment: Text.AlignHCenter
-                    linkColor: hifi.colors.blueAccent
-
-                    onLinkActivated: {
-                        loginDialog.isLogIn = true;
-                        bodyLoader.setSource("LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "errorString": "", "withSteam": true, "linkSteam": true });
-                    }
-                    Component.onCompleted: {
-                        if (additionalTextMetrics.width > root.bannerWidth && root.isTablet) {
-                            additionalText.width = root.bannerWidth;
-                            additionalText.wrapMode = Text.WordWrap;
-                            additionalText.verticalAlignment = Text.AlignLeft;
-                            additionalText.horizontalAlignment = Text.AlignLeft;
-                            additionalTextContainer.height = (additionalTextMetrics.width / root.bannerWidth) * additionalTextMetrics.height;
-                            additionalTextContainer.anchors.left = buttons.left;
-                        } else {
-                            additionalText.anchors.centerIn = additionalTextContainer;
+                        if (completeProfileBody.withOculus) {
+                            loginDialog.createAccountFromOculus(emailField.text, usernameField.text, passwordField.text);
+                            bodyLoader.setSource("LoggingInBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": completeProfileBody.withSteam,
+                                "linkSteam": false, "withOculus": completeProfileBody.withOculus, "linkOculus": false, "createOculus": true });
+                        } else if (completeProfileBody.withSteam) {
+                            loginDialog.createAccountFromSteam();
                         }
                     }
                 }
@@ -217,29 +367,33 @@ Item {
                 width: parent.width
                 height: termsTextMetrics.height
                 anchors {
-                    top: additionalTextContainer.bottom
+                    top: buttons.bottom
                     horizontalCenter: parent.horizontalCenter
-                    topMargin: 2 * hifi.dimensions.contentSpacing.y
+                    topMargin: hifi.dimensions.contentSpacing.y
                     left: parent.left
                 }
                 TextMetrics {
                     id: termsTextMetrics
                     font: termsText.font
-                    text: completeProfileBody.termsContainerText
+                    text: completeProfileBody.withOculus ? completeProfileBody.termsContainerOculusText : completeProfileBody.termsContainerText
                     Component.onCompleted: {
                         // with the link.
-                        termsText.text = qsTr("By creating this user profile, you agree to <a href='https://highfidelity.com/terms'>High Fidelity's Terms of Service</a>")
+                        if (completeProfileBody.withOculus) {
+                            termsText.text = qsTr("By signing up, you agree to <a href='https://highfidelity.com/terms'>High Fidelity's Terms of Service</a>")
+                        } else {
+                            termsText.text = qsTr("By creating this user profile, you agree to <a href='https://highfidelity.com/terms'>High Fidelity's Terms of Service</a>")
+                        }
                     }
                 }

                 HifiStylesUit.InfoItem {
                     id: termsText
-                    text: completeProfileBody.termsContainerText
+                    text: completeProfileBody.withOculus ? completeProfileBody.termsContainerOculusText : completeProfileBody.termsContainerText
                     font.family: completeProfileBody.fontFamily
                     font.pixelSize: completeProfileBody.fontSize
                     font.bold: completeProfileBody.fontBold
                     wrapMode: Text.WordWrap
-                    color: hifi.colors.lightGray
+                    color: hifi.colors.white
                     linkColor: hifi.colors.blueAccent
                     lineHeight: 1
                     lineHeightMode: Text.ProportionalHeight
@@ -247,7 +401,7 @@ Item {
                     onLinkActivated: loginDialog.openUrl(link);

                     Component.onCompleted: {
-                        if (termsTextMetrics.width > root.bannerWidth && root.isTablet) {
+                        if (termsTextMetrics.width > root.bannerWidth) {
                             termsText.width = root.bannerWidth;
                             termsText.wrapMode = Text.WordWrap;
                             additionalText.verticalAlignment = Text.AlignLeft;
@@ -260,14 +414,86 @@ Item {
                     }
                 }
             }
+
+            Item {
+                id: additionalTextContainer
+                width: parent.width
+                height: additionalTextMetrics.height
+                anchors {
+                    top: termsContainer.bottom
+                    horizontalCenter: parent.horizontalCenter
+                    topMargin: 2 * hifi.dimensions.contentSpacing.y
+                    left: parent.left
+                }
+
+                TextMetrics {
+                    id: additionalTextMetrics
+                    font: additionalText.font
+                    text: "Already have a High Fidelity profile? Link to an existing profile here."
+                }
+
+                HifiStylesUit.ShortcutText {
+                    id: additionalText
+                    text: "<a href='https://fake.link'>Already have a High Fidelity profile? Link to an existing profile here.</a>"
+                    width: root.bannerWidth;
+                    font.family: completeProfileBody.fontFamily
+                    font.pixelSize: completeProfileBody.fontSize
+                    font.bold: completeProfileBody.fontBold
+                    wrapMode: Text.NoWrap
+                    lineHeight: 1
+                    lineHeightMode: Text.ProportionalHeight
+                    horizontalAlignment: Text.AlignHCenter
+                    linkColor: hifi.colors.blueAccent
+
+                    onLinkActivated: {
+                        bodyLoader.setSource("LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "errorString": "",
+                            "withSteam": completeProfileBody.withSteam, "linkSteam": completeProfileBody.withSteam, "withOculus": completeProfileBody.withOculus,
+                            "linkOculus": completeProfileBody.withOculus });
+                    }
+                    Component.onCompleted: {
+                        if (additionalTextMetrics.width > root.bannerWidth) {
+                            additionalText.wrapMode = Text.WordWrap;
+                            additionalText.verticalAlignment = Text.AlignLeft;
+                            additionalText.horizontalAlignment = Text.AlignLeft;
+                            additionalTextContainer.height = (additionalTextMetrics.width / root.bannerWidth) * additionalTextMetrics.height;
+                            additionalTextContainer.anchors.left = buttons.left;
+                        } else {
+                            additionalText.anchors.centerIn = additionalTextContainer;
+                        }
+                    }
+                }
+            }
+        }
+        function recalculateErrorMessage() {
+            if (completeProfileBody.errorString !== "") {
+                loginErrorMessage.visible = true;
+                var errorLength = completeProfileBody.errorString.split(/\r\n|\r|\n/).length;
+                var errorStringEdited = completeProfileBody.errorString.replace(/[\n\r]+/g, "\n");
+                loginErrorMessage.text = errorStringEdited;
+                if (errorLength > 1.0) {
+                    loginErrorMessage.wrapMode = Text.WordWrap;
+                    loginErrorMessage.verticalAlignment = Text.AlignLeft;
+                    loginErrorMessage.horizontalAlignment = Text.AlignLeft;
+                    errorContainer.height = errorLength * loginErrorMessageTextMetrics.height;
+                } else if (loginErrorMessageTextMetrics.width > root.bannerWidth) {
+                    loginErrorMessage.wrapMode = Text.WordWrap;
+                    loginErrorMessage.verticalAlignment = Text.AlignLeft;
+                    loginErrorMessage.horizontalAlignment = Text.AlignLeft;
+                    errorContainer.height = (loginErrorMessageTextMetrics.width / root.bannerWidth) * loginErrorMessageTextMetrics.height;
+                } else {
+                    loginErrorMessage.wrapMode = Text.NoWrap;
+                    loginErrorMessage.verticalAlignment = Text.AlignVCenter;
+                    loginErrorMessage.horizontalAlignment = Text.AlignHCenter;
+                    errorContainer.height = loginErrorMessageTextMetrics.height;
+                }
+            }
         }
     }

     Connections {
         target: loginDialog
         onHandleCreateCompleted: {
-            console.log("Create Succeeded")
-
+            console.log("Create Succeeded");
             if (completeProfileBody.withSteam) {
                 if (completeProfileBody.loginDialogPoppedUp) {
                     var data = {
@@ -277,20 +503,24 @@ Item {
                 }
                 loginDialog.loginThroughSteam();
             }
-            bodyLoader.setSource("LoggingInBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": completeProfileBody.withSteam, "linkSteam": false });
+            bodyLoader.setSource("LoggingInBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": completeProfileBody.withSteam, "linkSteam": false,
+                "withOculus": completeProfileBody.withOculus, "linkOculus": false });
         }
         onHandleCreateFailed: {
             console.log("Create Failed: " + error);
-            if (completeProfileBody.withSteam) {
+            if (completeProfileBody.withSteam || completeProfileBody.withOculus) {
                 if (completeProfileBody.loginDialogPoppedUp) {
+                    action = completeProfileBody.withSteam ? "Steam" : "Oculus";
                     var data = {
-                        "action": "user failed to create a profile with Steam from the complete profile screen"
+                        "action": "user failed to create a profile with " + action + " from the complete profile screen"
                     }
                     UserActivityLogger.logAction("encourageLoginDialog", data);
                 }
             }
-
-            bodyLoader.setSource("UsernameCollisionBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": completeProfileBody.withSteam });
+            if (!completeProfileBody.withOculus) {
+                bodyLoader.setSource("UsernameCollisionBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": completeProfileBody.withSteam,
+                    "withOculus": completeProfileBody.withOculus });
+            }
         }
     }

@@ -302,5 +532,6 @@ Item {
         }
         d.resize();
         root.text = "";
+        usernameField.forceActiveFocus();
     }
 }

interface/resources/qml/LoginDialog/LinkAccountBody.qml

@@ -36,9 +36,10 @@ Item {
     property bool keyboardRaised: false
     property bool punctuationMode: false

-    property bool withSteam: false
+    property bool withSteam: withSteam
     property bool linkSteam: linkSteam
-    property bool withOculus: false
+    property bool withOculus: withOculus
+    property bool linkOculus: linkOculus
     property string errorString: errorString
     property bool lostFocus: false

@@ -83,23 +84,24 @@ Item {
             }
             UserActivityLogger.logAction("encourageLoginDialog", data);
         }
-
-        bodyLoader.setSource("LoggingInBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": linkAccountBody.withSteam, "withOculus": linkAccountBody.withOculus, "linkSteam": linkAccountBody.linkSteam });
+        bodyLoader.setSource("LoggingInBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": linkAccountBody.withSteam,
+            "withOculus": linkAccountBody.withOculus, "linkSteam": linkAccountBody.linkSteam, "linkOculus": linkAccountBody.linkOculus });
     }

     function init() {
         // going to/from sign in/up dialog.
-        loginDialog.isLogIn = true;
         loginErrorMessage.text = linkAccountBody.errorString;
         loginErrorMessage.visible = (linkAccountBody.errorString  !== "");
-        loginButton.text = !linkAccountBody.linkSteam ? "Log In" : "Link Account";
+        if (loginErrorMessageTextMetrics.width > emailField.width) {
+            loginErrorMessage.wrapMode = Text.WordWrap;
+            errorContainer.height = (loginErrorMessageTextMetrics.width / emailField.width) * loginErrorMessageTextMetrics.height;
+        }
+        loginButton.text = (!linkAccountBody.linkSteam && !linkAccountBody.linkOculus) ? "Log In" : "Link Account";
         loginButton.color = hifi.buttons.blue;
         emailField.placeholderText = "Username or Email";
         var savedUsername = Settings.getValue("keepMeLoggedIn/savedUsername", "");
         emailField.text = keepMeLoggedInCheckbox.checked ? savedUsername === "Unknown user" ? "" : savedUsername : "";
-        if (linkAccountBody.linkSteam) {
-            steamInfoText.anchors.top = passwordField.bottom;
-            keepMeLoggedInCheckbox.anchors.top = steamInfoText.bottom;
+        if (linkAccountBody.linkSteam || linkAccountBody.linkOculus) {
             loginButton.width = (passwordField.width - hifi.dimensions.contentSpacing.x) / 2;
             loginButton.anchors.right = emailField.right;
         } else {
@@ -125,7 +127,7 @@ Item {
             id: loginContainer
             width: emailField.width
             height: errorContainer.height + emailField.height + passwordField.height + 5.5 * hifi.dimensions.contentSpacing.y +
-                keepMeLoggedInCheckbox.height + loginButton.height + cantAccessTextMetrics.height + continueButton.height + steamInfoTextMetrics.height
+                keepMeLoggedInCheckbox.height + loginButton.height + cantAccessTextMetrics.height + continueButton.height
             anchors {
                 top: parent.top
                 topMargin: root.bannerHeight + 0.25 * parent.height
@@ -135,7 +137,7 @@ Item {

             Item {
                 id: errorContainer
-                width: loginErrorMessageTextMetrics.width
+                width: parent.width
                 height: loginErrorMessageTextMetrics.height
                 anchors {
                     bottom: emailField.top;
@@ -304,7 +306,7 @@ Item {
                 fontSize: linkAccountBody.fontSize
                 fontBold: linkAccountBody.fontBold
                 color: hifi.buttons.noneBorderlessWhite;
-                visible: linkAccountBody.linkSteam
+                visible: linkAccountBody.linkSteam || linkAccountBody.linkOculus
                 anchors {
                     top: keepMeLoggedInCheckbox.bottom
                     topMargin: hifi.dimensions.contentSpacing.y
@@ -315,10 +317,9 @@ Item {
                             "action": "user clicked cancel at link account screen"
                         };
                         UserActivityLogger.logAction("encourageLoginDialog", data);
-                        loginDialog.dismissLoginDialog();
                     }
-
-                    bodyLoader.setSource("CompleteProfileBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": linkAccountBody.withSteam, "errorString": "" });
+                    bodyLoader.setSource("CompleteProfileBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": linkAccountBody.withSteam,
+                        "withOculus": linkAccountBody.withOculus, "errorString": "" });
                 }
             }
             HifiControlsUit.Button {
@@ -337,33 +338,6 @@ Item {
                     linkAccountBody.login();
                 }
             }
-            TextMetrics {
-                id: steamInfoTextMetrics
-                font: steamInfoText.font
-                text: steamInfoText.text
-            }
-            Text {
-                id: steamInfoText
-                width: root.bannerWidth
-                visible: linkAccountBody.linkSteam
-                anchors {
-                    top: loginButton.bottom
-                    topMargin: hifi.dimensions.contentSpacing.y
-                    left: emailField.left
-                }
-
-                font.family: linkAccountBody.fontFamily
-                font.pixelSize: linkAccountBody.textFieldFontSize
-                color: "white"
-                text: qsTr("Your Steam account information will not be exposed to others.");
-                verticalAlignment: Text.AlignVCenter
-                horizontalAlignment: Text.AlignHCenter
-                Component.onCompleted: {
-                    if (steamInfoTextMetrics.width > root.bannerWidth) {
-                        steamInfoText.wrapMode = Text.WordWrap;
-                    }
-                }
-            }
             TextMetrics {
                 id: cantAccessTextMetrics
                 font: cantAccessText.font
@@ -372,7 +346,7 @@ Item {
             HifiStylesUit.ShortcutText {
                 id: cantAccessText
                 z: 10
-                visible: !linkAccountBody.linkSteam
+                visible: !linkAccountBody.linkSteam && !linkAccountBody.linkOculus
                 anchors {
                     top: loginButton.bottom
                     topMargin: hifi.dimensions.contentSpacing.y
@@ -423,10 +397,10 @@ Item {
                 buttonGlyphSize: 24
                 buttonGlyphRightMargin: 10
                 onClicked: {
-                    // if (loginDialog.isOculusStoreRunning()) {
-                    //     linkAccountBody.withOculus = true;
-                    //     loginDialog.loginThroughSteam();
-                    // } else
+                    if (loginDialog.isOculusRunning()) {
+                        linkAccountBody.withOculus = true;
+                        loginDialog.loginThroughOculus();
+                    } else
                     if (loginDialog.isSteamRunning()) {
                         linkAccountBody.withSteam = true;
                         loginDialog.loginThroughSteam();
@@ -446,18 +420,17 @@ Item {
                     }

                     bodyLoader.setSource("LoggingInBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader,
-                        "withSteam": linkAccountBody.withSteam, "withOculus": linkAccountBody.withOculus, "linkSteam": linkAccountBody.linkSteam });
+                        "withSteam": linkAccountBody.withSteam, "withOculus": linkAccountBody.withOculus, "linkSteam": linkAccountBody.linkSteam, "linkOculus": linkAccountBody.linkOculus });
                 }
                 Component.onCompleted: {
-                    if (linkAccountBody.linkSteam) {
+                    if (linkAccountBody.linkSteam || linkAccountBody.linkOculus) {
                         continueButton.visible = false;
                         return;
                     }
-                    // if (loginDialog.isOculusStoreRunning()) {
-                    //     continueButton.text = qsTr("CONTINUE WITH OCULUS");
-                    //     continueButton.buttonGlyph = hifi.glyphs.oculus;
-                    // } else
-                    if (loginDialog.isSteamRunning()) {
+                    if (loginDialog.isOculusRunning()) {
+                        continueButton.text = qsTr("CONTINUE WITH OCULUS");
+                        continueButton.buttonGlyph = hifi.glyphs.oculus;
+                    } else if (loginDialog.isSteamRunning()) {
                         continueButton.text = qsTr("CONTINUE WITH STEAM");
                         continueButton.buttonGlyph = hifi.glyphs.steamSquare;
                     } else {
@@ -470,7 +443,7 @@ Item {
             id: signUpContainer
             width: loginContainer.width
             height: signUpTextMetrics.height
-            visible: !linkAccountBody.linkSteam
+            visible: !linkAccountBody.linkSteam && !linkAccountBody.linkOculus
             anchors {
                 left: loginContainer.left
                 top: loginContainer.bottom
@@ -519,7 +492,7 @@ Item {
                         UserActivityLogger.logAction("encourageLoginDialog", data);
                     }
                     bodyLoader.setSource("SignUpBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader,
-                        "errorString": "", "linkSteam": linkAccountBody.linkSteam });
+                        "errorString": "" });
                 }
             }
         }
@@ -543,7 +516,7 @@ Item {
             fontFamily: linkAccountBody.fontFamily
             fontSize: linkAccountBody.fontSize
             fontBold: linkAccountBody.fontBold
-            visible: linkAccountBody.loginDialogPoppedUp && !linkAccountBody.linkSteam;
+            visible: loginDialog.getLoginDialogPoppedUp() && !linkAccountBody.linkSteam && !linkAccountBody.linkOculus;
             onClicked: {
                 if (linkAccountBody.loginDialogPoppedUp) {
                     var data = {

interface/resources/qml/LoginDialog/LoggingInBody.qml

@@ -29,6 +29,8 @@ Item {
     property bool withSteam: withSteam
     property bool withOculus: withOculus
     property bool linkSteam: linkSteam
+    property bool linkOculus: linkOculus
+    property bool createOculus: createOculus

     readonly property bool loginDialogPoppedUp: loginDialog.getLoginDialogPoppedUp()

@@ -75,15 +77,25 @@ Item {
         }
     }

+    Timer {
+        id: oculusSuccessTimer
+        interval: 500;
+        running: false;
+        repeat: false;
+        onTriggered: {
+            loginDialog.loginThroughOculus();
+            init();
+        }
+    }
+
     function init() {
         // For the process of logging in.
         loggingInText.wrapMode = Text.NoWrap;
-
-        if (loggingInBody.linkSteam) {
+        if (loggingInBody.createOculus) {
+            loggingInGlyph.text = hifi.glyphs.oculus;
             loggingInGlyph.visible = true;
-            loggingInText.text = "Linking to Steam";
+            loggingInText.text = "Creating account with Oculus";
             loggingInText.x = loggingInHeader.width/2 - loggingInTextMetrics.width/2 + loggingInGlyphTextMetrics.width/2;
-            loginDialog.linkSteam();
         } else if (loggingInBody.withSteam) {
             loggingInGlyph.visible = true;
             loggingInText.text = "Logging in to Steam";
@@ -100,12 +112,18 @@ Item {
         loggingInSpinner.visible = true;
     }
     function loadingSuccess() {
-        loggingInSpinner.visible = false;
         if (loggingInBody.linkSteam) {
             loggingInText.text = "Linking to Steam";
+            loggingInText.x = loggingInHeader.width/2 - loggingInTextMetrics.width/2 + loggingInGlyphTextMetrics.width/2;
             loginDialog.linkSteam();
             return;
+        } else if (loggingInBody.linkOculus) {
+            loggingInText.text = "Linking to Oculus";
+            loggingInText.x = loggingInHeader.width/2 - loggingInTextMetrics.width/2 + loggingInGlyphTextMetrics.width/2;
+            loginDialog.linkOculus();
+            return;
         }
+        loggingInSpinner.visible = false;
         if (loggingInBody.withSteam) {
             // reset the flag.
             loggingInGlyph.visible = false;
@@ -246,6 +264,26 @@ Item {
                     verticalAlignment: Text.AlignVCenter;
                     visible: false;
                 }
+                HifiControlsUit.Button {
+                    id: okButton;
+                    width: d.minWidthButton
+                    height: d.minHeightButton
+                    text: qsTr("OK")
+                    color: hifi.buttons.white
+                    anchors {
+                        top: loggedInGlyph.bottom
+                        topMargin: 3 * hifi.dimensions.contentSpacing.y
+                        left: parent.left
+                        leftMargin: (parent.width - width) / 2;
+                    }
+                    onClicked: {
+                        root.tryDestroy();
+                        if (loginDialog.getLoginDialogPoppedUp()) {
+                            loginDialog.dismissLoginDialog();
+                        }
+                    }
+                    visible: false
+                }
             }
         }
     }
@@ -257,6 +295,34 @@ Item {

     Connections {
         target: loginDialog
+        onHandleCreateCompleted: {
+            console.log("Create Succeeded")
+            if (loggingInBody.withOculus) {
+                if (loggingInBody.loginDialogPoppedUp) {
+                    var data = {
+                        "action": "user created Oculus account successfully"
+                    };
+                    UserActivityLogger.logAction("encourageLoginDialog", data);
+                }
+                loggingInBody.createOculus = false;
+                loggingInText.text = "Account created!";
+                loggingInText.x = loggingInHeader.width/2 - loggingInTextMetrics.width/2 + loggingInGlyphTextMetrics.width/2;
+                oculusSuccessTimer.start();
+            }
+        }
+        onHandleCreateFailed: {
+            console.log("Create Failed: " + error);
+            if (loggingInBody.withOculus) {
+                if (loggingInBody.loginDialogPoppedUp) {
+                    var data = {
+                        "action": "user created Oculus account unsuccessfully"
+                    };
+                    UserActivityLogger.logAction("encourageLoginDialog", data);
+                }
+                bodyLoader.setSource("CompleteProfileBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": loggingInBody.withSteam,
+                    "withOculus": loggingInBody.withOculus, "errorString": error });
+            }
+        }
         onHandleLinkCompleted: {
             console.log("Link Succeeded");
             if (loggingInBody.linkSteam) {
@@ -267,21 +333,40 @@ Item {
                     };
                     UserActivityLogger.logAction("encourageLoginDialog", data);
                 }
-
-                loggingInBody.loadingSuccess();
+            } else if (loggingInBody.linkOculus) {
+                loggingInBody.linkOculus = false;
+                if (loggingInBody.loginDialogPoppedUp) {
+                    var data = {
+                        "action": "user linked Oculus with their hifi account credentials successfully"
+                    };
+                    UserActivityLogger.logAction("encourageLoginDialog", data);
+                }
             }
+            loggingInBody.loadingSuccess();
         }
         onHandleLinkFailed: {
             console.log("Link Failed: " + error);
-            if (loggingInBody.linkSteam) {
+            loggingInSpinner.visible = false;
+            if (loggingInBody.linkOculus) {
+                loggingInText.text = "Oculus failed to link";
+                if (loggingInBody.loginDialogPoppedUp) {
+                    var data = {
+                        "action": "user linked Oculus unsuccessfully"
+                    };
+                    UserActivityLogger.logAction("encourageLoginDialog", data);
+                }
+                okButton.visible = true;
+            } else if (loggingInBody.linkSteam){
                 if (loggingInBody.loginDialogPoppedUp) {
                     var data = {
                         "action": "user linked Steam unsuccessfully"
                     };
                     UserActivityLogger.logAction("encourageLoginDialog", data);
                 }
+            } else {
+                bodyLoader.setSource("LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "linkSteam": loggingInBody.linkSteam,
+                    "linkOculus": loggingInBody.linkOculus, "errorString": error });
             }
-            bodyLoader.setSource("LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "linkSteam": true, "errorString": error });
         }

         onHandleLoginCompleted: {
@@ -292,8 +377,19 @@ Item {
         onHandleLoginFailed: {
             console.log("Login Failed")
             loggingInSpinner.visible = false;
+            loggingInGlyph.visible = false;
             var errorString = "";
-            if (loggingInBody.linkSteam && loggingInBody.withSteam) {
+            if (loggingInBody.linkOculus && loggingInBody.withOculus) {
+                errorString = "Username or password is incorrect.";
+                if (loggingInBody.loginDialogPoppedUp) {
+                    var data = {
+                        "action": "user failed to link Oculus with their hifi account credentials"
+                    };
+                    UserActivityLogger.logAction("encourageLoginDialog", data);
+                }
+                bodyLoader.setSource("LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": loggingInBody.withSteam,
+                    "withOculus": loggingInBody.withOculus, "linkSteam": loggingInBody.linkSteam, "linkOculus": loggingInBody.linkOculus, "errorString": errorString });
+            } else if (loggingInBody.linkSteam && loggingInBody.withSteam) {
                 errorString = "Username or password is incorrect.";
                 if (loggingInBody.loginDialogPoppedUp) {
                     var data = {
@@ -301,9 +397,9 @@ Item {
                     };
                     UserActivityLogger.logAction("encourageLoginDialog", data);
                 }
-                bodyLoader.setSource("LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": loggingInBody.withSteam, "linkSteam": loggingInBody.linkSteam, "errorString": errorString });
+                bodyLoader.setSource("LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": loggingInBody.withSteam,
+                    "withOculus": loggingInBody.withOculus, "linkSteam": loggingInBody.linkSteam, "linkOculus": loggingInBody.linkOculus, "errorString": errorString });
             } else if (loggingInBody.withSteam) {
-                loggingInGlyph.visible = false;
                 errorString = "Your Steam authentication has failed. Please make sure you are logged into Steam and try again.";
                 if (loggingInBody.loginDialogPoppedUp) {
                     var data = {
@@ -311,19 +407,19 @@ Item {
                     };
                     UserActivityLogger.logAction("encourageLoginDialog", data);
                 }
-                bodyLoader.setSource("CompleteProfileBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": loggingInBody.withSteam, "errorString": errorString });
+                bodyLoader.setSource("CompleteProfileBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": loggingInBody.withSteam,
+                    "withOculus": loggingInBody.withOculus, "linkSteam": loggingInBody.linkSteam, "linkOculus": loggingInBody.linkOculus, "errorString": errorString });
             } else if (loggingInBody.withOculus) {
-                loggingInGlyph.visible = false;
-                errorString = "Your Oculus authentication has failed. Please make sure you are logged into Oculus and try again."
+                errorString = "Your Oculus account is not connected to an existing High Fidelity account. Please create a new one."
                 if (loggingInBody.loginDialogPoppedUp) {
                     var data = {
                         "action": "user failed to authenticate with Oculus to log in"
                     };
                     UserActivityLogger.logAction("encourageLoginDialog", data);
                 }
-                bodyLoader.setSource("LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "errorString": errorString });
-            }
-            else {
+                bodyLoader.setSource("CompleteProfileBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": loggingInBody.withSteam,
+                    "withOculus": loggingInBody.withOculus, "linkSteam": loggingInBody.linkSteam, "linkOculus": loggingInBody.linkOculus, "errorString": errorString });
+            } else {
                 errorString = "Username or password is incorrect.";
                 if (loggingInBody.loginDialogPoppedUp) {
                     var data = {

interface/resources/qml/LoginDialog/SignUpBody.qml

@@ -23,6 +23,7 @@ Item {
     clip: true
     height: root.height
     width: root.width
+    readonly property string termsContainerText: qsTr("By signing up, you agree to High Fidelity's Terms of Service")
     property int textFieldHeight: 31
     property string fontFamily: "Raleway"
     property int fontSize: 15
@@ -37,7 +38,6 @@ Item {
     onKeyboardRaisedChanged: d.resize();

     property string errorString: errorString
-    property bool linkSteam: linkSteam
     property bool lostFocus: false

     readonly property bool loginDialogPoppedUp: loginDialog.getLoginDialogPoppedUp()
@@ -73,7 +73,6 @@ Item {

     function init() {
         // going to/from sign in/up dialog.
-        loginDialog.isLogIn = false;
         emailField.placeholderText = "Email";
         emailField.text = "";
         emailField.anchors.top = usernameField.bottom;
@@ -353,7 +352,7 @@ Item {
                         }
                         UserActivityLogger.logAction("encourageLoginDialog", data);
                     }
-                    bodyLoader.setSource("LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "linkSteam": signUpBody.linkSteam });
+                    bodyLoader.setSource("LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "linkSteam": false });
                 }
             }
             HifiControlsUit.Button {
@@ -380,6 +379,54 @@ Item {
                     signUpBody.signup();
                 }
             }
+            Item {
+                id: termsContainer
+                width: parent.width
+                height: termsTextMetrics.height
+                anchors {
+                    top: signUpButton.bottom
+                    horizontalCenter: parent.horizontalCenter
+                    topMargin: 2 * hifi.dimensions.contentSpacing.y
+                    left: parent.left
+                }
+                TextMetrics {
+                    id: termsTextMetrics
+                    font: termsText.font
+                    text: signUpBody.termsContainerText
+                    Component.onCompleted: {
+                        // with the link.
+                        termsText.text = qsTr("By signing up, you agree to <a href='https://highfidelity.com/terms'>High Fidelity's Terms of Service</a>")
+                    }
+                }
+
+                HifiStylesUit.InfoItem {
+                    id: termsText
+                    text: signUpBody.termsContainerText
+                    font.family: signUpBody.fontFamily
+                    font.pixelSize: signUpBody.fontSize
+                    font.bold: signUpBody.fontBold
+                    wrapMode: Text.WordWrap
+                    color: hifi.colors.white
+                    linkColor: hifi.colors.blueAccent
+                    lineHeight: 1
+                    lineHeightMode: Text.ProportionalHeight
+
+                    onLinkActivated: loginDialog.openUrl(link);
+
+                    Component.onCompleted: {
+                        if (termsTextMetrics.width > root.bannerWidth) {
+                            termsText.width = root.bannerWidth;
+                            termsText.wrapMode = Text.WordWrap;
+                            additionalText.verticalAlignment = Text.AlignLeft;
+                            additionalText.horizontalAlignment = Text.AlignLeft;
+                            termsContainer.height = (termsTextMetrics.width / root.bannerWidth) * termsTextMetrics.height;
+                            termsContainer.anchors.left = buttons.left;
+                        } else {
+                            termsText.anchors.centerIn = termsContainer;
+                        }
+                    }
+                }
+            }
         }
     }

@@ -433,14 +480,15 @@ Item {

             if (errorString !== "") {
                 loginErrorMessage.visible = true;
+                var errorLength = errorString.split(/\r\n|\r|\n/).length;
                 var errorStringEdited = errorString.replace(/[\n\r]+/g, "\n");
                 loginErrorMessage.text = errorStringEdited;
-                loginErrorMessageTextMetrics.text = errorString;
-                if (loginErrorMessageTextMetrics.width > usernameField.width) {
+                if (errorLength > 1.0) {
+                    loginErrorMessage.width = root.bannerWidth;
                     loginErrorMessage.wrapMode = Text.WordWrap;
                     loginErrorMessage.verticalAlignment = Text.AlignLeft;
                     loginErrorMessage.horizontalAlignment = Text.AlignLeft;
-                    errorContainer.height = (loginErrorMessageTextMetrics.width / usernameField.width) * loginErrorMessageTextMetrics.height;
+                    errorContainer.height = errorLength * loginErrorMessageTextMetrics.height;
                 }
                 errorContainer.anchors.bottom = usernameField.top;
                 errorContainer.anchors.bottomMargin = hifi.dimensions.contentSpacing.y;

interface/resources/qml/LoginDialog/UsernameCollisionBody.qml

@@ -19,6 +19,7 @@ import TabletScriptingInterface 1.0
 Item {
     id: usernameCollisionBody
     clip: true
+    readonly property string termsContainerText: qsTr("By creating this user profile, you agree to High Fidelity's Terms of Service")
     width: root.width
     height: root.height
     readonly property string fontFamily: "Raleway"
@@ -26,13 +27,18 @@ Item {
     readonly property int textFieldFontSize: 18
     readonly property bool fontBold: true

-    readonly property bool withSteam: withSteam
+    property bool withSteam: withSteam
+    property bool withOculus: withOculus

     readonly property bool loginDialogPoppedUp: loginDialog.getLoginDialogPoppedUp()

     function create() {
         mainTextContainer.visible = false
-        loginDialog.createAccountFromSteam(textField.text);
+        if (usernameCollisionBody.withOculus) {
+            loginDialog.createAccountFromOculus(textField.text);
+        } else if (usernameCollisionBody.withSteam) {
+            loginDialog.createAccountFromSteam(textField.text);
+        }
     }

     property bool keyboardEnabled: false
@@ -90,12 +96,19 @@ Item {
             font.family: usernameCollisionBody.fontFamily
             font.pixelSize: usernameCollisionBody.fontSize
             font.bold: usernameCollisionBody.fontBold
-            text: qsTr("Your Steam username is not available.");
+            text: qsTr("");
             wrapMode: Text.WordWrap
             color: hifi.colors.redAccent
             lineHeight: 1
             lineHeightMode: Text.ProportionalHeight
             horizontalAlignment: Text.AlignHCenter
+            Component.onCompleted: {
+                if (usernameCollisionBody.withOculus) {
+                    text = qsTr("Your Oculus username is not available.");
+                } else if (usernameCollisionBody.withSteam) {
+                    text = qsTr("Your Steam username is not available.");
+                }
+            }
         }


@@ -164,7 +177,8 @@ Item {
                 fontSize: usernameCollisionBody.fontSize
                 fontBold: usernameCollisionBody.fontBold
                 onClicked: {
-                    bodyLoader.setSource("CompleteProfileBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "errorString": "" });
+                    bodyLoader.setSource("CompleteProfileBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": usernameCollisionBody.withSteam,
+                        "withOculus": usernameCollisionBody.withOculus, "errorString": "" });
                 }
             }
             HifiControlsUit.Button {
@@ -187,6 +201,55 @@ Item {
                 }
             }
         }
+        Item {
+            id: termsContainer
+            width: parent.width
+            height: termsTextMetrics.height
+            anchors {
+                top: buttons.bottom
+                horizontalCenter: parent.horizontalCenter
+                topMargin: 2 * hifi.dimensions.contentSpacing.y
+                left: parent.left
+                leftMargin: (parent.width - buttons.width) / 2
+            }
+            TextMetrics {
+                id: termsTextMetrics
+                font: termsText.font
+                text: usernameCollisionBody.termsContainerText
+                Component.onCompleted: {
+                    // with the link.
+                    termsText.text = qsTr("By creating this user profile, you agree to <a href='https://highfidelity.com/terms'>High Fidelity's Terms of Service</a>")
+                }
+            }
+
+            HifiStylesUit.InfoItem {
+                id: termsText
+                text: usernameCollisionBody.termsContainerText
+                font.family: usernameCollisionBody.fontFamily
+                font.pixelSize: usernameCollisionBody.fontSize
+                font.bold: usernameCollisionBody.fontBold
+                wrapMode: Text.WordWrap
+                color: hifi.colors.white
+                linkColor: hifi.colors.blueAccent
+                lineHeight: 1
+                lineHeightMode: Text.ProportionalHeight
+
+                onLinkActivated: loginDialog.openUrl(link);
+
+                Component.onCompleted: {
+                    if (termsTextMetrics.width > root.bannerWidth) {
+                        termsText.width = root.bannerWidth;
+                        termsText.wrapMode = Text.WordWrap;
+                        additionalText.verticalAlignment = Text.AlignLeft;
+                        additionalText.horizontalAlignment = Text.AlignLeft;
+                        termsContainer.height = (termsTextMetrics.width / root.bannerWidth) * termsTextMetrics.height;
+                        termsContainer.anchors.left = buttons.left;
+                    } else {
+                        termsText.anchors.centerIn = termsContainer;
+                    }
+                }
+            }
+        }
     }

     Component.onCompleted: {
@@ -201,18 +264,25 @@ Item {
         target: loginDialog
         onHandleCreateCompleted: {
             console.log("Create Succeeded");
-            if (usernameCollisionBody.withSteam) {
+            if (usernameCollisionBody.withOculus) {
+                if (usernameCollisionBody.loginDialogPoppedUp) {
+                    var data = {
+                        "action": "user created a profile with Oculus successfully in the username collision screen"
+                    }
+                    UserActivityLogger.logAction("encourageLoginDialog", data);
+                }
+                loginDialog.loginThroughOculus();
+            } else if (usernameCollisionBody.withSteam) {
                 if (usernameCollisionBody.loginDialogPoppedUp) {
                     var data = {
                         "action": "user created a profile with Steam successfully in the username collision screen"
                     }
                     UserActivityLogger.logAction("encourageLoginDialog", data);
                 }
-
                 loginDialog.loginThroughSteam();
             }
-
-            bodyLoader.setSource("LoggingInBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": usernameCollisionBody.withSteam, "linkSteam": false })
+            bodyLoader.setSource("LoggingInBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "withSteam": usernameCollisionBody.withSteam,
+                "withOculus": usernameCollisionBody.withOculus, "linkSteam": false, "linkOculus": false })
         }
         onHandleCreateFailed: {
             console.log("Create Failed: " + error)

interface/resources/qml/OverlayLoginDialog.qml

@@ -55,7 +55,8 @@ FocusScope {
     Image {
         z: -10
         id: loginDialogBackground
-        source: "LoginDialog/images/background.jpg"
+        fillMode: Image.PreserveAspectCrop
+        source: "LoginDialog/images/background.png"
         anchors.fill: parent
     }

@@ -149,6 +150,6 @@ FocusScope {

     Component.onCompleted: {
         keyboardTimer.start();
-        bodyLoader.setSource("LoginDialog/LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "linkSteam": false });
+        bodyLoader.setSource("LoginDialog/LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "linkSteam": false, "linkOculus": false });
     }
 }

interface/resources/qml/androidAppForce/ForFolderListModel.qml

@@ -0,0 +1,26 @@
+import QtQuick 2.2
+import QtQuick.Dialogs 1.1
+import Qt.labs.folderlistmodel 2.11
+
+Item {
+    width: 640
+    height: 480
+
+    ListView {
+        width: 200; height: 400
+
+        FolderListModel {
+            id: folderModel
+            folder: "assets:/frames/"
+            nameFilters: ["*.json"]
+        }
+
+        Component {
+            id: fileDelegate
+            Text { text: fileName }
+        }
+
+        model: folderModel
+        delegate: fileDelegate
+    }
+}

interface/resources/qml/controlsUit/SpinBox.qml

@@ -57,16 +57,23 @@ SpinBox {

     locale: Qt.locale("en_US")

-    onValueModified: realValue = value/factor
-    onValueChanged: realValue = value/factor
+    onValueModified: {
+        realValue = value / factor
+    }
+
+    onValueChanged: {
+        realValue = value / factor
+        spinBox.editingFinished();
+    }
+
     onRealValueChanged: {
-        var newValue = Math.round(realValue*factor);
+        var newValue = Math.round(realValue * factor);
         if(value != newValue) {
             value = newValue;
         }
     }

-    stepSize: realStepSize*factor
+    stepSize: realStepSize * factor
     to : realTo*factor
     from : realFrom*factor

@@ -90,11 +97,11 @@ SpinBox {
     }

     textFromValue: function(value, locale) {
-        return parseFloat(value/factor).toFixed(decimals);
+        return parseFloat(value / factor).toFixed(decimals);
     }

     valueFromText: function(text, locale) {
-        return Number.fromLocaleString(locale, text)*factor;
+        return Number.fromLocaleString(locale, text) * factor;
     }


@@ -102,7 +109,7 @@ SpinBox {
         id: spinboxText
         z: 2
         color: isLightColorScheme
-               ? (spinBox.activeFocus ? hifi.colors.black : hifi.colors.lightGray)
+               ? (spinBox.activeFocus ? hifi.colors.black : hifi.colors.faintGray)
                : (spinBox.activeFocus ? hifi.colors.white : hifi.colors.lightGrayText)
         selectedTextColor: hifi.colors.black
         selectionColor: hifi.colors.primaryHighlight
@@ -112,8 +119,6 @@ SpinBox {
         verticalAlignment: Qt.AlignVCenter
         leftPadding: spinBoxLabelInside.visible ? 30 : hifi.dimensions.textPadding
         width: spinBox.width - hifi.dimensions.spinnerSize
-        onEditingFinished: spinBox.editingFinished()
-
         Text {
             id: suffixText
             x: metrics.advanceWidth(spinboxText.text + '*')
@@ -125,7 +130,7 @@ SpinBox {
             }

             color: isLightColorScheme
-                   ? (spinBox.activeFocus ? hifi.colors.black : hifi.colors.lightGray)
+                   ? (spinBox.activeFocus ? hifi.colors.black : hifi.colors.faintGray)
                    : (spinBox.activeFocus ? hifi.colors.white : hifi.colors.lightGrayText)
             text: suffix
             verticalAlignment: Qt.AlignVCenter
@@ -170,6 +175,22 @@ SpinBox {
         }
     }

+    Keys.onPressed: {
+        if (event.key === Qt.Key_Return) {
+            if (!spinboxText.acceptableInput) {
+                var number = spinBox.valueFromText(spinboxText.text, spinBox.locale) / spinBox.factor
+
+                if (number < spinBox.minimumValue) {
+                    number = spinBox.minimumValue;
+                } else if (number > maximumValue) {
+                    number = spinBox.maximumValue;
+                }
+
+                spinboxText.text = spinBox.textFromValue(Math.round(number * factor), spinBox.locale)
+            }
+        }
+    }
+
     HifiControls.Label {
         id: spinBoxLabel
         text: spinBox.label

interface/resources/qml/dialogs/TabletLoginDialog.qml

@@ -14,6 +14,8 @@ import QtQuick 2.5
 import controlsUit 1.0 as HifiControlsUit
 import stylesUit 1.0 as HifiStylesUit

+import TabletScriptingInterface 1.0
+
 import "../LoginDialog"

 FocusScope {
@@ -25,10 +27,9 @@ FocusScope {
     width: parent.width
     height: parent.height

-    signal sendToScript(var message);
-    signal canceled();
+    property var tabletProxy: Tablet.getTablet("com.highfidelity.interface.tablet.system");

-    property bool isHMD: false
+    property bool isHMD: HMD.active
     property bool gotoPreviousApp: false;

     property bool keyboardEnabled: false
@@ -52,6 +53,7 @@ FocusScope {
     }

     function tryDestroy() {
+        tabletProxy.gotoHomeScreen();
     }

     MouseArea {
@@ -76,7 +78,7 @@ FocusScope {
         interval: 200

         onTriggered: {
-            if (MenuInterface.isOptionChecked("Use 3D Keyboard")) {
+            if (MenuInterface.isOptionChecked("Use 3D Keyboard") && root.isHMD) {
                 KeyboardScriptingInterface.raised = true;
             }
         }
@@ -95,7 +97,8 @@ FocusScope {
     Image {
         z: -10
         id: loginDialogBackground
-        source: "../LoginDialog/images/background_tablet.jpg"
+        fillMode: Image.PreserveAspectCrop
+        source: "../LoginDialog/images/background_tablet.png"
         anchors.fill: parent
     }

@@ -168,11 +171,13 @@ FocusScope {

     Component.onDestruction: {
         loginKeyboard.raised = false;
-        KeyboardScriptingInterface.raised = false;
+        if (root.isHMD) {
+            KeyboardScriptingInterface.raised = false;
+        }
     }

     Component.onCompleted: {
         keyboardTimer.start();
-        bodyLoader.setSource("../LoginDialog/LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "linkSteam": false });
+        bodyLoader.setSource("../LoginDialog/LinkAccountBody.qml", { "loginDialog": loginDialog, "root": root, "bodyLoader": bodyLoader, "linkSteam": false, "linkOculus": false });
     }
 }

interface/resources/qml/hifi/AssetServer.qml

@@ -148,7 +148,7 @@ Windows.ScrollingWindow {
     }

     function canAddToWorld(path) {
-        var supportedExtensions = [/\.fbx\b/i, /\.obj\b/i, /\.jpg\b/i, /\.png\b/i];
+        var supportedExtensions = [/\.fbx\b/i, /\.obj\b/i, /\.jpg\b/i, /\.png\b/i, /\.gltf\b/i];

         if (selectedItemCount > 1) {
             return false;

interface/resources/qml/hifi/AvatarApp.qml

@@ -254,6 +254,7 @@ Rectangle {
         onSaveClicked: function() {
             var avatarSettings = {
                 dominantHand : settings.dominantHandIsLeft ? 'left' : 'right',
+                hmdAvatarAlignmentType : settings.hmdAvatarAlignmentTypeIsEyes ? 'eyes' : 'head',
                 collisionsEnabled : settings.environmentCollisionsOn,
                 otherAvatarsCollisionsEnabled : settings.otherAvatarsCollisionsOn,
                 animGraphOverrideUrl : settings.avatarAnimationOverrideJSON,

interface/resources/qml/hifi/avatarapp/Settings.qml

@@ -37,6 +37,7 @@ Rectangle {
     property alias dominantHandIsLeft: leftHandRadioButton.checked
     property alias otherAvatarsCollisionsOn: otherAvatarsCollisionsEnabledRadiobutton.checked
     property alias environmentCollisionsOn: environmentCollisionsEnabledRadiobutton.checked
+    property alias hmdAvatarAlignmentTypeIsEyes: eyesRadioButton.checked
     property alias avatarAnimationOverrideJSON: avatarAnimationUrlInputText.text
     property alias avatarAnimationJSON: avatarAnimationUrlInputText.placeholderText
     property alias avatarCollisionSoundUrl: avatarCollisionSoundUrlInputText.text
@@ -65,6 +66,11 @@ Rectangle {
         } else {
             environmentCollisionsDisabledRadiobutton.checked = true;
         }
+        if (settings.hmdAvatarAlignmentType === 'eyes') {
+            eyesRadioButton.checked = true;
+        } else {
+            headRadioButton.checked = true;
+        }

         avatarAnimationJSON = settings.animGraphUrl;
         avatarAnimationOverrideJSON = settings.animGraphOverrideUrl;
@@ -210,7 +216,7 @@ Rectangle {
             anchors.left: parent.left
             anchors.right: parent.right

-            rows: 2
+            rows: 4
             rowSpacing: 25

             columns: 3
@@ -233,7 +239,7 @@ Rectangle {

                 Layout.row: 0
                 Layout.column: 1
-                Layout.leftMargin: -20
+                Layout.leftMargin: -15

                 ButtonGroup.group: leftRight
                 checked: true
@@ -249,7 +255,7 @@ Rectangle {
                 id: rightHandRadioButton

                 Layout.row: 0
-                Layout.column: 3
+                Layout.column: 2
                 Layout.rightMargin: -15

                 ButtonGroup.group: leftRight
@@ -260,7 +266,7 @@ Rectangle {
                 text: "Right"
                 boxSize: 20
             }
-
+
             HifiConstants {
                 id: hifi
             }
@@ -272,17 +278,17 @@ Rectangle {
                 Layout.column: 0
                 text: "Avatar to avatar collision"
             }
-
+
             ButtonGroup {
                 id: otherAvatarsOnOff
             }
-
+
             HifiControlsUit.RadioButton {
                 id: otherAvatarsCollisionsEnabledRadiobutton

                 Layout.row: 1
                 Layout.column: 1
-                Layout.leftMargin: -20
+                Layout.leftMargin: -15

                 ButtonGroup.group: otherAvatarsOnOff

@@ -297,7 +303,7 @@ Rectangle {
                 id: otherAvatarsCollisionsDisabledRadiobutton

                 Layout.row: 1
-                Layout.column: 3
+                Layout.column: 2
                 Layout.rightMargin: -15

                 ButtonGroup.group: otherAvatarsOnOff
@@ -320,13 +326,13 @@ Rectangle {
             ButtonGroup {
                 id: worldOnOff
             }
-
+
             HifiControlsUit.RadioButton {
                 id: environmentCollisionsEnabledRadiobutton

                 Layout.row: 2
                 Layout.column: 1
-                Layout.leftMargin: -20
+                Layout.leftMargin: -15

                 ButtonGroup.group: worldOnOff

@@ -341,7 +347,7 @@ Rectangle {
                 id: environmentCollisionsDisabledRadiobutton

                 Layout.row: 2
-                Layout.column: 3
+                Layout.column: 2
                 Layout.rightMargin: -15

                 ButtonGroup.group: worldOnOff
@@ -352,6 +358,52 @@ Rectangle {
                 text: "Off"
                 boxSize: 20
             }
+
+            // TextStyle9
+            RalewaySemiBold {
+                size: 17;
+                Layout.row: 3
+                Layout.column: 0
+                text: "HMD Alignment"
+            }
+
+            ButtonGroup {
+                id: headEyes
+            }
+
+            HifiControlsUit.RadioButton {
+                id: headRadioButton
+
+                Layout.row: 3
+                Layout.column: 1
+                Layout.leftMargin: -15
+
+                ButtonGroup.group: headEyes
+                checked: true
+
+                colorScheme: hifi.colorSchemes.light
+                fontSize: 17
+                letterSpacing: 1.4
+                text: "Head"
+                boxSize: 20
+            }
+
+            HifiControlsUit.RadioButton {
+                id: eyesRadioButton
+
+                Layout.row: 3
+                Layout.column: 2
+                Layout.rightMargin: -15
+
+                ButtonGroup.group: headEyes
+
+                colorScheme: hifi.colorSchemes.light
+                fontSize: 17
+                letterSpacing: 1.4
+                text: "Eyes"
+                boxSize: 20
+            }
+
         }

         ColumnLayout {

interface/resources/qml/hifi/dialogs/TabletAssetServer.qml

@@ -148,7 +148,7 @@ Rectangle {
     }

     function canAddToWorld(path) {
-        var supportedExtensions = [/\.fbx\b/i, /\.obj\b/i, /\.jpg\b/i, /\.png\b/i];
+        var supportedExtensions = [/\.fbx\b/i, /\.obj\b/i, /\.jpg\b/i, /\.png\b/i, /\.gltf\b/i];

         if (selectedItemCount > 1) {
             return false;

interface/resources/qml/hifi/tablet/OpenVrConfiguration.qml

@@ -70,7 +70,7 @@ Flickable {
             readonly property bool hmdDesktop: hmdInDesktop.checked

             property int state: buttonState.disabled
-            property var lastConfiguration: null
+            property var lastConfiguration:  null

             HifiConstants { id: hifi }

@@ -90,7 +90,6 @@ Flickable {
                 anchors.fill: parent
                 propagateComposedEvents: true
                 onPressed: {
-                    parent.forceActiveFocus()
                     mouse.accepted = false;
                 }
             }
@@ -169,9 +168,7 @@ Flickable {
                     boxRadius: 7
                     visible: viveInDesktop.checked

-                    anchors.top: viveInDesktop.bottom
                     anchors.topMargin: 5
-                    anchors.left: openVrConfiguration.left
                     anchors.leftMargin: leftMargin + 10

                     onClicked: {
@@ -214,13 +211,13 @@ Flickable {

                     onRealValueChanged: {
                         sendConfigurationSettings();
-                        openVrConfiguration.forceActiveFocus();
                     }
                 }


                 HifiControls.SpinBox {
                     id: headZOffset
+                    z: 10
                     width: 112
                     label: "Z Offset"
                     minimumValue: -50
@@ -232,7 +229,6 @@ Flickable {

                     onRealValueChanged: {
                         sendConfigurationSettings();
-                        openVrConfiguration.forceActiveFocus();
                     }
                 }
             }
@@ -326,7 +322,6 @@ Flickable {

                     onRealValueChanged: {
                         sendConfigurationSettings();
-                        openVrConfiguration.forceActiveFocus();
                     }
                 }

@@ -344,7 +339,6 @@ Flickable {

                     onRealValueChanged: {
                         sendConfigurationSettings();
-                        openVrConfiguration.forceActiveFocus();
                     }
                 }
             }
@@ -578,7 +572,6 @@ Flickable {

                     onRealValueChanged: {
                         sendConfigurationSettings();
-                        openVrConfiguration.forceActiveFocus();
                     }
                 }

@@ -596,7 +589,6 @@ Flickable {

                     onRealValueChanged: {
                         sendConfigurationSettings();
-                        openVrConfiguration.forceActiveFocus();
                     }
                 }
             }
@@ -747,8 +739,8 @@ Flickable {
             }

             Component.onCompleted: {
-                InputConfiguration.calibrationStatus.connect(calibrationStatusInfo);
                 lastConfiguration = composeConfigurationSettings();
+                InputConfiguration.calibrationStatus.connect(calibrationStatusInfo);
             }

             Component.onDestruction: {
@@ -777,7 +769,6 @@ Flickable {
                     calibrationTimer.interval = realValue * 1000;
                     openVrConfiguration.countDown = realValue;
                     numberAnimation.duration = calibrationTimer.interval;
-                    openVrConfiguration.forceActiveFocus();
                 }
             }

@@ -1048,6 +1039,9 @@ Flickable {
             }

             function updateButtonState() {
+                if (lastConfiguration === null) {
+                    lastConfiguration = composeConfigurationSettings();
+                }
                 var settings = composeConfigurationSettings();
                 var bodySetting = settings["bodyConfiguration"];
                 var headSetting = settings["headConfiguration"];

interface/src/Application.cpp

@@ -120,6 +120,7 @@
 #include <plugins/PluginManager.h>
 #include <plugins/PluginUtils.h>
 #include <plugins/SteamClientPlugin.h>
+#include <plugins/OculusPlatformPlugin.h>
 #include <plugins/InputConfiguration.h>
 #include <RecordingScriptingInterface.h>
 #include <render/EngineStats.h>
@@ -780,7 +781,6 @@ bool setupEssentials(int& argc, char** argv, bool runningMarkerExisted) {
     if (auto steamClient = pluginManager->getSteamClientPlugin()) {
         steamClient->init();
     }
-
     PROFILE_SET_THREAD_NAME("Main Thread");

 #if defined(Q_OS_WIN)
@@ -2387,7 +2387,6 @@ void Application::updateVerboseLogging() {
     bool enable = menu->isOptionChecked(MenuOption::VerboseLogging);

     QString rules =
-        "hifi.*.debug=%1\n"
         "hifi.*.info=%1\n"
         "hifi.audio-stream.debug=false\n"
         "hifi.audio-stream.info=false";
@@ -2706,6 +2705,7 @@ Application::~Application() {
     if (auto steamClient = PluginManager::getInstance()->getSteamClientPlugin()) {
         steamClient->shutdown();
     }
+
     DependencyManager::destroy<PluginManager>();

     DependencyManager::destroy<CompositorHelper>(); // must be destroyed before the FramebufferCache
@@ -3512,8 +3512,10 @@ void Application::resizeGL() {
         auto renderConfig = _graphicsEngine.getRenderEngine()->getConfiguration();
         assert(renderConfig);
         auto mainView = renderConfig->getConfig("RenderMainView.RenderDeferredTask");
-        assert(mainView);
-        mainView->setProperty("resolutionScale", renderResolutionScale);
+        // mainView can be null if we're rendering in forward mode
+        if (mainView) {
+            mainView->setProperty("resolutionScale", renderResolutionScale);
+        }
         displayPlugin->setRenderResolutionScale(renderResolutionScale);
     }

@@ -4039,6 +4041,19 @@ void Application::keyPressEvent(QKeyEvent* event) {
                 }
                 break;

+            case Qt::Key_G:
+                if (isShifted && isMeta && Menu::getInstance() && Menu::getInstance()->getMenu("Developer")->isVisible()) {
+                    static const QString HIFI_FRAMES_FOLDER_VAR = "HIFI_FRAMES_FOLDER";
+                    static const QString GPU_FRAME_FOLDER = QProcessEnvironment::systemEnvironment().contains(HIFI_FRAMES_FOLDER_VAR)
+                        ? QProcessEnvironment::systemEnvironment().value(HIFI_FRAMES_FOLDER_VAR)
+                        : "hifiFrames";
+                    static QString GPU_FRAME_TEMPLATE = GPU_FRAME_FOLDER + "/{DATE}_{TIME}";
+                    QString fullPath = FileUtils::computeDocumentPath(FileUtils::replaceDateTimeTokens(GPU_FRAME_TEMPLATE));
+                    if (FileUtils::canCreateFile(fullPath)) {
+                        getActiveDisplayPlugin()->captureFrame(fullPath.toStdString());
+                    }
+                }
+                break;
             case Qt::Key_X:
                 if (isShifted && isMeta) {
                     auto offscreenUi = getOffscreenUI();
@@ -4820,6 +4835,10 @@ void Application::idle() {
         steamClient->runCallbacks();
     }

+    if (auto oculusPlugin = PluginManager::getInstance()->getOculusPlatformPlugin()) {
+        oculusPlugin->handleOVREvents();
+    }
+
     float secondsSinceLastUpdate = (float)_lastTimeUpdated.nsecsElapsed() / NSECS_PER_MSEC / MSECS_PER_SECOND;
     _lastTimeUpdated.start();

@@ -5958,6 +5977,13 @@ void Application::update(float deltaTime) {

         auto userInputMapper = DependencyManager::get<UserInputMapper>();

+        controller::HmdAvatarAlignmentType hmdAvatarAlignmentType;
+        if (myAvatar->getHmdAvatarAlignmentType() == "eyes") {
+            hmdAvatarAlignmentType = controller::HmdAvatarAlignmentType::Eyes;
+        } else {
+            hmdAvatarAlignmentType = controller::HmdAvatarAlignmentType::Head;
+        }
+
         controller::InputCalibrationData calibrationData = {
             myAvatar->getSensorToWorldMatrix(),
             createMatFromQuatAndPos(myAvatar->getWorldOrientation(), myAvatar->getWorldPosition()),
@@ -5971,7 +5997,8 @@ void Application::update(float deltaTime) {
             myAvatar->getRightArmCalibrationMat(),
             myAvatar->getLeftArmCalibrationMat(),
             myAvatar->getRightHandCalibrationMat(),
-            myAvatar->getLeftHandCalibrationMat()
+            myAvatar->getLeftHandCalibrationMat(),
+            hmdAvatarAlignmentType
         };

         InputPluginPointer keyboardMousePlugin;
@@ -8131,7 +8158,18 @@ void Application::toggleLogDialog() {
         return;
     }
     if (! _logDialog) {
+
+        bool keepOnTop =_keepLogWindowOnTop.get();
+#ifdef Q_OS_WIN
+        _logDialog = new LogDialog(keepOnTop ? qApp->getWindow() : nullptr, getLogger());
+#else
         _logDialog = new LogDialog(nullptr, getLogger());
+
+        if (keepOnTop) {
+            Qt::WindowFlags flags = _logDialog->windowFlags() | Qt::Tool;
+            _logDialog->setWindowFlags(flags);
+        }
+#endif
     }

     if (_logDialog->isVisible()) {
@@ -8141,6 +8179,19 @@ void Application::toggleLogDialog() {
     }
 }

+ void Application::recreateLogWindow(int keepOnTop) {
+     _keepLogWindowOnTop.set(keepOnTop != 0);
+     if (_logDialog) {
+         bool toggle = _logDialog->isVisible();
+         _logDialog->close();
+         _logDialog = nullptr;
+
+         if (toggle) {
+             toggleLogDialog();
+         }
+     }
+ }
+
 void Application::toggleEntityScriptServerLogDialog() {
     if (! _entityScriptServerLogDialog) {
         _entityScriptServerLogDialog = new EntityScriptServerLogDialog(nullptr);

interface/src/Application.h

@@ -217,6 +217,8 @@ public:
     void setDesktopTabletScale(float desktopTabletScale);

     bool getDesktopTabletBecomesToolbarSetting() { return _desktopTabletBecomesToolbarSetting.get(); }
+    bool getLogWindowOnTopSetting() { return _keepLogWindowOnTop.get(); }
+    void setLogWindowOnTopSetting(bool keepOnTop) { _keepLogWindowOnTop.set(keepOnTop); }
     void setDesktopTabletBecomesToolbarSetting(bool value);
     bool getHmdTabletBecomesToolbarSetting() { return _hmdTabletBecomesToolbarSetting.get(); }
     void setHmdTabletBecomesToolbarSetting(bool value);
@@ -365,6 +367,7 @@ public slots:
     Q_INVOKABLE void loadDialog();
     Q_INVOKABLE void loadScriptURLDialog() const;
     void toggleLogDialog();
+    void recreateLogWindow(int);
     void toggleEntityScriptServerLogDialog();
     Q_INVOKABLE void showAssetServerWidget(QString filePath = "");
     Q_INVOKABLE void loadAddAvatarBookmarkDialog() const;
@@ -653,6 +656,7 @@ private:
     Setting::Handle<bool> _constrainToolbarPosition;
     Setting::Handle<QString> _preferredCursor;
     Setting::Handle<bool> _miniTabletEnabledSetting;
+    Setting::Handle<bool> _keepLogWindowOnTop { "keepLogWindowOnTop", false };

     float _scaleMirror;
     float _mirrorYawOffset;

interface/src/avatar/AvatarActionHold.cpp

@@ -288,39 +288,37 @@ void AvatarActionHold::doKinematicUpdate(float deltaTimeStep) {
             glm::vec3 oneFrameVelocity = (_positionalTarget - _previousPositionalTarget) / deltaTimeStep;

             _measuredLinearVelocities[_measuredLinearVelocitiesIndex++] = oneFrameVelocity;
-            if (_measuredLinearVelocitiesIndex >= AvatarActionHold::velocitySmoothFrames) {
-                _measuredLinearVelocitiesIndex = 0;
+            _measuredLinearVelocitiesIndex %= AvatarActionHold::velocitySmoothFrames;
+        }
+
+        if (_kinematicSetVelocity) {
+            glm::vec3 measuredLinearVelocity = _measuredLinearVelocities[0];
+            for (int i = 1; i < AvatarActionHold::velocitySmoothFrames; i++) {
+                // there is a bit of lag between when someone releases the trigger and when the software reacts to
+                // the release.  we calculate the velocity from previous frames but we don't include several
+                // of the most recent.
+                //
+                // if _measuredLinearVelocitiesIndex is
+                //     0 -- ignore i of 3 4 5
+                //     1 -- ignore i of 4 5 0
+                //     2 -- ignore i of 5 0 1
+                //     3 -- ignore i of 0 1 2
+                //     4 -- ignore i of 1 2 3
+                //     5 -- ignore i of 2 3 4
+
+                // This code is now disabled, but I'm leaving it commented-out because I suspect it will come back.
+                // if ((i + 1) % AvatarActionHold::velocitySmoothFrames == _measuredLinearVelocitiesIndex ||
+                //     (i + 2) % AvatarActionHold::velocitySmoothFrames == _measuredLinearVelocitiesIndex ||
+                //     (i + 3) % AvatarActionHold::velocitySmoothFrames == _measuredLinearVelocitiesIndex) {
+                //     continue;
+                // }
+
+                measuredLinearVelocity += _measuredLinearVelocities[i];
             }
-        }
-
-        glm::vec3 measuredLinearVelocity;
-        for (int i = 0; i < AvatarActionHold::velocitySmoothFrames; i++) {
-            // there is a bit of lag between when someone releases the trigger and when the software reacts to
-            // the release.  we calculate the velocity from previous frames but we don't include several
-            // of the most recent.
-            //
-            // if _measuredLinearVelocitiesIndex is
-            //     0 -- ignore i of 3 4 5
-            //     1 -- ignore i of 4 5 0
-            //     2 -- ignore i of 5 0 1
-            //     3 -- ignore i of 0 1 2
-            //     4 -- ignore i of 1 2 3
-            //     5 -- ignore i of 2 3 4
-
-            // This code is now disabled, but I'm leaving it commented-out because I suspect it will come back.
-            // if ((i + 1) % AvatarActionHold::velocitySmoothFrames == _measuredLinearVelocitiesIndex ||
-            //     (i + 2) % AvatarActionHold::velocitySmoothFrames == _measuredLinearVelocitiesIndex ||
-            //     (i + 3) % AvatarActionHold::velocitySmoothFrames == _measuredLinearVelocitiesIndex) {
-            //     continue;
-            // }
-
-            measuredLinearVelocity += _measuredLinearVelocities[i];
-        }
-        measuredLinearVelocity /= (float)(AvatarActionHold::velocitySmoothFrames
+            measuredLinearVelocity /= (float)(AvatarActionHold::velocitySmoothFrames
                                           // - 3  // 3 because of the 3 we skipped, above
                                           );

-        if (_kinematicSetVelocity) {
             rigidBody->setLinearVelocity(glmToBullet(measuredLinearVelocity));
             rigidBody->setAngularVelocity(glmToBullet(_angularVelocityTarget));
         }

interface/src/avatar/AvatarManager.cpp

@@ -270,7 +270,6 @@ void AvatarManager::updateOtherAvatars(float deltaTime) {
         if (avatar->getSkeletonModel()->isLoaded()) {
             // remove the orb if it is there
             avatar->removeOrb();
-            avatar->updateCollisionGroup(_myAvatar->getOtherAvatarsCollisionsEnabled());
             if (avatar->needsPhysicsUpdate()) {
                 _avatarsToChangeInPhysics.insert(avatar);
             }
@@ -376,7 +375,6 @@ void AvatarManager::simulateAvatarFades(float deltaTime) {
 }

 AvatarSharedPointer AvatarManager::newSharedAvatar(const QUuid& sessionUUID) {
-
     auto otherAvatar = new OtherAvatar(qApp->thread());
     otherAvatar->setSessionUUID(sessionUUID);
     auto nodeList = DependencyManager::get<NodeList>();
@@ -452,6 +450,7 @@ void AvatarManager::handleRemovedAvatar(const AvatarSharedPointer& removedAvatar
         _spaceProxiesToDelete.push_back(avatar->getSpaceIndex());
     }
     AvatarHashMap::handleRemovedAvatar(avatar, removalReason);
+    avatar->tearDownGrabs();

     avatar->die();
     queuePhysicsChange(avatar);

interface/src/avatar/AvatarMotionState.cpp

@@ -15,7 +15,6 @@
 #include <PhysicsEngine.h>
 #include <PhysicsHelpers.h>

-
 AvatarMotionState::AvatarMotionState(OtherAvatarPointer avatar, const btCollisionShape* shape) : ObjectMotionState(shape), _avatar(avatar) {
     assert(_avatar);
     _type = MOTIONSTATE_TYPE_AVATAR;
@@ -172,7 +171,10 @@ QUuid AvatarMotionState::getSimulatorID() const {
 // virtual
 void AvatarMotionState::computeCollisionGroupAndMask(int32_t& group, int32_t& mask) const {
     group = _collisionGroup;
-    mask = _collisionGroup == BULLET_COLLISION_GROUP_COLLISIONLESS ? 0 : Physics::getDefaultCollisionMask(group);
+    mask = Physics::getDefaultCollisionMask(group);
+    if (!_avatar->getCollideWithOtherAvatars()) {
+        mask &= ~(BULLET_COLLISION_GROUP_MY_AVATAR | BULLET_COLLISION_GROUP_OTHER_AVATAR);
+    }
 }

 // virtual

interface/src/avatar/MyAvatar.cpp

@@ -95,6 +95,37 @@ const float CENTIMETERS_PER_METER = 100.0f;

 const QString AVATAR_SETTINGS_GROUP_NAME { "Avatar" };

+static const QString USER_RECENTER_MODEL_FORCE_SIT = QStringLiteral("ForceSit");
+static const QString USER_RECENTER_MODEL_FORCE_STAND = QStringLiteral("ForceStand");
+static const QString USER_RECENTER_MODEL_AUTO = QStringLiteral("Auto");
+static const QString USER_RECENTER_MODEL_DISABLE_HMD_LEAN = QStringLiteral("DisableHMDLean");
+
+MyAvatar::SitStandModelType stringToUserRecenterModel(const QString& str) {
+    if (str == USER_RECENTER_MODEL_FORCE_SIT) {
+        return MyAvatar::ForceSit;
+    } else if (str == USER_RECENTER_MODEL_FORCE_STAND) {
+        return MyAvatar::ForceStand;
+    } else if (str == USER_RECENTER_MODEL_DISABLE_HMD_LEAN) {
+        return MyAvatar::DisableHMDLean;
+    } else {
+        return MyAvatar::Auto;
+    }
+}
+
+QString userRecenterModelToString(MyAvatar::SitStandModelType model) {
+    switch (model) {
+    case MyAvatar::ForceSit:
+        return USER_RECENTER_MODEL_FORCE_SIT;
+    case MyAvatar::ForceStand:
+        return USER_RECENTER_MODEL_FORCE_STAND;
+    case MyAvatar::DisableHMDLean:
+        return USER_RECENTER_MODEL_DISABLE_HMD_LEAN;
+    case MyAvatar::Auto:
+    default:
+        return USER_RECENTER_MODEL_AUTO;
+    }
+}
+
 MyAvatar::MyAvatar(QThread* thread) :
     Avatar(thread),
     _yawSpeed(YAW_SPEED_DEFAULT),
@@ -125,6 +156,7 @@ MyAvatar::MyAvatar(QThread* thread) :
     _prevShouldDrawHead(true),
     _audioListenerMode(FROM_HEAD),
     _dominantHandSetting(QStringList() << AVATAR_SETTINGS_GROUP_NAME << "dominantHand", DOMINANT_RIGHT_HAND),
+    _hmdAvatarAlignmentTypeSetting(QStringList() << AVATAR_SETTINGS_GROUP_NAME << "hmdAvatarAlignmentType", DEFAULT_HMD_AVATAR_ALIGNMENT_TYPE),
     _headPitchSetting(QStringList() << AVATAR_SETTINGS_GROUP_NAME << "", 0.0f),
     _scaleSetting(QStringList() << AVATAR_SETTINGS_GROUP_NAME << "scale", _targetScale),
     _yawSpeedSetting(QStringList() << AVATAR_SETTINGS_GROUP_NAME << "yawSpeed", _yawSpeed),
@@ -138,7 +170,8 @@ MyAvatar::MyAvatar(QThread* thread) :
     _useSnapTurnSetting(QStringList() << AVATAR_SETTINGS_GROUP_NAME << "useSnapTurn", _useSnapTurn),
     _userHeightSetting(QStringList() << AVATAR_SETTINGS_GROUP_NAME << "userHeight", DEFAULT_AVATAR_HEIGHT),
     _flyingHMDSetting(QStringList() << AVATAR_SETTINGS_GROUP_NAME << "flyingHMD", _flyingPrefHMD),
-    _avatarEntityCountSetting(QStringList() << AVATAR_SETTINGS_GROUP_NAME << "avatarEntityData" << "size", 0)
+    _avatarEntityCountSetting(QStringList() << AVATAR_SETTINGS_GROUP_NAME << "avatarEntityData" << "size", 0),
+    _userRecenterModelSetting(QStringList() << AVATAR_SETTINGS_GROUP_NAME << "userRecenterModel", USER_RECENTER_MODEL_AUTO)
 {
     _clientTraitsHandler.reset(new ClientTraitsHandler(this));

@@ -205,12 +238,12 @@ MyAvatar::MyAvatar(QThread* thread) :
             if (recordingInterface->getPlayFromCurrentLocation()) {
                 setRecordingBasis();
             }
-            _previousCollisionGroup = _characterController.computeCollisionGroup();
+            _previousCollisionMask = _characterController.computeCollisionMask();
             _characterController.setCollisionless(true);
         } else {
             clearRecordingBasis();
             useFullAvatarURL(_fullAvatarURLFromPreferences, _fullAvatarModelName);
-            if (_previousCollisionGroup != BULLET_COLLISION_GROUP_COLLISIONLESS) {
+            if (_previousCollisionMask != BULLET_COLLISION_MASK_COLLISIONLESS) {
                 _characterController.setCollisionless(false);
             }
         }
@@ -286,10 +319,25 @@ MyAvatar::~MyAvatar() {
     _myScriptEngine = nullptr;
 }

+QString MyAvatar::getDominantHand() const {
+    return _dominantHand.get();
+}
+
 void MyAvatar::setDominantHand(const QString& hand) {
     if (hand == DOMINANT_LEFT_HAND || hand == DOMINANT_RIGHT_HAND) {
-        _dominantHand = hand;
-        emit dominantHandChanged(_dominantHand);
+        _dominantHand.set(hand);
+        emit dominantHandChanged(hand);
+    }
+}
+
+QString MyAvatar::getHmdAvatarAlignmentType() const {
+    return _hmdAvatarAlignmentType.get();
+}
+
+void MyAvatar::setHmdAvatarAlignmentType(const QString& type) {
+    if (type != _hmdAvatarAlignmentType.get()) {
+        _hmdAvatarAlignmentType.set(type);
+        emit hmdAvatarAlignmentTypeChanged(type);
     }
 }

@@ -377,6 +425,7 @@ void MyAvatar::resetSensorsAndBody() {
     if (QThread::currentThread() != thread()) {
         QMetaObject::invokeMethod(this, "resetSensorsAndBody");
         return;
+
     }

     qApp->getActiveDisplayPlugin()->resetSensors();
@@ -817,7 +866,7 @@ void MyAvatar::simulate(float deltaTime, bool inView) {
     // and all of its joints, now update our attachements.
     Avatar::simulateAttachments(deltaTime);
     relayJointDataToChildren();
-    if (updateGrabs()) {
+    if (applyGrabChanges()) {
         _cauterizationNeedsUpdate = true;
     }

@@ -1277,7 +1326,8 @@ void MyAvatar::resizeAvatarEntitySettingHandles(uint32_t maxIndex) {
 }

 void MyAvatar::saveData() {
-    _dominantHandSetting.set(_dominantHand);
+    _dominantHandSetting.set(getDominantHand());
+    _hmdAvatarAlignmentTypeSetting.set(getHmdAvatarAlignmentType());
     _headPitchSetting.set(getHead()->getBasePitch());
     _scaleSetting.set(_targetScale);
     _yawSpeedSetting.set(_yawSpeed);
@@ -1300,6 +1350,7 @@ void MyAvatar::saveData() {
     _useSnapTurnSetting.set(_useSnapTurn);
     _userHeightSetting.set(getUserHeight());
     _flyingHMDSetting.set(getFlyingHMDPref());
+    _userRecenterModelSetting.set(userRecenterModelToString(getUserRecenterModel()));

     auto hmdInterface = DependencyManager::get<HMDScriptingInterface>();
     saveAvatarEntityDataToSettings();
@@ -1882,9 +1933,12 @@ void MyAvatar::loadData() {
     setCollisionSoundURL(_collisionSoundURLSetting.get(QUrl(DEFAULT_AVATAR_COLLISION_SOUND_URL)).toString());
     setSnapTurn(_useSnapTurnSetting.get());
     setDominantHand(_dominantHandSetting.get(DOMINANT_RIGHT_HAND).toLower());
+    setHmdAvatarAlignmentType(_hmdAvatarAlignmentTypeSetting.get(DEFAULT_HMD_AVATAR_ALIGNMENT_TYPE).toLower());
     setUserHeight(_userHeightSetting.get(DEFAULT_AVATAR_HEIGHT));
     setTargetScale(_scaleSetting.get());

+    setUserRecenterModel(stringToUserRecenterModel(_userRecenterModelSetting.get(USER_RECENTER_MODEL_AUTO)));
+
     setEnableMeshVisible(Menu::getInstance()->isOptionChecked(MenuOption::MeshVisible));
     _follow.setToggleHipsFollowing (Menu::getInstance()->isOptionChecked(MenuOption::ToggleHipsFollowing));
     setEnableDebugDrawBaseOfSupport(Menu::getInstance()->isOptionChecked(MenuOption::AnimDebugDrawBaseOfSupport));
@@ -2534,7 +2588,7 @@ void MyAvatar::updateMotors() {
     float verticalMotorTimescale;

     if (_characterController.getState() == CharacterController::State::Hover ||
-            _characterController.computeCollisionGroup() == BULLET_COLLISION_GROUP_COLLISIONLESS) {
+            _characterController.computeCollisionMask() == BULLET_COLLISION_MASK_COLLISIONLESS) {
         horizontalMotorTimescale = FLYING_MOTOR_TIMESCALE;
         verticalMotorTimescale = FLYING_MOTOR_TIMESCALE;
     } else {
@@ -2544,7 +2598,7 @@ void MyAvatar::updateMotors() {

     if (_motionBehaviors & AVATAR_MOTION_ACTION_MOTOR_ENABLED) {
         if (_characterController.getState() == CharacterController::State::Hover ||
-                _characterController.computeCollisionGroup() == BULLET_COLLISION_GROUP_COLLISIONLESS) {
+                _characterController.computeCollisionMask() == BULLET_COLLISION_MASK_COLLISIONLESS) {
             motorRotation = getMyHead()->getHeadOrientation();
         } else {
             // non-hovering = walking: follow camera twist about vertical but not lift
@@ -2599,7 +2653,7 @@ void MyAvatar::prepareForPhysicsSimulation() {
         qDebug() << "Warning: getParentVelocity failed" << getID();
         parentVelocity = glm::vec3();
     }
-    _characterController.handleChangedCollisionGroup();
+    _characterController.handleChangedCollisionMask();
     _characterController.setParentVelocity(parentVelocity);
     _characterController.setScaleFactor(getSensorToWorldScale());

@@ -3279,7 +3333,7 @@ void MyAvatar::updateOrientation(float deltaTime) {
         head->setBaseRoll(ROLL(euler));
     } else {
         head->setBaseYaw(0.0f);
-        head->setBasePitch(getHead()->getBasePitch() + getDriveKey(PITCH) * _pitchSpeed * deltaTime
+        head->setBasePitch(getHead()->getBasePitch() + getDriveKey(PITCH) * _pitchSpeed * deltaTime
             + getDriveKey(DELTA_PITCH) * _pitchSpeed / PITCH_SPEED_DEFAULT);
         head->setBaseRoll(0.0f);
     }
@@ -3325,7 +3379,7 @@ void MyAvatar::updateActionMotor(float deltaTime) {

     glm::vec3 direction = forward + right;
     if (state == CharacterController::State::Hover ||
-            _characterController.computeCollisionGroup() == BULLET_COLLISION_GROUP_COLLISIONLESS) {
+            _characterController.computeCollisionMask() == BULLET_COLLISION_MASK_COLLISIONLESS) {
         glm::vec3 up = (getDriveKey(TRANSLATE_Y)) * IDENTITY_UP;
         direction += up;
     }
@@ -3881,7 +3935,7 @@ void MyAvatar::setCollisionsEnabled(bool enabled) {
 bool MyAvatar::getCollisionsEnabled() {
     // may return 'false' even though the collisionless option was requested
     // because the zone may disallow collisionless avatars
-    return _characterController.computeCollisionGroup() != BULLET_COLLISION_GROUP_COLLISIONLESS;
+    return _characterController.computeCollisionMask() != BULLET_COLLISION_MASK_COLLISIONLESS;
 }

 void MyAvatar::setOtherAvatarsCollisionsEnabled(bool enabled) {
@@ -3890,7 +3944,11 @@ void MyAvatar::setOtherAvatarsCollisionsEnabled(bool enabled) {
         QMetaObject::invokeMethod(this, "setOtherAvatarsCollisionsEnabled", Q_ARG(bool, enabled));
         return;
     }
+    bool change = _collideWithOtherAvatars != enabled;
     _collideWithOtherAvatars = enabled;
+    if (change) {
+        setCollisionWithOtherAvatarsFlags();
+    }
     emit otherAvatarsCollisionsEnabledChanged(enabled);
 }

@@ -3898,6 +3956,11 @@ bool MyAvatar::getOtherAvatarsCollisionsEnabled() {
     return _collideWithOtherAvatars;
 }

+void MyAvatar::setCollisionWithOtherAvatarsFlags() {
+    _characterController.setCollideWithOtherAvatars(_collideWithOtherAvatars);
+    _characterController.setPendingFlagsUpdateCollisionMask();
+}
+
 void MyAvatar::updateCollisionCapsuleCache() {
     glm::vec3 start, end;
     float radius;
@@ -4752,7 +4815,7 @@ bool MyAvatar::FollowHelper::shouldActivateHorizontalCG(MyAvatar& myAvatar) cons
 }

 bool MyAvatar::FollowHelper::shouldActivateVertical(const MyAvatar& myAvatar, const glm::mat4& desiredBodyMatrix, const glm::mat4& currentBodyMatrix) const {
-    const float CYLINDER_TOP = 0.1f;
+    const float CYLINDER_TOP = 2.0f;
     const float CYLINDER_BOTTOM = -1.5f;
     const float SITTING_BOTTOM = -0.02f;

@@ -5310,7 +5373,7 @@ void MyAvatar::releaseGrab(const QUuid& grabID) {

     _avatarGrabsLock.withWriteLock([&] {
         if (_avatarGrabData.remove(grabID)) {
-            _deletedAvatarGrabs.insert(grabID);
+            _grabsToDelete.push_back(grabID);
             tellHandler = true;
         }
     });

interface/src/avatar/MyAvatar.h

@@ -252,6 +252,7 @@ class MyAvatar : public Avatar {

     const QString DOMINANT_LEFT_HAND = "left";
     const QString DOMINANT_RIGHT_HAND = "right";
+    const QString DEFAULT_HMD_AVATAR_ALIGNMENT_TYPE = "head";

     using Clock = std::chrono::system_clock;
     using TimePoint = Clock::time_point;
@@ -297,6 +298,8 @@ public:

     void reset(bool andRecenter = false, bool andReload = true, bool andHead = true);

+    void setCollisionWithOtherAvatarsFlags() override;
+
     /**jsdoc
      * @function MyAvatar.resetSensorsAndBody
      */
@@ -517,7 +520,18 @@ public:
      * @function MyAvatar.getDominantHand
      * @returns {string}
      */
-    Q_INVOKABLE QString getDominantHand() const { return _dominantHand; }
+    Q_INVOKABLE QString getDominantHand() const;
+
+    /**jsdoc
+     * @function MyAvatar.setHmdAvatarAlignmentType
+     * @param {string} hand
+     */
+    Q_INVOKABLE void setHmdAvatarAlignmentType(const QString& hand);
+    /**jsdoc
+     * @function MyAvatar.setHmdAvatarAlignmentType
+     * @returns {string}
+     */
+    Q_INVOKABLE QString getHmdAvatarAlignmentType() const;

     /**jsdoc
     * @function MyAvatar.setCenterOfGravityModelEnabled
@@ -1583,6 +1597,13 @@ signals:
      */
     void dominantHandChanged(const QString& hand);

+    /**jsdoc
+     * @function MyAvatar.hmdAvatarAlignmentTypeChanged
+     * @param {string} type
+     * @returns {Signal}
+     */
+    void hmdAvatarAlignmentTypeChanged(const QString& type);
+
     /**jsdoc
      * @function MyAvatar.sensorToWorldScaleChanged
      * @param {number} scale
@@ -1732,7 +1753,7 @@ private:
     SharedSoundPointer _collisionSound;

     MyCharacterController _characterController;
-    int32_t _previousCollisionGroup { BULLET_COLLISION_GROUP_MY_AVATAR };
+    int32_t _previousCollisionMask { BULLET_COLLISION_MASK_MY_AVATAR };

     AvatarWeakPointer _lookAtTargetAvatar;
     glm::vec3 _targetAvatarPosition;
@@ -1771,7 +1792,8 @@ private:
     ThreadSafeValueCache<QUrl> _prefOverrideAnimGraphUrl;
     QUrl _fstAnimGraphOverrideUrl;
     bool _useSnapTurn { true };
-    QString _dominantHand { DOMINANT_RIGHT_HAND };
+    ThreadSafeValueCache<QString> _dominantHand { DOMINANT_RIGHT_HAND };
+    ThreadSafeValueCache<QString> _hmdAvatarAlignmentType { DEFAULT_HMD_AVATAR_ALIGNMENT_TYPE };

     const float ROLL_CONTROL_DEAD_ZONE_DEFAULT = 8.0f; // degrees
     const float ROLL_CONTROL_RATE_DEFAULT = 114.0f; // degrees / sec
@@ -1944,6 +1966,7 @@ private:
     TimePoint _nextTraitsSendWindow;

     Setting::Handle<QString> _dominantHandSetting;
+    Setting::Handle<QString> _hmdAvatarAlignmentTypeSetting;
     Setting::Handle<float> _headPitchSetting;
     Setting::Handle<float> _scaleSetting;
     Setting::Handle<float> _yawSpeedSetting;
@@ -1960,6 +1983,7 @@ private:
     Setting::Handle<bool> _allowTeleportingSetting { "allowTeleporting", true };
     std::vector<Setting::Handle<QUuid>> _avatarEntityIDSettings;
     std::vector<Setting::Handle<QByteArray>> _avatarEntityDataSettings;
+    Setting::Handle<QString> _userRecenterModelSetting;

     // AvatarEntities stuff:
     // We cache the "map of unfortunately-formatted-binary-blobs" because they are expensive to compute

interface/src/avatar/MyCharacterController.cpp

@@ -202,6 +202,29 @@ bool MyCharacterController::testRayShotgun(const glm::vec3& position, const glm:
     return result.hitFraction < 1.0f;
 }

+int32_t MyCharacterController::computeCollisionMask() const {
+    int32_t collisionMask = BULLET_COLLISION_MASK_MY_AVATAR;
+    if (_collisionless && _collisionlessAllowed) {
+        collisionMask = BULLET_COLLISION_MASK_COLLISIONLESS;
+    } else if (!_collideWithOtherAvatars) {
+        collisionMask &= ~BULLET_COLLISION_GROUP_OTHER_AVATAR;
+    }
+    return collisionMask;
+}
+
+void MyCharacterController::handleChangedCollisionMask() {
+    if (_pendingFlags & PENDING_FLAG_UPDATE_COLLISION_MASK) {
+        // ATM the easiest way to update collision groups/masks is to remove/re-add the RigidBody
+        if (_dynamicsWorld) {
+            _dynamicsWorld->removeRigidBody(_rigidBody);
+            int32_t collisionMask = computeCollisionMask();
+            _dynamicsWorld->addRigidBody(_rigidBody, BULLET_COLLISION_GROUP_MY_AVATAR, collisionMask);
+        }
+        _pendingFlags &= ~PENDING_FLAG_UPDATE_COLLISION_MASK;
+        updateCurrentGravity();
+    }
+}
+
 btConvexHullShape* MyCharacterController::computeShape() const {
     // HACK: the avatar collides using convex hull with a collision margin equal to
     // the old capsule radius.  Two points define a capsule and additional points are

interface/src/avatar/MyCharacterController.h

@@ -42,6 +42,12 @@ public:

     void setDensity(btScalar density) { _density = density; }

+    int32_t computeCollisionMask() const override;
+    void handleChangedCollisionMask() override;
+
+    bool _collideWithOtherAvatars{ true };
+    void setCollideWithOtherAvatars(bool collideWithOtherAvatars) { _collideWithOtherAvatars = collideWithOtherAvatars; }
+
 protected:
     void initRayShotgun(const btCollisionWorld* world);
     void updateMassProperties() override;

interface/src/avatar/MySkeletonModel.cpp

@@ -187,7 +187,7 @@ void MySkeletonModel::updateRig(float deltaTime, glm::mat4 parentTransform) {
         }
     }

-    bool isFlying = (myAvatar->getCharacterController()->getState() == CharacterController::State::Hover || myAvatar->getCharacterController()->computeCollisionGroup() == BULLET_COLLISION_GROUP_COLLISIONLESS);
+    bool isFlying = (myAvatar->getCharacterController()->getState() == CharacterController::State::Hover || myAvatar->getCharacterController()->computeCollisionMask() == BULLET_COLLISION_MASK_COLLISIONLESS);
     if (isFlying != _prevIsFlying) {
         const float FLY_TO_IDLE_HIPS_TRANSITION_TIME = 0.5f;
         _flyIdleTimer = FLY_TO_IDLE_HIPS_TRANSITION_TIME;
@@ -198,7 +198,7 @@ void MySkeletonModel::updateRig(float deltaTime, glm::mat4 parentTransform) {

     // if hips are not under direct control, estimate the hips position.
     if (avatarHeadPose.isValid() && !(params.primaryControllerFlags[Rig::PrimaryControllerType_Hips] & (uint8_t)Rig::ControllerFlags::Enabled)) {
-        bool isFlying = (myAvatar->getCharacterController()->getState() == CharacterController::State::Hover || myAvatar->getCharacterController()->computeCollisionGroup() == BULLET_COLLISION_GROUP_COLLISIONLESS);
+        bool isFlying = (myAvatar->getCharacterController()->getState() == CharacterController::State::Hover || myAvatar->getCharacterController()->computeCollisionMask() == BULLET_COLLISION_MASK_COLLISIONLESS);

         // timescale in seconds
         const float TRANS_HORIZ_TIMESCALE = 0.15f;

interface/src/avatar/OtherAvatar.cpp

@@ -138,17 +138,9 @@ void OtherAvatar::rebuildCollisionShape() {
     }
 }

-void OtherAvatar::updateCollisionGroup(bool myAvatarCollide) {
+void OtherAvatar::setCollisionWithOtherAvatarsFlags() {
     if (_motionState) {
-        bool collides = _motionState->getCollisionGroup() == BULLET_COLLISION_GROUP_OTHER_AVATAR && myAvatarCollide;
-        if (_collideWithOtherAvatars != collides) {
-            if (!myAvatarCollide) {
-                _collideWithOtherAvatars = false;
-            }
-            auto newCollisionGroup = _collideWithOtherAvatars ? BULLET_COLLISION_GROUP_OTHER_AVATAR : BULLET_COLLISION_GROUP_COLLISIONLESS;
-            _motionState->setCollisionGroup(newCollisionGroup);
-            _motionState->addDirtyFlags(Simulation::DIRTY_COLLISION_GROUP);
-        }
+        _motionState->addDirtyFlags(Simulation::DIRTY_COLLISION_GROUP);
     }
 }

@@ -228,7 +220,7 @@ void OtherAvatar::simulate(float deltaTime, bool inView) {

     {
         PROFILE_RANGE(simulation, "grabs");
-        updateGrabs();
+        applyGrabChanges();
     }

     updateFadingStatus();

interface/src/avatar/OtherAvatar.h

@@ -44,7 +44,9 @@ public:
     bool shouldBeInPhysicsSimulation() const;
     bool needsPhysicsUpdate() const;

-    void updateCollisionGroup(bool myAvatarCollide);
+    bool getCollideWithOtherAvatars() const { return _collideWithOtherAvatars; }
+
+    void setCollisionWithOtherAvatarsFlags() override;

     void simulate(float deltaTime, bool inView) override;


interface/src/ui/BaseLogDialog.cpp

@@ -20,9 +20,9 @@
 #include <PathUtils.h>

 const int TOP_BAR_HEIGHT = 124;
-const int INITIAL_WIDTH = 720;
+const int INITIAL_WIDTH = 800;
 const int INITIAL_HEIGHT = 480;
-const int MINIMAL_WIDTH = 700;
+const int MINIMAL_WIDTH = 780;
 const int SEARCH_BUTTON_LEFT = 25;
 const int SEARCH_BUTTON_WIDTH = 20;
 const int SEARCH_TOGGLE_BUTTON_WIDTH = 50;

interface/src/ui/LogDialog.cpp

@@ -19,6 +19,9 @@

 #include <shared/AbstractLoggerInterface.h>

+#include "Application.h"
+#include "MainWindow.h"
+
 const int REVEAL_BUTTON_WIDTH = 122;
 const int ALL_LOGS_BUTTON_WIDTH = 90;
 const int MARGIN_LEFT = 25;
@@ -148,6 +151,16 @@ LogDialog::LogDialog(QWidget* parent, AbstractLoggerInterface* logger) : BaseLog
     _messageCount->setObjectName("messageCount");
     _messageCount->show();

+    _keepOnTopBox = new QCheckBox(" Keep window on top", this);
+    bool isOnTop = qApp-> getLogWindowOnTopSetting();
+    _keepOnTopBox->setCheckState(isOnTop ? Qt::Checked : Qt::Unchecked);
+#ifdef Q_OS_WIN
+    connect(_keepOnTopBox, &QCheckBox::stateChanged, qApp, &Application::recreateLogWindow);
+#else
+    connect(_keepOnTopBox, &QCheckBox::stateChanged, this, &LogDialog::handleKeepWindowOnTop);
+#endif
+    _keepOnTopBox->show();
+
     _extraDebuggingBox = new QCheckBox("Extra debugging", this);
     if (_logger->extraDebugging()) {
         _extraDebuggingBox->setCheckState(Qt::Checked);
@@ -183,6 +196,11 @@ void LogDialog::resizeEvent(QResizeEvent* event) {
         THIRD_ROW,
         COMBOBOX_WIDTH,
         ELEMENT_HEIGHT);
+
+     _keepOnTopBox->setGeometry(width() - ELEMENT_MARGIN - COMBOBOX_WIDTH - ELEMENT_MARGIN - ALL_LOGS_BUTTON_WIDTH - ELEMENT_MARGIN - COMBOBOX_WIDTH - ELEMENT_MARGIN,
+        THIRD_ROW,
+        COMBOBOX_WIDTH,
+        ELEMENT_HEIGHT);
     _messageCount->setGeometry(_leftPad,
         THIRD_ROW,
         COMBOBOX_WIDTH,
@@ -234,6 +252,23 @@ void LogDialog::handleInfoPrintBox(int state) {
     printLogFile();
 }

+void LogDialog::handleKeepWindowOnTop(int state) {
+    bool keepOnTop = (state != 0);
+
+    Qt::WindowFlags flags = windowFlags();
+
+    if (keepOnTop) {
+        flags |= Qt::Tool;
+    } else {
+        flags &= ~Qt::Tool;
+    }
+
+    setWindowFlags(flags);
+    qApp->setLogWindowOnTopSetting(keepOnTop);
+
+    show();
+}
+
 void LogDialog::handleCriticalPrintBox(int state) {
     _logger->setCriticalPrint(state != 0);
     printLogFile();

interface/src/ui/LogDialog.h

@@ -34,6 +34,7 @@ public slots:
 private slots:
     void handleRevealButton();
     void handleExtraDebuggingCheckbox(int);
+    void handleKeepWindowOnTop(int);
     void handleDebugPrintBox(int);
     void handleInfoPrintBox(int);
     void handleCriticalPrintBox(int);
@@ -55,6 +56,7 @@ protected:

 private:
     QCheckBox* _extraDebuggingBox;
+    QCheckBox* _keepOnTopBox;
     QPushButton* _revealLogButton;
     QPushButton* _allLogsButton;
     QCheckBox* _debugPrintBox;

interface/src/ui/LoginDialog.cpp

@@ -18,6 +18,7 @@

 #include <plugins/PluginManager.h>
 #include <plugins/SteamClientPlugin.h>
+#include <plugins/OculusPlatformPlugin.h>
 #include <shared/GlobalAppProperties.h>
 #include <ui/TabletScriptingInterface.h>
 #include <UserActivityLogger.h>
@@ -109,8 +110,16 @@ bool LoginDialog::isSteamRunning() const {
     return steamClient && steamClient->isRunning();
 }

-bool LoginDialog::isOculusStoreRunning() const {
-    return qApp->property(hifi::properties::OCULUS_STORE).toBool();
+bool LoginDialog::isOculusRunning() const {
+    auto oculusPlatformPlugin = PluginManager::getInstance()->getOculusPlatformPlugin();
+    return (oculusPlatformPlugin && oculusPlatformPlugin->isRunning());
+}
+
+QString LoginDialog::oculusUserID() const {
+    if (auto oculusPlatformPlugin = PluginManager::getInstance()->getOculusPlatformPlugin()) {
+        return oculusPlatformPlugin->getOculusUserID();
+    }
+    return "";
 }

 void LoginDialog::dismissLoginDialog() {
@@ -126,6 +135,79 @@ void LoginDialog::login(const QString& username, const QString& password) const
     DependencyManager::get<AccountManager>()->requestAccessToken(username, password);
 }

+void LoginDialog::loginThroughOculus() {
+   qDebug() << "Attempting to login through Oculus";
+    if (auto oculusPlatformPlugin = PluginManager::getInstance()->getOculusPlatformPlugin()) {
+       oculusPlatformPlugin->requestNonceAndUserID([this] (QString nonce, QString oculusID) {
+            DependencyManager::get<AccountManager>()->requestAccessTokenWithOculus(nonce, oculusID);
+        });
+    }
+}
+
+void LoginDialog::linkOculus() {
+    qDebug() << "Attempting to link Oculus account";
+    if (auto oculusPlatformPlugin = PluginManager::getInstance()->getOculusPlatformPlugin()) {
+        oculusPlatformPlugin->requestNonceAndUserID([this] (QString nonce, QString oculusID) {
+            if (nonce.isEmpty() || oculusID.isEmpty()) {
+                emit handleLoginFailed();
+                return;
+            }
+
+            JSONCallbackParameters callbackParams;
+            callbackParams.callbackReceiver = this;
+            callbackParams.jsonCallbackMethod = "linkCompleted";
+            callbackParams.errorCallbackMethod = "linkFailed";
+            const QString LINK_OCULUS_PATH = "api/v1/user/oculus/link";
+
+            QJsonObject payload;
+            payload["oculus_nonce"] = nonce;
+            payload["oculus_id"] = oculusID;
+
+            auto accountManager = DependencyManager::get<AccountManager>();
+            accountManager->sendRequest(LINK_OCULUS_PATH, AccountManagerAuth::Required,
+                                        QNetworkAccessManager::PostOperation, callbackParams,
+                                        QJsonDocument(payload).toJson());
+        });
+    }
+}
+
+void LoginDialog::createAccountFromOculus(QString email, QString username, QString password) {
+    qDebug() << "Attempting to create account from Oculus info";
+    if (auto oculusPlatformPlugin = PluginManager::getInstance()->getOculusPlatformPlugin()) {
+        oculusPlatformPlugin->requestNonceAndUserID([this, email, username, password] (QString nonce, QString oculusID) {
+            if (nonce.isEmpty() || oculusID.isEmpty()) {
+                emit handleLoginFailed();
+                return;
+            }
+
+            JSONCallbackParameters callbackParams;
+            callbackParams.callbackReceiver = this;
+            callbackParams.jsonCallbackMethod = "createCompleted";
+            callbackParams.errorCallbackMethod = "createFailed";
+
+            const QString CREATE_ACCOUNT_FROM_OCULUS_PATH = "api/v1/user/oculus/create";
+
+            QJsonObject payload;
+            payload["oculus_nonce"] = nonce;
+            payload["oculus_id"] = oculusID;
+            if (!email.isEmpty()) {
+                payload["email"] = email;
+            }
+            if (!username.isEmpty()) {
+                payload["username"] = username;
+            }
+            if (!password.isEmpty()) {
+                payload["password"] = password;
+            }
+
+            auto accountManager = DependencyManager::get<AccountManager>();
+            accountManager->sendRequest(CREATE_ACCOUNT_FROM_OCULUS_PATH, AccountManagerAuth::None,
+                                        QNetworkAccessManager::PostOperation, callbackParams,
+                                        QJsonDocument(payload).toJson());
+            });
+    }
+}
+
 void LoginDialog::loginThroughSteam() {
     qDebug() << "Attempting to login through Steam";
     if (auto steamClient = PluginManager::getInstance()->getSteamClientPlugin()) {
@@ -157,7 +239,7 @@ void LoginDialog::linkSteam() {
             const QString LINK_STEAM_PATH = "api/v1/user/steam/link";

             QJsonObject payload;
-            payload.insert("steam_auth_ticket", QJsonValue::fromVariant(QVariant(ticket)));
+            payload["steam_auth_ticket"] = QJsonValue::fromVariant(QVariant(ticket));

             auto accountManager = DependencyManager::get<AccountManager>();
             accountManager->sendRequest(LINK_STEAM_PATH, AccountManagerAuth::Required,
@@ -184,9 +266,9 @@ void LoginDialog::createAccountFromSteam(QString username) {
             const QString CREATE_ACCOUNT_FROM_STEAM_PATH = "api/v1/user/steam/create";

             QJsonObject payload;
-            payload.insert("steam_auth_ticket", QJsonValue::fromVariant(QVariant(ticket)));
+            payload["steam_auth_ticket"] = QJsonValue::fromVariant(QVariant(ticket));
             if (!username.isEmpty()) {
-                payload.insert("username", QJsonValue::fromVariant(QVariant(username)));
+                payload["username"] = username;
             }

             auto accountManager = DependencyManager::get<AccountManager>();
@@ -214,6 +296,45 @@ void LoginDialog::createCompleted(QNetworkReply* reply) {
 }

 void LoginDialog::createFailed(QNetworkReply* reply) {
+    if (isOculusRunning()) {
+        auto replyData = reply->readAll();
+        QJsonParseError parseError;
+        auto doc = QJsonDocument::fromJson(replyData, &parseError);
+        if (parseError.error != QJsonParseError::NoError) {
+            emit handleCreateFailed(reply->errorString());
+            return;
+        }
+        auto data = doc["data"];
+        auto error = data["error"];
+        auto oculusError = data["oculus"];
+        auto user = error["username"].toArray();
+        auto uid = error["uid"].toArray();
+        auto email = error["email"].toArray();
+        auto password = error["password"].toArray();
+        QString reply;
+        if (uid[0].isString()) {
+            emit handleCreateFailed("Oculus ID " + uid[0].toString() + ".");
+            return;
+        }
+        if (user[0].isString()) {
+            reply = "Username " + user[0].toString() + ".";
+        }
+        if (email[0].isString()) {
+            reply.append((!reply.isEmpty()) ? "\n" : "");
+            reply.append("Email " + email[0].toString() + ".");
+        }
+        if (password[0].isString()) {
+            reply.append((!reply.isEmpty()) ? "\n" : "");
+            reply.append("Password " + password[0].toString() + ".");
+        }
+        if (!oculusError.isNull() && !oculusError.isUndefined()) {
+            emit handleCreateFailed("Could not verify token with Oculus. Please try again.");
+            return;
+        } else {
+            emit handleCreateFailed(reply);
+            return;
+        }
+    }
     emit handleCreateFailed(reply->errorString());
 }


interface/src/ui/LoginDialog.h

@@ -22,7 +22,6 @@ extern const QUrl LOGIN_DIALOG;

 class LoginDialog : public OffscreenQmlDialog {
     Q_OBJECT
-    Q_PROPERTY(bool isLogIn READ getIsLogIn WRITE setIsLogIn)
     HIFI_QML_DECL

 public:
@@ -67,24 +66,23 @@ protected slots:
     Q_INVOKABLE void dismissLoginDialog();

     Q_INVOKABLE bool isSteamRunning() const;
-    Q_INVOKABLE bool isOculusStoreRunning() const;
+    Q_INVOKABLE bool isOculusRunning() const;
+
+    Q_INVOKABLE QString oculusUserID() const;

     Q_INVOKABLE void login(const QString& username, const QString& password) const;
     Q_INVOKABLE void loginThroughSteam();
     Q_INVOKABLE void linkSteam();
     Q_INVOKABLE void createAccountFromSteam(QString username = QString());
+    Q_INVOKABLE void loginThroughOculus();
+    Q_INVOKABLE void linkOculus();
+    Q_INVOKABLE void createAccountFromOculus(QString email = QString(), QString username = QString(), QString password = QString());

     Q_INVOKABLE void signup(const QString& email, const QString& username, const QString& password);

     Q_INVOKABLE void openUrl(const QString& url) const;

     Q_INVOKABLE bool getLoginDialogPoppedUp() const;
-
-private:
-    bool getIsLogIn() const { return _isLogIn; }
-    void setIsLogIn(const bool isLogIn) { _isLogIn = isLogIn; }
-
-    bool _isLogIn{ false };
 };

 #endif // hifi_LoginDialog_h

libraries/animation/src/AnimSkeleton.cpp

@@ -237,8 +237,17 @@ void AnimSkeleton::buildSkeletonFromJoints(const std::vector<HFMJoint>& joints,
     _relativeDefaultPoses = _absoluteDefaultPoses;
     convertAbsolutePosesToRelative(_relativeDefaultPoses);

+    // build _jointIndicesByName hash
     for (int i = 0; i < _jointsSize; i++) {
-        _jointIndicesByName[_joints[i].name] = i;
+        auto iter = _jointIndicesByName.find(_joints[i].name);
+        if (iter != _jointIndicesByName.end()) {
+            // prefer joints over meshes if there is a name collision.
+            if (_joints[i].isSkeletonJoint && !_joints[iter.value()].isSkeletonJoint) {
+                iter.value() = i;
+            }
+        } else {
+            _jointIndicesByName.insert(_joints[i].name, i);
+        }
     }

     // build mirror map.

libraries/avatars-renderer/src/avatars-renderer/Avatar.cpp

@@ -324,88 +324,79 @@ void Avatar::removeAvatarEntitiesFromTree() {
     }
 }

-bool Avatar::updateGrabs() {
+bool Avatar::applyGrabChanges() {
+    if (!_avatarGrabDataChanged && _grabsToChange.empty() && _grabsToDelete.empty()) {
+        // early exit for most common case: nothing to do
+        return false;
+    }
+
     bool grabAddedOrRemoved = false;
-    // update the Grabs according to any changes in _avatarGrabData
     _avatarGrabsLock.withWriteLock([&] {
         if (_avatarGrabDataChanged) {
+            // collect changes in _avatarGrabData
             foreach (auto grabID, _avatarGrabData.keys()) {
-                AvatarGrabMap::iterator grabItr = _avatarGrabs.find(grabID);
-                if (grabItr == _avatarGrabs.end()) {
+                MapOfGrabs::iterator itr = _avatarGrabs.find(grabID);
+                if (itr == _avatarGrabs.end()) {
                     GrabPointer grab = std::make_shared<Grab>();
                     grab->fromByteArray(_avatarGrabData.value(grabID));
                     _avatarGrabs[grabID] = grab;
-                    _changedAvatarGrabs.insert(grabID);
+                    _grabsToChange.insert(grabID);
                 } else {
-                    GrabPointer grab = grabItr.value();
-                    bool changed = grab->fromByteArray(_avatarGrabData.value(grabID));
+                    bool changed = itr->second->fromByteArray(_avatarGrabData.value(grabID));
                     if (changed) {
-                        _changedAvatarGrabs.insert(grabID);
+                        _grabsToChange.insert(grabID);
                     }
                 }
             }
             _avatarGrabDataChanged = false;
         }

-        auto treeRenderer = DependencyManager::get<EntityTreeRenderer>();
-        auto entityTree = treeRenderer ? treeRenderer->getTree() : nullptr;
-        EntityEditPacketSender* packetSender = treeRenderer ? treeRenderer->getPacketSender() : nullptr;
-        auto sessionID = DependencyManager::get<NodeList>()->getSessionUUID();
-
-        QMutableSetIterator<QUuid> delItr(_deletedAvatarGrabs);
-        while (delItr.hasNext()) {
-            QUuid grabID = delItr.next();
-            GrabPointer grab = _avatarGrabs[grabID];
-            if (!grab) {
-                delItr.remove();
+        // delete _avatarGrabs
+        VectorOfIDs undeleted;
+        for (const auto& id : _grabsToDelete) {
+            MapOfGrabs::iterator itr = _avatarGrabs.find(id);
+            if (itr == _avatarGrabs.end()) {
                 continue;
             }

             bool success;
+            const GrabPointer& grab = itr->second;
             SpatiallyNestablePointer target = SpatiallyNestable::findByID(grab->getTargetID(), success);
-
-            // only clear this entry from the _deletedAvatarGrabs if we found the entity.
             if (success && target) {
-                bool iShouldTellServer = target->getEditSenderID() == sessionID;
-
-                EntityItemPointer entity = std::dynamic_pointer_cast<EntityItem>(target);
-                if (entity && entity->isAvatarEntity() && (entity->getOwningAvatarID() == sessionID ||
-                                                           entity->getOwningAvatarID() == AVATAR_SELF_ID)) {
-                    // this is our own avatar-entity, so we always tell the server about the release
-                    iShouldTellServer = true;
-                }
-
                 target->removeGrab(grab);
-                delItr.remove();
-                // in case this is the last grab on an entity, we need to shrink the queryAACube and tell the server
-                // about the final position.
-                if (entityTree) {
-                    bool force = true;
-                    entityTree->withWriteLock([&] {
-                        entityTree->updateEntityQueryAACube(target, packetSender, force, iShouldTellServer);
-                    });
-                }
+                _avatarGrabs.erase(itr);
                 grabAddedOrRemoved = true;
+            } else {
+                undeleted.push_back(id);
             }
-            _avatarGrabs.remove(grabID);
-            _changedAvatarGrabs.remove(grabID);
         }
+        _grabsToDelete = std::move(undeleted);

-        QMutableSetIterator<QUuid> changeItr(_changedAvatarGrabs);
-        while (changeItr.hasNext()) {
-            QUuid grabID = changeItr.next();
-            GrabPointer& grab = _avatarGrabs[grabID];
+        // change _avatarGrabs and add Actions to target
+        SetOfIDs unchanged;
+        for (const auto& id : _grabsToChange) {
+            MapOfGrabs::iterator itr = _avatarGrabs.find(id);
+            if (itr == _avatarGrabs.end()) {
+                continue;
+            }

             bool success;
+            const GrabPointer& grab = itr->second;
             SpatiallyNestablePointer target = SpatiallyNestable::findByID(grab->getTargetID(), success);
-
             if (success && target) {
                 target->addGrab(grab);
-                // only clear this entry from the _changedAvatarGrabs if we found the entity.
-                changeItr.remove();
+                if (isMyAvatar()) {
+                    EntityItemPointer entity = std::dynamic_pointer_cast<EntityItem>(target);
+                    if (entity) {
+                        entity->upgradeScriptSimulationPriority(PERSONAL_SIMULATION_PRIORITY);
+                    }
+                }
                 grabAddedOrRemoved = true;
+            } else {
+                unchanged.insert(id);
             }
         }
+        _grabsToChange = std::move(unchanged);
     });
     return grabAddedOrRemoved;
 }
@@ -413,8 +404,8 @@ bool Avatar::updateGrabs() {
 void Avatar::accumulateGrabPositions(std::map<QUuid, GrabLocationAccumulator>& grabAccumulators) {
     // relay avatar's joint position to grabbed target in a way that allows for averaging
     _avatarGrabsLock.withReadLock([&] {
-        foreach (auto grabID, _avatarGrabs.keys()) {
-            const GrabPointer& grab = _avatarGrabs.value(grabID);
+        for (const auto& entry : _avatarGrabs) {
+            const GrabPointer& grab = entry.second;

             if (!grab || !grab->getActionID().isNull()) {
                 continue; // the accumulated value isn't used, in this case.
@@ -432,6 +423,20 @@ void Avatar::accumulateGrabPositions(std::map<QUuid, GrabLocationAccumulator>& g
     });
 }

+void Avatar::tearDownGrabs() {
+    _avatarGrabsLock.withWriteLock([&] {
+        for (const auto& entry : _avatarGrabs) {
+            _grabsToDelete.push_back(entry.first);
+        }
+        _grabsToChange.clear();
+    });
+    applyGrabChanges();
+    if (!_grabsToDelete.empty()) {
+        // some grabs failed to delete, which is a possible "leak", so we log about it
+        qWarning() << "Failed to tearDown" << _grabsToDelete.size() << "grabs for Avatar" << getID();
+    }
+}
+
 void Avatar::relayJointDataToChildren() {
     forEachChild([&](SpatiallyNestablePointer child) {
         if (child->getNestableType() == NestableType::Entity) {
@@ -1929,3 +1934,12 @@ scriptable::ScriptableModelBase Avatar::getScriptableModel() {
     }
     return result;
 }
+
+void Avatar::clearAvatarGrabData(const QUuid& id) {
+    AvatarData::clearAvatarGrabData(id);
+    _avatarGrabsLock.withWriteLock([&] {
+        if (_avatarGrabs.find(id) != _avatarGrabs.end()) {
+            _grabsToDelete.push_back(id);
+        }
+    });
+}

libraries/avatars-renderer/src/avatars-renderer/Avatar.h

@@ -14,6 +14,9 @@
 #include <functional>
 #include <glm/glm.hpp>
 #include <glm/gtc/quaternion.hpp>
+#include <map>
+#include <set>
+#include <vector>

 #include <QtCore/QUuid>

@@ -23,10 +26,12 @@
 #include <graphics-scripting/Forward.h>
 #include <GLMHelpers.h>

+#include <Grab.h>
+#include <ThreadSafeValueCache.h>
+
 #include "Head.h"
 #include "SkeletonModel.h"
 #include "Rig.h"
-#include <ThreadSafeValueCache.h>

 #include "MetaModelPayload.h"

@@ -436,6 +441,8 @@ public:

     void accumulateGrabPositions(std::map<QUuid, GrabLocationAccumulator>& grabAccumulators);

+    void tearDownGrabs();
+
 signals:
     void targetScaleChanged(float targetScale);

@@ -538,7 +545,7 @@ protected:

     // protected methods...
     bool isLookingAtMe(AvatarSharedPointer avatar) const;
-    bool updateGrabs();
+    bool applyGrabChanges();
     void relayJointDataToChildren();

     void fade(render::Transaction& transaction, render::Transition::Type type);
@@ -625,8 +632,15 @@ protected:

     static void metaBlendshapeOperator(render::ItemID renderItemID, int blendshapeNumber, const QVector<BlendshapeOffset>& blendshapeOffsets,
                                        const QVector<int>& blendedMeshSizes, const render::ItemIDs& subItemIDs);
+    void clearAvatarGrabData(const QUuid& grabID) override;

-    AvatarGrabMap _avatarGrabs;
+    using SetOfIDs = std::set<QUuid>;
+    using VectorOfIDs = std::vector<QUuid>;
+    using MapOfGrabs = std::map<QUuid, GrabPointer>;
+
+    MapOfGrabs _avatarGrabs;
+    SetOfIDs _grabsToChange; // updated grab IDs -- changes needed to entities or physics
+    VectorOfIDs _grabsToDelete; // deleted grab IDs -- changes needed to entities or physics
 };

 #endif // hifi_Avatar_h

libraries/avatars/src/AvatarData.cpp

@@ -639,7 +639,7 @@ QByteArray AvatarData::toByteArray(AvatarDataDetail dataDetail, quint64 lastSent

         // compute maxTranslationDimension before we send any joint data.
         float maxTranslationDimension = 0.001f;
-        for (int i = sendStatus.rotationsSent; i < numJoints; ++i) {
+        for (int i = sendStatus.translationsSent; i < numJoints; ++i) {
             const JointData& data = jointData[i];
             if (!data.translationIsDefaultPose) {
                 maxTranslationDimension = glm::max(fabsf(data.translation.x), maxTranslationDimension);
@@ -1172,6 +1172,9 @@ int AvatarData::parseDataFromBuffer(const QByteArray& buffer) {

         sourceBuffer += sizeof(AvatarDataPacket::AdditionalFlags);

+        if (collideWithOtherAvatarsChanged) {
+            setCollisionWithOtherAvatarsFlags();
+        }
         if (somethingChanged) {
             _additionalFlagsChanged = now;
         }
@@ -2428,7 +2431,8 @@ static const QString JSON_AVATAR_VERSION = QStringLiteral("version");
 enum class JsonAvatarFrameVersion : int {
     JointRotationsInRelativeFrame = 0,
     JointRotationsInAbsoluteFrame,
-    JointDefaultPoseBits
+    JointDefaultPoseBits,
+    JointUnscaledTranslations,
 };

 QJsonValue toJsonValue(const JointData& joint) {
@@ -2445,7 +2449,16 @@ JointData jointDataFromJsonValue(int version, const QJsonValue& json) {
     if (json.isArray()) {
         QJsonArray array = json.toArray();
         result.rotation = quatFromJsonValue(array[0]);
+
         result.translation = vec3FromJsonValue(array[1]);
+
+        // In old recordings, translations are scaled by _geometryOffset.  Undo that scaling.
+        if (version < (int)JsonAvatarFrameVersion::JointUnscaledTranslations) {
+            // because we don't have access to the actual _geometryOffset used. we have to guess.
+            // most avatar FBX files were authored in centimeters.
+            const float METERS_TO_CENTIMETERS = 100.0f;
+            result.translation *= METERS_TO_CENTIMETERS;
+        }
         if (version >= (int)JsonAvatarFrameVersion::JointDefaultPoseBits) {
             result.rotationIsDefaultPose = array[2].toBool();
             result.translationIsDefaultPose = array[3].toBool();
@@ -2464,7 +2477,7 @@ void AvatarData::avatarEntityDataToJson(QJsonObject& root) const {
 QJsonObject AvatarData::toJson() const {
     QJsonObject root;

-    root[JSON_AVATAR_VERSION] = (int)JsonAvatarFrameVersion::JointDefaultPoseBits;
+    root[JSON_AVATAR_VERSION] = (int)JsonAvatarFrameVersion::JointUnscaledTranslations;

     if (!getSkeletonModelURL().isEmpty()) {
         root[JSON_AVATAR_BODY_MODEL] = getSkeletonModelURL().toString();
@@ -2997,7 +3010,6 @@ void AvatarData::clearAvatarGrabData(const QUuid& grabID) {
     _avatarGrabsLock.withWriteLock([&] {
         if (_avatarGrabData.remove(grabID)) {
             _avatarGrabDataChanged = true;
-            _deletedAvatarGrabs.insert(grabID);
         }
     });
 }

libraries/avatars/src/AvatarData.h

@@ -54,7 +54,6 @@
 #include "AvatarTraits.h"
 #include "HeadData.h"
 #include "PathUtils.h"
-#include "Grab.h"

 #include <graphics/Material.h>

@@ -67,8 +66,6 @@ using PackedAvatarEntityMap = QMap<QUuid, QByteArray>; // similar to AvatarEntit
 using AvatarEntityIDs = QSet<QUuid>;

 using AvatarGrabDataMap = QMap<QUuid, QByteArray>;
-using AvatarGrabIDs = QSet<QUuid>;
-using AvatarGrabMap = QMap<QUuid, GrabPointer>;

 using AvatarDataSequenceNumber = uint16_t;

@@ -496,6 +493,8 @@ public:
     /// \return number of bytes parsed
     virtual int parseDataFromBuffer(const QByteArray& buffer);

+    virtual void setCollisionWithOtherAvatarsFlags() {};
+
     // Body Rotation (degrees)
     float getBodyYaw() const;
     void setBodyYaw(float bodyYaw);
@@ -1473,8 +1472,6 @@ protected:
     mutable ReadWriteLockable _avatarGrabsLock;
     AvatarGrabDataMap _avatarGrabData;
     bool _avatarGrabDataChanged { false }; // by network
-    AvatarGrabIDs _changedAvatarGrabs; // updated grab IDs -- changes needed to entities or physics
-    AvatarGrabIDs _deletedAvatarGrabs; // deleted grab IDs -- changes needed to entities or physics

     // used to transform any sensor into world space, including the _hmdSensorMat, or hand controllers.
     ThreadSafeValueCache<glm::mat4> _sensorToWorldMatrixCache { glm::mat4() };
@@ -1537,7 +1534,7 @@ protected:
     }

     bool updateAvatarGrabData(const QUuid& grabID, const QByteArray& grabData);
-    void clearAvatarGrabData(const QUuid& grabID);
+    virtual void clearAvatarGrabData(const QUuid& grabID);

 private:
     friend void avatarStateFromFrame(const QByteArray& frameData, AvatarData* _avatar);

libraries/controllers/src/controllers/Input.h

@@ -15,6 +15,11 @@

 namespace controller {

+enum class HmdAvatarAlignmentType {
+    Eyes = 0,  // align the user's eyes with the avatars eyes
+    Head       // align the user's head with the avatars head
+};
+
 struct InputCalibrationData {
     glm::mat4 sensorToWorldMat;    // sensor to world
     glm::mat4 avatarMat;           // avatar to world
@@ -29,6 +34,7 @@ struct InputCalibrationData {
     glm::mat4 defaultLeftArm;      // default pose for leftArm joint in sensor space
     glm::mat4 defaultRightHand;    // default pose for rightHand joint in sensor space
     glm::mat4 defaultLeftHand;     // default pose for leftHand joint in sensor space
+    HmdAvatarAlignmentType hmdAvatarAlignmentType;
 };

 enum class ChannelType {

libraries/display-plugins/src/display-plugins/Basic2DWindowOpenGLDisplayPlugin.h

@@ -31,6 +31,8 @@ public:

     virtual void compositeExtra() override;

+    virtual void pluginUpdate() override {};
+
 protected:
     mutable bool _isThrottled = false;


libraries/display-plugins/src/display-plugins/NullDisplayPlugin.h

@@ -20,6 +20,7 @@ public:
     QImage getScreenshot(float aspectRatio = 0.0f) const override;
     QImage getSecondaryCameraScreenshot() const override;
     void copyTextureToQuickFramebuffer(NetworkTexturePointer source, QOpenGLFramebufferObject* target, GLsync* fenceSync) override {};
+    void pluginUpdate() override {};
 private:
     static const QString NAME;
 };

libraries/display-plugins/src/display-plugins/OpenGLDisplayPlugin.cpp

@@ -15,8 +15,10 @@
 #include <QtCore/QCoreApplication>
 #include <QtCore/QThread>
 #include <QtCore/QTimer>
+#include <QtCore/QFileInfo>

 #include <QtGui/QImage>
+#include <QtGui/QImageWriter>
 #include <QtGui/QOpenGLFramebufferObject>

 #include <NumericalConstants.h>
@@ -30,6 +32,7 @@
 #include <gl/OffscreenGLCanvas.h>

 #include <gpu/Texture.h>
+#include <gpu/FrameIO.h>
 #include <shaders/Shaders.h>
 #include <gpu/gl/GLShared.h>
 #include <gpu/gl/GLBackend.h>
@@ -465,11 +468,43 @@ void OpenGLDisplayPlugin::submitFrame(const gpu::FramePointer& newFrame) {
     });
 }

-void OpenGLDisplayPlugin::renderFromTexture(gpu::Batch& batch, const gpu::TexturePointer texture, glm::ivec4 viewport, const glm::ivec4 scissor) {
-    renderFromTexture(batch, texture, viewport, scissor, gpu::FramebufferPointer());
+void OpenGLDisplayPlugin::captureFrame(const std::string& filename) const {
+    withOtherThreadContext([&] {
+        using namespace gpu;
+        auto glBackend = const_cast<OpenGLDisplayPlugin&>(*this).getGLBackend();
+        FramebufferPointer framebuffer{ Framebuffer::create("captureFramebuffer") };
+        TextureCapturer captureLambda = [&](const std::string& filename, const gpu::TexturePointer& texture, uint16 layer) {
+            QImage image;
+            if (texture->getUsageType() == TextureUsageType::STRICT_RESOURCE) {
+                image = QImage{ 1, 1, QImage::Format_ARGB32 };
+                auto storedImage = texture->accessStoredMipFace(0, 0);
+                memcpy(image.bits(), storedImage->data(), image.sizeInBytes());
+            //if (texture == textureCache->getWhiteTexture()) {
+            //} else if (texture == textureCache->getBlackTexture()) {
+            //} else if (texture == textureCache->getBlueTexture()) {
+            //} else if (texture == textureCache->getGrayTexture()) {
+            } else {
+                ivec4 rect = { 0, 0, texture->getWidth(), texture->getHeight() };
+                framebuffer->setRenderBuffer(0, texture, layer);
+                glBackend->syncGPUObject(*framebuffer);
+
+                image = QImage{ rect.z, rect.w, QImage::Format_ARGB32 };
+                glBackend->downloadFramebuffer(framebuffer, rect, image);
+            }
+            QImageWriter(filename.c_str()).write(image);
+        };
+
+        if (_currentFrame) {
+            gpu::writeFrame(filename, _currentFrame, captureLambda);
+        }
+    });
 }

-void OpenGLDisplayPlugin::renderFromTexture(gpu::Batch& batch, const gpu::TexturePointer texture, glm::ivec4 viewport, const glm::ivec4 scissor, gpu::FramebufferPointer copyFbo /*=gpu::FramebufferPointer()*/) {
+void OpenGLDisplayPlugin::renderFromTexture(gpu::Batch& batch, const gpu::TexturePointer& texture, const glm::ivec4& viewport, const glm::ivec4& scissor) {
+    renderFromTexture(batch, texture, viewport, scissor, nullptr);
+}
+
+void OpenGLDisplayPlugin::renderFromTexture(gpu::Batch& batch, const gpu::TexturePointer& texture, const glm::ivec4& viewport, const glm::ivec4& scissor, const gpu::FramebufferPointer& copyFbo /*=gpu::FramebufferPointer()*/) {
     auto fbo = gpu::FramebufferPointer();
     batch.enableStereo(false);
     batch.resetViewTransform();

libraries/display-plugins/src/display-plugins/OpenGLDisplayPlugin.h

@@ -47,7 +47,7 @@ public:
     void endSession() override final;
     bool eventFilter(QObject* receiver, QEvent* event) override;
     bool isDisplayVisible() const override { return true; }
-
+    void captureFrame(const std::string& outputName) const override;
     void submitFrame(const gpu::FramePointer& newFrame) override;

     glm::uvec2 getRecommendedRenderSize() const override {
@@ -113,8 +113,8 @@ protected:
     // Plugin specific functionality to send the composed scene to the output window or device
     virtual void internalPresent();

-    void renderFromTexture(gpu::Batch& batch, const gpu::TexturePointer texture, glm::ivec4 viewport, const glm::ivec4 scissor, gpu::FramebufferPointer fbo);
-    void renderFromTexture(gpu::Batch& batch, const gpu::TexturePointer texture, glm::ivec4 viewport, const glm::ivec4 scissor);
+    void renderFromTexture(gpu::Batch& batch, const gpu::TexturePointer& texture, const glm::ivec4& viewport, const glm::ivec4& scissor, const gpu::FramebufferPointer& fbo);
+    void renderFromTexture(gpu::Batch& batch, const gpu::TexturePointer& texture, const glm::ivec4& viewport, const glm::ivec4& scissor);
     virtual void updateFrameData();
     virtual glm::mat4 getViewCorrection() { return glm::mat4(); }


libraries/display-plugins/src/display-plugins/hmd/DebugHmdDisplayPlugin.cpp

@@ -69,7 +69,10 @@ bool DebugHmdDisplayPlugin::internalActivate() {
     _eyeInverseProjections[1] = glm::inverse(_eyeProjections[1]);
     _eyeOffsets[0][3] = vec4{ -0.0327499993, 0.0, -0.0149999997, 1.0 };
     _eyeOffsets[1][3] = vec4{ 0.0327499993, 0.0, -0.0149999997, 1.0 };
-    _renderTargetSize = { 3024, 1680 };
+    // Test HMD per-eye resolution
+    _renderTargetSize = uvec2{ 1214 * 2 , 1344 };
+    // uncomment to capture a quarter size frame
+    //_renderTargetSize /= 2;
     _cullingProjection = _eyeProjections[0];
     // This must come after the initialization, so that the values calculated
     // above are available during the customizeContext call (when not running

libraries/display-plugins/src/display-plugins/hmd/HmdDisplayPlugin.h

@@ -46,6 +46,8 @@ public:

     virtual bool onDisplayTextureReset() override { _clearPreviewFlag = true; return true; };

+    void pluginUpdate() override {};
+
 signals:
     void hmdMountedChanged();
     void hmdVisibleChanged(bool visible);

libraries/display-plugins/src/display-plugins/stereo/StereoDisplayPlugin.h

@@ -28,6 +28,8 @@ public:
     // to the HMD plugins.
     //virtual glm::mat4 getEyeToHeadTransform(Eye eye) const override;

+    virtual void pluginUpdate() override {};
+
 protected:
     virtual bool internalActivate() override;
     virtual void internalDeactivate() override;

libraries/entities-renderer/src/RenderableEntityItem.cpp

@@ -141,7 +141,7 @@ std::shared_ptr<T> make_renderer(const EntityItemPointer& entity) {
     return std::shared_ptr<T>(new T(entity), [](T* ptr) { ptr->deleteLater(); });
 }

-EntityRenderer::EntityRenderer(const EntityItemPointer& entity) : _entity(entity), _created(entity->getCreated()) {
+EntityRenderer::EntityRenderer(const EntityItemPointer& entity) : _created(entity->getCreated()), _entity(entity) {
     connect(entity.get(), &EntityItem::requestRenderUpdate, this, [&] {
         _needsRenderUpdate = true;
         emit requestRenderUpdate();
@@ -479,7 +479,7 @@ glm::vec4 EntityRenderer::calculatePulseColor(const glm::vec4& color, const Puls
     }

     float t = ((float)(usecTimestampNow() - start)) / ((float)USECS_PER_SECOND);
-    float pulse = 0.5f * (glm::cos(t * (2.0f * M_PI) / pulseProperties.getPeriod()) + 1.0f) * (pulseProperties.getMax() - pulseProperties.getMin()) + pulseProperties.getMin();
+    float pulse = 0.5f * (cosf(t * (2.0f * (float)M_PI) / pulseProperties.getPeriod()) + 1.0f) * (pulseProperties.getMax() - pulseProperties.getMin()) + pulseProperties.getMin();
     float outPulse = (1.0f - pulse);

     glm::vec4 result = color;

libraries/entities-renderer/src/RenderableGizmoEntityItem.cpp

@@ -286,4 +286,4 @@ void GizmoEntityRenderer::doRender(RenderArgs* args) {
             }
         }
     }
-}
+}

libraries/entities-renderer/src/RenderableShapeEntityItem.cpp

@@ -42,10 +42,23 @@ ShapeEntityRenderer::ShapeEntityRenderer(const EntityItemPointer& entity) : Pare
     // TODO: move into Procedural.cpp
     PrepareStencil::testMaskDrawShape(*_procedural._opaqueState);
     PrepareStencil::testMask(*_procedural._transparentState);
+
+    addMaterial(graphics::MaterialLayer(_material, 0), "0");
 }

 bool ShapeEntityRenderer::needsRenderUpdate() const {
-    if (_procedural.isEnabled() && _procedural.isFading()) {
+    if (resultWithReadLock<bool>([&] {
+        if (_procedural.isEnabled() && _procedural.isFading()) {
+            return true;
+        }
+
+        auto mat = _materials.find("0");
+        if (mat != _materials.end() && mat->second.needsUpdate()) {
+            return true;
+        }
+
+        return false;
+    })) {
         return true;
     }

@@ -56,7 +69,11 @@ bool ShapeEntityRenderer::needsRenderUpdateFromTypedEntity(const TypedEntityPoin
     if (_lastUserData != entity->getUserData()) {
         return true;
     }
-    if (_material != entity->getMaterial()) {
+
+    if (_color != entity->getColor()) {
+        return true;
+    }
+    if (_alpha != entity->getAlpha()) {
         return true;
     }

@@ -83,10 +100,6 @@ void ShapeEntityRenderer::doRenderUpdateSynchronousTyped(const ScenePointer& sce
             _procedural.setProceduralData(ProceduralData::parse(_lastUserData));
         }

-        removeMaterial(_material, "0");
-        _material = entity->getMaterial();
-        addMaterial(graphics::MaterialLayer(_material, 0), "0");
-
         _shape = entity->getShape();
         _pulseProperties = entity->getPulseProperties();
     });
@@ -116,6 +129,20 @@ void ShapeEntityRenderer::doRenderUpdateAsynchronousTyped(const TypedEntityPoint
             _procedural.setIsFading(isFading);
         }
     });
+
+    glm::u8vec3 color = entity->getColor();
+    float alpha = entity->getAlpha();
+    if (_color != color || _alpha != alpha) {
+        _color = color;
+        _alpha = alpha;
+        _material->setAlbedo(toGlm(_color));
+        _material->setOpacity(_alpha);
+
+        auto materials = _materials.find("0");
+        if (materials != _materials.end()) {
+            materials->second.setNeedsUpdate(true);
+        }
+    }
 }

 bool ShapeEntityRenderer::isTransparent() const {
@@ -129,18 +156,15 @@ bool ShapeEntityRenderer::isTransparent() const {

     auto mat = _materials.find("0");
     if (mat != _materials.end()) {
-        if (mat->second.top().material) {
-            auto matKey = mat->second.top().material->getKey();
-            if (matKey.isTranslucent()) {
-                return true;
-            }
+        if (mat->second.getMaterialKey().isTranslucent()) {
+            return true;
         }
     }

     return Parent::isTransparent();
 }

-bool ShapeEntityRenderer::useMaterialPipeline() const {
+bool ShapeEntityRenderer::useMaterialPipeline(const graphics::MultiMaterial& materials) const {
     bool proceduralReady = resultWithReadLock<bool>([&] {
         return _procedural.isReady();
     });
@@ -148,12 +172,7 @@ bool ShapeEntityRenderer::useMaterialPipeline() const {
         return false;
     }

-    graphics::MaterialKey drawMaterialKey;
-    auto mat = _materials.find("0");
-    if (mat != _materials.end() && mat->second.top().material) {
-        drawMaterialKey = mat->second.top().material->getKey();
-    }
-
+    graphics::MaterialKey drawMaterialKey = materials.getMaterialKey();
     if (drawMaterialKey.isEmissive() || drawMaterialKey.isUnlit() || drawMaterialKey.isMetallic() || drawMaterialKey.isScattering()) {
         return true;
     }
@@ -168,11 +187,13 @@ bool ShapeEntityRenderer::useMaterialPipeline() const {
 }

 ShapeKey ShapeEntityRenderer::getShapeKey() {
-    if (useMaterialPipeline()) {
-        graphics::MaterialKey drawMaterialKey;
-        if (_materials["0"].top().material) {
-            drawMaterialKey = _materials["0"].top().material->getKey();
-        }
+    auto mat = _materials.find("0");
+    if (mat != _materials.end() && mat->second.needsUpdate()) {
+        RenderPipelines::updateMultiMaterial(mat->second);
+    }
+
+    if (mat != _materials.end() && useMaterialPipeline(mat->second)) {
+        graphics::MaterialKey drawMaterialKey = mat->second.getMaterialKey();

         bool isTranslucent = drawMaterialKey.isTranslucent();
         bool hasTangents = drawMaterialKey.isNormalMap();
@@ -225,7 +246,7 @@ void ShapeEntityRenderer::doRender(RenderArgs* args) {

     gpu::Batch& batch = *args->_batch;

-    std::shared_ptr<graphics::Material> mat;
+    graphics::MultiMaterial materials;
     auto geometryCache = DependencyManager::get<GeometryCache>();
     GeometryCache::Shape geometryShape;
     bool proceduralRender = false;
@@ -233,30 +254,25 @@ void ShapeEntityRenderer::doRender(RenderArgs* args) {
     withReadLock([&] {
         geometryShape = geometryCache->getShapeForEntityShape(_shape);
         batch.setModelTransform(_renderTransform); // use a transform with scale, rotation, registration point and translation
-        mat = _materials["0"].top().material;
-        if (mat) {
-            outColor = glm::vec4(mat->getAlbedo(), mat->getOpacity());
-            outColor = EntityRenderer::calculatePulseColor(outColor, _pulseProperties, _created);
-            if (_procedural.isReady()) {
-                outColor = _procedural.getColor(outColor);
-                outColor.a *= _procedural.isFading() ? Interpolate::calculateFadeRatio(_procedural.getFadeStartTime()) : 1.0f;
-                _procedural.prepare(batch, _position, _dimensions, _orientation, ProceduralProgramKey(outColor.a < 1.0f));
-                proceduralRender = true;
-            }
+        materials = _materials["0"];
+        auto& schema = materials.getSchemaBuffer().get<graphics::MultiMaterial::Schema>();
+        outColor = glm::vec4(schema._albedo, schema._opacity);
+        outColor = EntityRenderer::calculatePulseColor(outColor, _pulseProperties, _created);
+        if (_procedural.isReady()) {
+            outColor = _procedural.getColor(outColor);
+            outColor.a *= _procedural.isFading() ? Interpolate::calculateFadeRatio(_procedural.getFadeStartTime()) : 1.0f;
+            _procedural.prepare(batch, _position, _dimensions, _orientation, ProceduralProgramKey(outColor.a < 1.0f));
+            proceduralRender = true;
         }
     });

-    if (!mat) {
-        return;
-    }
-
     if (proceduralRender) {
         if (render::ShapeKey(args->_globalShapeKey).isWireframe()) {
             geometryCache->renderWireShape(batch, geometryShape, outColor);
         } else {
             geometryCache->renderShape(batch, geometryShape, outColor);
         }
-    } else if (!useMaterialPipeline()) {
+    } else if (!useMaterialPipeline(materials)) {
         // FIXME, support instanced multi-shape rendering using multidraw indirect
         outColor.a *= _isFading ? Interpolate::calculateFadeRatio(_fadeStartTime) : 1.0f;
         render::ShapePipelinePointer pipeline;
@@ -272,7 +288,7 @@ void ShapeEntityRenderer::doRender(RenderArgs* args) {
         }
     } else {
         if (args->_renderMode != render::Args::RenderMode::SHADOW_RENDER_MODE) {
-            RenderPipelines::bindMaterial(mat, batch, args->_enableTexturing);
+            RenderPipelines::bindMaterials(materials, batch, args->_enableTexturing);
             args->_details._materialSwitches++;
         }

@@ -291,8 +307,9 @@ scriptable::ScriptableModelBase ShapeEntityRenderer::getScriptableModel()  {
     {
         std::lock_guard<std::mutex> lock(_materialsLock);
         result.appendMaterials(_materials);
-        if (_materials["0"].top().material) {
-            vertexColor = _materials["0"].top().material->getAlbedo();
+        auto materials = _materials.find("0");
+        if (materials != _materials.end()) {
+            vertexColor = materials->second.getSchemaBuffer().get<graphics::MultiMaterial::Schema>()._albedo;
         }
     }
     if (auto mesh = geometryCache->meshFromShape(geometryShape, vertexColor)) {

libraries/entities-renderer/src/RenderableShapeEntityItem.h

@@ -35,13 +35,17 @@ private:
     virtual void doRender(RenderArgs* args) override;
     virtual bool isTransparent() const override;

-    bool useMaterialPipeline() const;
+    bool useMaterialPipeline(const graphics::MultiMaterial& materials) const;

     Procedural _procedural;
     QString _lastUserData;
     entity::Shape _shape { entity::Sphere };
+
     PulsePropertyGroup _pulseProperties;
-    std::shared_ptr<graphics::Material> _material;
+    std::shared_ptr<graphics::Material> _material { std::make_shared<graphics::Material>() };
+    glm::u8vec3 _color;
+    float _alpha;
+
     glm::vec3 _position;
     glm::vec3 _dimensions;
     glm::quat _orientation;

libraries/entities/src/EntityItem.cpp

@@ -3425,7 +3425,19 @@ void EntityItem::addGrab(GrabPointer grab) {
     enableNoBootstrap();
     SpatiallyNestable::addGrab(grab);

-    if (getDynamic() && getParentID().isNull()) {
+    if (!getParentID().isNull()) {
+        return;
+    }
+
+    int jointIndex = grab->getParentJointIndex();
+    bool isFarGrab = jointIndex == FARGRAB_RIGHTHAND_INDEX
+        || jointIndex == FARGRAB_LEFTHAND_INDEX
+        || jointIndex == FARGRAB_MOUSE_INDEX;
+
+    // GRAB HACK: FarGrab doesn't work on non-dynamic things yet, but we really really want NearGrab
+    // (aka Hold) to work for such ojects, hence we filter the useAction case like so:
+    bool useAction = getDynamic() || (_physicsInfo && !isFarGrab);
+    if (useAction) {
         EntityTreePointer entityTree = getTree();
         assert(entityTree);
         EntitySimulationPointer simulation = entityTree ? entityTree->getSimulation() : nullptr;
@@ -3436,13 +3448,11 @@ void EntityItem::addGrab(GrabPointer grab) {

         EntityDynamicType dynamicType;
         QVariantMap arguments;
-        int grabParentJointIndex =grab->getParentJointIndex();
-        if (grabParentJointIndex == FARGRAB_RIGHTHAND_INDEX || grabParentJointIndex == FARGRAB_LEFTHAND_INDEX ||
-            grabParentJointIndex == FARGRAB_MOUSE_INDEX) {
+        if (isFarGrab) {
             // add a far-grab action
             dynamicType = DYNAMIC_TYPE_FAR_GRAB;
             arguments["otherID"] = grab->getOwnerID();
-            arguments["otherJointIndex"] = grabParentJointIndex;
+            arguments["otherJointIndex"] = jointIndex;
             arguments["targetPosition"] = vec3ToQMap(grab->getPositionalOffset());
             arguments["targetRotation"] = quatToQMap(grab->getRotationalOffset());
             arguments["linearTimeScale"] = 0.05;
@@ -3463,11 +3473,23 @@ void EntityItem::addGrab(GrabPointer grab) {
         grab->setActionID(actionID);
         _grabActions[actionID] = action;
         simulation->addDynamic(action);
+        markDirtyFlags(Simulation::DIRTY_MOTION_TYPE);
+        simulation->changeEntity(getThisPointer());
     }
 }

 void EntityItem::removeGrab(GrabPointer grab) {
+    int oldNumGrabs = _grabs.size();
     SpatiallyNestable::removeGrab(grab);
+    if (!getDynamic() && _grabs.size() != oldNumGrabs) {
+        // GRAB HACK: the expected behavior is for non-dynamic grabbed things to NOT be throwable
+        // so we slam the velocities to zero here whenever the number of grabs change.
+        // NOTE: if there is still another grab in effect this shouldn't interfere with the object's motion
+        // because that grab will slam the position+velocities next frame.
+        setLocalVelocity(glm::vec3(0.0f));
+        setAngularVelocity(glm::vec3(0.0f));
+    }
+    markDirtyFlags(Simulation::DIRTY_MOTION_TYPE);

     QUuid actionID = grab->getActionID();
     if (!actionID.isNull()) {

libraries/entities/src/EntityItemProperties.cpp

@@ -1023,7 +1023,7 @@ EntityPropertyFlags EntityItemProperties::getChangedProperties() const {
  *     parse the JSON string into a JavaScript object of name, URL pairs. <em>Read-only.</em>
  *
  * @property {ShapeType} shapeType="none" - The shape of the collision hull used if collisions are enabled.
- * @property {string} compoundShapeURL="" - The OBJ file to use for the compound shape if <code>shapeType</code> is
+ * @property {string} compoundShapeURL="" - The model file to use for the compound shape if <code>shapeType</code> is
  *     <code>"compound"</code>.
  *
  * @property {Entities.AnimationProperties} animation - An animation to play on the model.
@@ -1373,7 +1373,7 @@ EntityPropertyFlags EntityItemProperties::getChangedProperties() const {
  * @property {ShapeType} shapeType="box" - The shape of the volume in which the zone's lighting effects and avatar
  *     permissions have effect. Reverts to the default value if set to <code>"none"</code>, or set to <code>"compound"</code>
  *     and <code>compoundShapeURL</code> is <code>""</code>.
-  * @property {string} compoundShapeURL="" - The OBJ file to use for the compound shape if <code>shapeType</code> is
+  * @property {string} compoundShapeURL="" - The model file to use for the compound shape if <code>shapeType</code> is
  *     <code>"compound"</code>.
  *
  * @property {string} keyLightMode="inherit" - Configures the key light in the zone. Possible values:<br />

libraries/entities/src/ShapeEntityItem.cpp

@@ -112,7 +112,6 @@ EntityItemPointer ShapeEntityItem::sphereFactory(const EntityItemID& entityID, c
 ShapeEntityItem::ShapeEntityItem(const EntityItemID& entityItemID) : EntityItem(entityItemID) {
     _type = EntityTypes::Shape;
     _volumeMultiplier *= PI / 6.0f;
-    _material = std::make_shared<graphics::Material>();
 }

 EntityItemProperties ShapeEntityItem::getProperties(const EntityPropertyFlags& desiredProperties, bool allowEmptyDesiredProperties) const {
@@ -234,7 +233,6 @@ void ShapeEntityItem::appendSubclassData(OctreePacketData* packetData, EncodeBit
 void ShapeEntityItem::setColor(const glm::u8vec3& value) {
     withWriteLock([&] {
         _color = value;
-        _material->setAlbedo(toGlm(_color));
     });
 }

@@ -247,7 +245,6 @@ glm::u8vec3 ShapeEntityItem::getColor() const {
 void ShapeEntityItem::setAlpha(float alpha) {
     withWriteLock([&] {
         _alpha = alpha;
-        _material->setOpacity(alpha);
     });
 }


libraries/entities/src/ShapeEntityItem.h

@@ -101,8 +101,6 @@ public:
     virtual void computeShapeInfo(ShapeInfo& info) override;
     virtual ShapeType getShapeType() const override;

-    std::shared_ptr<graphics::Material> getMaterial() { return _material; }
-
     PulsePropertyGroup getPulseProperties() const;

 protected:
@@ -115,8 +113,6 @@ protected:
     //! prior functionality where new or unsupported shapes are treated as
     //! ellipsoids.
     ShapeType _collisionShapeType{ ShapeType::SHAPE_TYPE_ELLIPSOID };
-
-    std::shared_ptr<graphics::Material> _material;
 };

 #endif // hifi_ShapeEntityItem_h

libraries/entities/src/SimulationOwner.h

@@ -96,11 +96,11 @@ const uint8_t RECRUIT_SIMULATION_PRIORITY = VOLUNTEER_SIMULATION_PRIORITY + 1;
 // When poking objects with scripts an observer will bid at SCRIPT_EDIT priority.
 const uint8_t SCRIPT_GRAB_SIMULATION_PRIORITY = 128;
 const uint8_t SCRIPT_POKE_SIMULATION_PRIORITY = SCRIPT_GRAB_SIMULATION_PRIORITY - 1;
-const uint8_t AVATAR_ENTITY_SIMULATION_PRIORITY = 255;

 // PERSONAL priority (needs a better name) is the level at which a simulation observer owns its own avatar
 // which really just means: things that collide with it will be bid at a priority level one lower
 const uint8_t PERSONAL_SIMULATION_PRIORITY = SCRIPT_GRAB_SIMULATION_PRIORITY;
+const uint8_t AVATAR_ENTITY_SIMULATION_PRIORITY = PERSONAL_SIMULATION_PRIORITY;


 class SimulationOwner {

libraries/fbx/src/FBXSerializer.cpp

@@ -131,6 +131,7 @@ public:
     glm::vec3 geometricTranslation;
     glm::quat geometricRotation;
     glm::vec3 geometricScaling;
+    bool isLimbNode;  // is this FBXModel transform is a "LimbNode" i.e. a joint
 };

 glm::mat4 getGlobalTransform(const QMultiMap<QString, QString>& _connectionParentMap,
@@ -559,9 +560,11 @@ HFMModel* FBXSerializer::extractHFMModel(const QVariantHash& mapping, const QStr
                     glm::vec3 geometricRotation;

                     glm::vec3 rotationMin, rotationMax;
+
+                    bool isLimbNode = object.properties.size() >= 3 && object.properties.at(2) == "LimbNode";
                     FBXModel fbxModel = { name, -1, glm::vec3(), glm::mat4(), glm::quat(), glm::quat(), glm::quat(),
-                                       glm::mat4(), glm::vec3(), glm::vec3(),
-                                       false, glm::vec3(), glm::quat(), glm::vec3(1.0f) };
+                                          glm::mat4(), glm::vec3(), glm::vec3(),
+                                          false, glm::vec3(), glm::quat(), glm::vec3(1.0f), isLimbNode };
                     ExtractedMesh* mesh = NULL;
                     QVector<ExtractedBlendshape> blendshapes;
                     foreach (const FBXNode& subobject, object.children) {
@@ -752,17 +755,17 @@ HFMModel* FBXSerializer::extractHFMModel(const QVariantHash& mapping, const QStr
                         } else if (subobject.name == "Texture_Alpha_Source" && subobject.properties.length() >= TEXTURE_ALPHA_SOURCE_MIN_SIZE) {
                             tex.assign<uint8_t>(tex.alphaSource, subobject.properties.at(0).value<int>());
                         } else if (subobject.name == "ModelUVTranslation" && subobject.properties.length() >= MODEL_UV_TRANSLATION_MIN_SIZE) {
-                            tex.assign(tex.UVTranslation, glm::vec2(subobject.properties.at(0).value<double>(),
-                                                                    subobject.properties.at(1).value<double>()));
+                            auto newTranslation = glm::vec3(subobject.properties.at(0).value<double>(), subobject.properties.at(1).value<double>(), 0.0);
+                            tex.assign(tex.translation, tex.translation + newTranslation);
                         } else if (subobject.name == "ModelUVScaling" && subobject.properties.length() >= MODEL_UV_SCALING_MIN_SIZE) {
-                            tex.assign(tex.UVScaling, glm::vec2(subobject.properties.at(0).value<double>(),
-                                                                subobject.properties.at(1).value<double>()));
-                            if (tex.UVScaling.x == 0.0f) {
-                                tex.UVScaling.x = 1.0f;
+                            auto newScaling = glm::vec3(subobject.properties.at(0).value<double>(), subobject.properties.at(1).value<double>(), 1.0);
+                            if (newScaling.x == 0.0f) {
+                                newScaling.x = 1.0f;
                             }
-                            if (tex.UVScaling.y == 0.0f) {
-                                tex.UVScaling.y = 1.0f;
+                            if (newScaling.y == 0.0f) {
+                                newScaling.y = 1.0f;
                             }
+                            tex.assign(tex.scaling, tex.scaling * newScaling);
                         } else if (subobject.name == "Cropping" && subobject.properties.length() >= CROPPING_MIN_SIZE) {
                             tex.assign(tex.cropping, glm::vec4(subobject.properties.at(0).value<int>(),
                                                                 subobject.properties.at(1).value<int>(),
@@ -790,20 +793,21 @@ HFMModel* FBXSerializer::extractHFMModel(const QVariantHash& mapping, const QStr
                                         } else if (property.properties.at(0) == USE_MATERIAL) {
                                             tex.assign<bool>(tex.useMaterial, property.properties.at(index).value<int>());
                                         } else if (property.properties.at(0) == TRANSLATION) {
-                                            tex.assign(tex.translation, getVec3(property.properties, index));
+                                            tex.assign(tex.translation, tex.translation + getVec3(property.properties, index));
                                         } else if (property.properties.at(0) == ROTATION) {
                                             tex.assign(tex.rotation, getVec3(property.properties, index));
                                         } else if (property.properties.at(0) == SCALING) {
-                                            tex.assign(tex.scaling, getVec3(property.properties, index));
-                                            if (tex.scaling.x == 0.0f) {
-                                                tex.scaling.x = 1.0f;
+                                            auto newScaling = getVec3(property.properties, index);
+                                            if (newScaling.x == 0.0f) {
+                                                newScaling.x = 1.0f;
                                             }
-                                            if (tex.scaling.y == 0.0f) {
-                                                tex.scaling.y = 1.0f;
+                                            if (newScaling.y == 0.0f) {
+                                                newScaling.y = 1.0f;
                                             }
-                                            if (tex.scaling.z == 0.0f) {
-                                                tex.scaling.z = 1.0f;
+                                            if (newScaling.z == 0.0f) {
+                                                newScaling.z = 1.0f;
                                             }
+                                            tex.assign(tex.scaling, tex.scaling * newScaling);
                                         }
 #if defined(DEBUG_FBXSERIALIZER)
                                         else {
@@ -848,6 +852,7 @@ HFMModel* FBXSerializer::extractHFMModel(const QVariantHash& mapping, const QStr
                     }
                 } else if (object.name == "Material") {
                     HFMMaterial material;
+                    MaterialParam materialParam;
                     material.name = (object.properties.at(1).toString());
                     foreach (const FBXNode& subobject, object.children) {
                         bool properties = false;
@@ -892,6 +897,10 @@ HFMModel* FBXSerializer::extractHFMModel(const QVariantHash& mapping, const QStr
                             static const QVariant MAYA_EMISSIVE_INTENSITY = QByteArray("Maya|emissive_intensity");
                             static const QVariant MAYA_USE_EMISSIVE_MAP = QByteArray("Maya|use_emissive_map");
                             static const QVariant MAYA_USE_AO_MAP = QByteArray("Maya|use_ao_map");
+                            static const QVariant MAYA_UV_SCALE = QByteArray("Maya|uv_scale");
+                            static const QVariant MAYA_UV_OFFSET = QByteArray("Maya|uv_offset");
+                            static const int MAYA_UV_OFFSET_PROPERTY_LENGTH = 6;
+                            static const int MAYA_UV_SCALE_PROPERTY_LENGTH = 6;



@@ -980,6 +989,27 @@ HFMModel* FBXSerializer::extractHFMModel(const QVariantHash& mapping, const QStr
                                         material.isPBSMaterial = true;
                                         material.useOcclusionMap = (bool)property.properties.at(index).value<double>();

+                                    } else if (property.properties.at(0) == MAYA_UV_SCALE) {
+                                        if (property.properties.size() == MAYA_UV_SCALE_PROPERTY_LENGTH) {
+                                            // properties: { "Maya|uv_scale", "Vector2D", "Vector2", nothing, double, double }
+                                            glm::vec3 scale = glm::vec3(property.properties.at(4).value<double>(), property.properties.at(5).value<double>(), 1.0);
+                                            if (scale.x == 0.0f) {
+                                                scale.x = 1.0f;
+                                            }
+                                            if (scale.y == 0.0f) {
+                                                scale.y = 1.0f;
+                                            }
+                                            if (scale.z == 0.0f) {
+                                                scale.z = 1.0f;
+                                            }
+                                            materialParam.scaling *= scale;
+                                        }
+                                    } else if (property.properties.at(0) == MAYA_UV_OFFSET) {
+                                        if (property.properties.size() == MAYA_UV_OFFSET_PROPERTY_LENGTH) {
+                                            // properties: { "Maya|uv_offset", "Vector2D", "Vector2", nothing, double, double }
+                                            glm::vec3 translation = glm::vec3(property.properties.at(4).value<double>(), property.properties.at(5).value<double>(), 1.0);
+                                            materialParam.translation += translation;
+                                        }
                                     } else {
                                         const QString propname = property.properties.at(0).toString();
                                         unknowns.push_back(propname.toStdString());
@@ -1001,6 +1031,7 @@ HFMModel* FBXSerializer::extractHFMModel(const QVariantHash& mapping, const QStr
                     }
                     material.materialID = getID(object.properties);
                     _hfmMaterials.insert(material.materialID, material);
+                    _materialParams.insert(material.materialID, materialParam);


                 } else if (object.name == "NodeAttribute") {
@@ -1258,6 +1289,7 @@ HFMModel* FBXSerializer::extractHFMModel(const QVariantHash& mapping, const QStr
     // convert the models to joints
     QVariantList freeJoints = mapping.values("freeJoint");
     hfmModel.hasSkeletonJoints = false;
+
     foreach (const QString& modelID, modelIDs) {
         const FBXModel& fbxModel = fbxModels[modelID];
         HFMJoint joint;
@@ -1288,6 +1320,8 @@ HFMModel* FBXSerializer::extractHFMModel(const QVariantHash& mapping, const QStr
         joint.geometricTranslation = fbxModel.geometricTranslation;
         joint.geometricRotation = fbxModel.geometricRotation;
         joint.geometricScaling = fbxModel.geometricScaling;
+        joint.isSkeletonJoint = fbxModel.isLimbNode;
+        hfmModel.hasSkeletonJoints = (hfmModel.hasSkeletonJoints || joint.isSkeletonJoint);

         glm::quat combinedRotation = joint.preRotation * joint.rotation * joint.postRotation;

@@ -1311,14 +1345,6 @@ HFMModel* FBXSerializer::extractHFMModel(const QVariantHash& mapping, const QStr
             joint.name = hfmModel.hfmToHifiJointNameMapping.key(fbxModel.name);
         }

-        foreach (const QString& childID, _connectionChildMap.values(modelID)) {
-            QString type = typeFlags.value(childID);
-            if (!type.isEmpty()) {
-                hfmModel.hasSkeletonJoints |= (joint.isSkeletonJoint = type.toLower().contains("Skeleton"));
-                break;
-            }
-        }
-
         joint.bindTransformFoundInCluster = false;

         hfmModel.joints.append(joint);
@@ -1439,7 +1465,9 @@ HFMModel* FBXSerializer::extractHFMModel(const QVariantHash& mapping, const QStr
                 materialIndex++;

             } else if (_textureFilenames.contains(childID)) {
-                HFMTexture texture = getTexture(childID);
+                // NOTE (Sabrina 2019/01/11): getTextures now takes in the materialID as a second parameter, because FBX material nodes can sometimes have uv transform information (ex: "Maya|uv_scale")
+                // I'm leaving the second parameter blank right now as this code may never be used.
+                HFMTexture texture = getTexture(childID, "");
                 for (int j = 0; j < extracted.partMaterialTextures.size(); j++) {
                     int partTexture = extracted.partMaterialTextures.at(j).second;
                     if (partTexture == textureIndex && !(partTexture == 0 && materialsHaveTextures)) {
@@ -1452,9 +1480,6 @@ HFMModel* FBXSerializer::extractHFMModel(const QVariantHash& mapping, const QStr
             }
         }

-        extracted.mesh.createMeshTangents(generateTangents);
-        extracted.mesh.createBlendShapeTangents(generateTangents);
-
         // find the clusters with which the mesh is associated
         QVector<QString> clusterIDs;
         foreach (const QString& childID, _connectionChildMap.values(it.key())) {

libraries/fbx/src/FBXSerializer.h

@@ -37,8 +37,6 @@ class FBXNode;

 class TextureParam {
 public:
-    glm::vec2 UVTranslation;
-    glm::vec2 UVScaling;
     glm::vec4 cropping;
     QString UVSet;

@@ -63,8 +61,6 @@ public:
     bool isDefault;

     TextureParam() :
-        UVTranslation(0.0f),
-        UVScaling(1.0f),
         cropping(0.0f),
         UVSet("map1"),
         translation(0.0f),
@@ -77,8 +73,6 @@ public:
     {}

     TextureParam(const TextureParam& src) :
-        UVTranslation(src.UVTranslation),
-        UVScaling(src.UVScaling),
         cropping(src.cropping),
         UVSet(src.UVSet),
         translation(src.translation),
@@ -92,6 +86,22 @@ public:

 };

+class MaterialParam {
+public:
+    glm::vec3 translation;
+    glm::vec3 scaling;
+
+    MaterialParam() :
+        translation(0.0),
+        scaling(1.0)
+    {}
+
+    MaterialParam(const MaterialParam& src) :
+        translation(src.translation),
+        scaling(src.scaling)
+    {}
+};
+
 class ExtractedMesh;

 class FBXSerializer : public HFMSerializer {
@@ -114,7 +124,7 @@ public:
     static ExtractedMesh extractMesh(const FBXNode& object, unsigned int& meshIndex, bool deduplicate = true);
     QHash<QString, ExtractedMesh> meshes;

-    HFMTexture getTexture(const QString& textureID);
+    HFMTexture getTexture(const QString& textureID, const QString& materialID);

     QHash<QString, QString> _textureNames;
     // Hashes the original RelativeFilename of textures
@@ -141,6 +151,7 @@ public:
     QHash<QString, QString> occlusionTextures;

     QHash<QString, HFMMaterial> _hfmMaterials;
+    QHash<QString, MaterialParam> _materialParams;

     void consolidateHFMMaterials(const QVariantHash& mapping);


libraries/fbx/src/FBXSerializer_Material.cpp

@@ -27,7 +27,7 @@

 #include <hfm/ModelFormatLogging.h>

-HFMTexture FBXSerializer::getTexture(const QString& textureID) {
+HFMTexture FBXSerializer::getTexture(const QString& textureID, const QString& materialID) {
     HFMTexture texture;
     const QByteArray& filepath = _textureFilepaths.value(textureID);
     texture.content = _textureContent.value(filepath);
@@ -45,8 +45,8 @@ HFMTexture FBXSerializer::getTexture(const QString& textureID) {
     if (_textureParams.contains(textureID)) {
         auto p = _textureParams.value(textureID);

-        texture.transform.setTranslation(p.translation);
-        texture.transform.setRotation(glm::quat(glm::radians(p.rotation)));
+        texture.transform.postTranslate(p.translation);
+        texture.transform.postRotate(glm::quat(glm::radians(p.rotation)));

         auto scaling = p.scaling;
         // Protect from bad scaling which should never happen
@@ -59,13 +59,19 @@ HFMTexture FBXSerializer::getTexture(const QString& textureID) {
         if (scaling.z == 0.0f) {
             scaling.z = 1.0f;
         }
-        texture.transform.setScale(scaling);
+        texture.transform.postScale(scaling);

         if ((p.UVSet != "map1") && (p.UVSet != "UVSet0")) {
             texture.texcoordSet = 1;
         }
         texture.texcoordSetName = p.UVSet;
     }
+    auto materialParamItr = _materialParams.find(materialID);
+    if (materialParamItr != _materialParams.end()) {
+        auto& materialParam = materialParamItr.value();
+        texture.transform.postTranslate(materialParam.translation);
+        texture.transform.postScale(materialParam.scaling);
+    }
     return texture;
 }

@@ -102,12 +108,12 @@ void FBXSerializer::consolidateHFMMaterials(const QVariantHash& mapping) {
                 material.diffuseFactor = 1.0;
             }

-            diffuseTexture = getTexture(diffuseTextureID);
+            diffuseTexture = getTexture(diffuseTextureID, material.materialID);

             // FBX files generated by 3DSMax have an intermediate texture parent, apparently
             foreach(const QString& childTextureID, _connectionChildMap.values(diffuseTextureID)) {
                 if (_textureFilenames.contains(childTextureID)) {
-                    diffuseTexture = getTexture(diffuseTextureID);
+                    diffuseTexture = getTexture(diffuseTextureID, material.materialID);
                 }
             }

@@ -122,7 +128,7 @@ void FBXSerializer::consolidateHFMMaterials(const QVariantHash& mapping) {
             transparentTextureID = diffuseTextureID;
         }
         if (!transparentTextureID.isNull()) {
-            transparentTexture = getTexture(transparentTextureID);
+            transparentTexture = getTexture(transparentTextureID, material.materialID);
             material.opacityTexture = transparentTexture;
             detectDifferentUVs |= (transparentTexture.texcoordSet != 0) || (!transparentTexture.transform.isIdentity());
         }
@@ -131,13 +137,13 @@ void FBXSerializer::consolidateHFMMaterials(const QVariantHash& mapping) {
         QString bumpTextureID = bumpTextures.value(material.materialID);
         QString normalTextureID = normalTextures.value(material.materialID);
         if (!normalTextureID.isNull()) {
-            normalTexture = getTexture(normalTextureID);
+            normalTexture = getTexture(normalTextureID, material.materialID);
             normalTexture.isBumpmap = false;

             material.normalTexture = normalTexture;
             detectDifferentUVs |= (normalTexture.texcoordSet != 0) || (!normalTexture.transform.isIdentity());
         } else if (!bumpTextureID.isNull()) {
-            normalTexture = getTexture(bumpTextureID);
+            normalTexture = getTexture(bumpTextureID, material.materialID);
             normalTexture.isBumpmap = true;

             material.normalTexture = normalTexture;
@@ -147,7 +153,7 @@ void FBXSerializer::consolidateHFMMaterials(const QVariantHash& mapping) {
         HFMTexture specularTexture;
         QString specularTextureID = specularTextures.value(material.materialID);
         if (!specularTextureID.isNull()) {
-            specularTexture = getTexture(specularTextureID);
+            specularTexture = getTexture(specularTextureID, material.materialID);
             detectDifferentUVs |= (specularTexture.texcoordSet != 0) || (!specularTexture.transform.isIdentity());
             material.specularTexture = specularTexture;
         }
@@ -155,7 +161,7 @@ void FBXSerializer::consolidateHFMMaterials(const QVariantHash& mapping) {
         HFMTexture metallicTexture;
         QString metallicTextureID = metallicTextures.value(material.materialID);
         if (!metallicTextureID.isNull()) {
-            metallicTexture = getTexture(metallicTextureID);
+            metallicTexture = getTexture(metallicTextureID, material.materialID);
             detectDifferentUVs |= (metallicTexture.texcoordSet != 0) || (!metallicTexture.transform.isIdentity());
             material.metallicTexture = metallicTexture;
         }
@@ -163,7 +169,7 @@ void FBXSerializer::consolidateHFMMaterials(const QVariantHash& mapping) {
         HFMTexture roughnessTexture;
         QString roughnessTextureID = roughnessTextures.value(material.materialID);
         if (!roughnessTextureID.isNull()) {
-            roughnessTexture = getTexture(roughnessTextureID);
+            roughnessTexture = getTexture(roughnessTextureID, material.materialID);
             material.roughnessTexture = roughnessTexture;
             detectDifferentUVs |= (roughnessTexture.texcoordSet != 0) || (!roughnessTexture.transform.isIdentity());
         }
@@ -171,7 +177,7 @@ void FBXSerializer::consolidateHFMMaterials(const QVariantHash& mapping) {
         HFMTexture shininessTexture;
         QString shininessTextureID = shininessTextures.value(material.materialID);
         if (!shininessTextureID.isNull()) {
-            shininessTexture = getTexture(shininessTextureID);
+            shininessTexture = getTexture(shininessTextureID, material.materialID);
             material.glossTexture = shininessTexture;
             detectDifferentUVs |= (shininessTexture.texcoordSet != 0) || (!shininessTexture.transform.isIdentity());
         }
@@ -179,7 +185,7 @@ void FBXSerializer::consolidateHFMMaterials(const QVariantHash& mapping) {
         HFMTexture emissiveTexture;
         QString emissiveTextureID = emissiveTextures.value(material.materialID);
         if (!emissiveTextureID.isNull()) {
-            emissiveTexture = getTexture(emissiveTextureID);
+            emissiveTexture = getTexture(emissiveTextureID, material.materialID);
             detectDifferentUVs |= (emissiveTexture.texcoordSet != 0) || (!emissiveTexture.transform.isIdentity());
             material.emissiveTexture = emissiveTexture;

@@ -202,7 +208,7 @@ void FBXSerializer::consolidateHFMMaterials(const QVariantHash& mapping) {
         }

         if (!occlusionTextureID.isNull()) {
-            occlusionTexture = getTexture(occlusionTextureID);
+            occlusionTexture = getTexture(occlusionTextureID, material.materialID);
             detectDifferentUVs |= (occlusionTexture.texcoordSet != 0) || (!emissiveTexture.transform.isIdentity());
             material.occlusionTexture = occlusionTexture;
         }
@@ -222,7 +228,7 @@ void FBXSerializer::consolidateHFMMaterials(const QVariantHash& mapping) {
         }

         if (_loadLightmaps && !ambientTextureID.isNull()) {
-            ambientTexture = getTexture(ambientTextureID);
+            ambientTexture = getTexture(ambientTextureID, material.materialID);
             detectDifferentUVs |= (ambientTexture.texcoordSet != 0) || (!ambientTexture.transform.isIdentity());
             material.lightmapTexture = ambientTexture;
             material.lightmapParams = lightmapParams;

libraries/gl/src/gl/Config.cpp

@@ -118,6 +118,8 @@ void gl::setSwapInterval(int interval) {
     wglSwapIntervalEXT(interval);
 #elif defined(Q_OS_MAC)
     CGLSetParameter(CGLGetCurrentContext(), kCGLCPSwapInterval, &interval);
+#elif defined(Q_OS_ANDROID)
+    eglSwapInterval(eglGetCurrentDisplay(), interval);
 #else
     Q_UNUSED(interval);
 #endif

libraries/gl/src/gl/Context.cpp

@@ -34,22 +34,9 @@ bool Context::USE_CUSTOM_CONTEXT { true };
 #endif

 bool Context::enableDebugLogger() {
-#if defined(Q_OS_MAC)
-    // OSX does not support GL_KHR_debug or GL_ARB_debug_output
-    return false;
-#else
-#if defined(DEBUG) || defined(USE_GLES)
-    static bool enableDebugLogger = true;
-#else
-    static const QString DEBUG_FLAG("HIFI_DEBUG_OPENGL");
-    static bool enableDebugLogger = QProcessEnvironment::systemEnvironment().contains(DEBUG_FLAG);
-#endif
-    return enableDebugLogger;
-#endif
+    return gl::debugContextEnabled();
 }

-
-
 std::atomic<size_t> Context::_totalSwapchainMemoryUsage { 0 };

 size_t Context::getSwapchainMemoryUsage() { return _totalSwapchainMemoryUsage.load(); }

libraries/gl/src/gl/ContextQt.cpp

@@ -52,6 +52,11 @@ void Context::moveToThread(QThread* thread) {
 }

 void Context::debugMessageHandler(const QOpenGLDebugMessage& debugMessage) {
+    auto type = debugMessage.type();
+    if (type == QOpenGLDebugMessage::PerformanceType) {
+        return;
+    }
+
     auto severity = debugMessage.severity();
     switch (severity) {
         case QOpenGLDebugMessage::NotificationSeverity:
@@ -60,13 +65,13 @@ void Context::debugMessageHandler(const QOpenGLDebugMessage& debugMessage) {
         default:
             break;
     }
-    qDebug(glLogging) << debugMessage;
+    qWarning(glLogging) << debugMessage;
     return;
 }

 void Context::setupDebugLogging(QOpenGLContext *context) {
     QOpenGLDebugLogger *logger = new QOpenGLDebugLogger(context);
-    QObject::connect(logger, &QOpenGLDebugLogger::messageLogged, nullptr, [](const QOpenGLDebugMessage& message){
+    QObject::connect(logger, &QOpenGLDebugLogger::messageLogged, context, [](const QOpenGLDebugMessage& message){
         Context::debugMessageHandler(message);
     });
     if (logger->initialize()) {

libraries/gl/src/gl/GLHelpers.cpp

@@ -198,11 +198,48 @@ namespace gl {


     bool checkGLErrorDebug(const char* name) {
-#ifdef DEBUG
+        // Disabling error checking macro on Android debug builds for now,
+        // as it throws off performance testing, which must be done on
+        // Debug builds
+#if defined(DEBUG) && !defined(Q_OS_ANDROID)
         return checkGLError(name);
 #else
         Q_UNUSED(name);
         return false;
 #endif
     }
+
+    // Enables annotation of captures made by tools like renderdoc
+    bool khrDebugEnabled() {
+        static std::once_flag once;
+        static bool khrDebug = false;
+        std::call_once(once, [&] {
+            khrDebug = nullptr != glPushDebugGroupKHR;
+        });
+        return khrDebug;
+    }
+
+    // Enables annotation of captures made by tools like renderdoc
+    bool extDebugMarkerEnabled() {
+        static std::once_flag once;
+        static bool extMarker = false;
+        std::call_once(once, [&] {
+            extMarker = nullptr != glPushGroupMarkerEXT;
+        });
+        return extMarker;
+    }
+
+    bool debugContextEnabled() {
+#if defined(Q_OS_MAC)
+        // OSX does not support GL_KHR_debug or GL_ARB_debug_output
+        static bool enableDebugLogger = false;
+#elif defined(DEBUG) || defined(USE_GLES)
+        //static bool enableDebugLogger = true;
+        static bool enableDebugLogger = false;
+#else
+        static const QString DEBUG_FLAG("HIFI_DEBUG_OPENGL");
+        static bool enableDebugLogger = QProcessEnvironment::systemEnvironment().contains(DEBUG_FLAG);
+#endif
+        return enableDebugLogger;
+    }
 }

libraries/gl/src/gl/GLHelpers.h

@@ -37,7 +37,13 @@ bool isRenderThread();
 namespace gl {
     void globalLock();
     void globalRelease(bool finish = true);
-
+
+    bool debugContextEnabled();
+
+    bool khrDebugEnabled();
+
+    bool extDebugMarkerEnabled();
+
     void withSavedContext(const std::function<void()>& f);

     bool checkGLError(const char* name);

libraries/gpu-gl-common/src/gpu/gl/GLBackend.cpp

@@ -392,8 +392,38 @@ void GLBackend::renderPassDraw(const Batch& batch) {
     }
 }

+// Support annotating captures in tools like Renderdoc
+class GlDuration {
+public:
+#ifdef USE_GLES
+    GlDuration(const char* name) {
+        // We need to use strlen here instead of -1, because the Snapdragon profiler
+        // will crash otherwise
+        glPushDebugGroup(GL_DEBUG_SOURCE_APPLICATION, 0, strlen(name), name);
+    }
+    ~GlDuration() {
+        glPopDebugGroup();
+    }
+#else
+    GlDuration(const char* name) {
+        if (::gl::khrDebugEnabled()) {
+            glPushDebugGroupKHR(GL_DEBUG_SOURCE_APPLICATION_KHR, 0, -1, name);
+        }
+    }
+    ~GlDuration() {
+        if (::gl::khrDebugEnabled()) {
+            glPopDebugGroupKHR();
+        }
+    }
+#endif
+};
+
+#define GL_PROFILE_RANGE(category, name) \
+    PROFILE_RANGE(category, name); \
+    GlDuration glProfileRangeThis(name);
+
 void GLBackend::render(const Batch& batch) {
-    PROFILE_RANGE(render_gpu_gl, batch.getName());
+    GL_PROFILE_RANGE(render_gpu_gl, batch.getName().c_str());

     _transform._skybox = _stereo._skybox = batch.isSkyboxEnabled();
     // Allow the batch to override the rendering stereo settings
@@ -406,7 +436,7 @@ void GLBackend::render(const Batch& batch) {
     _transform._projectionJitter = Vec2(0.0f, 0.0f);

     {
-        PROFILE_RANGE(render_gpu_gl_detail, "Transfer");
+        GL_PROFILE_RANGE(render_gpu_gl_detail, "Transfer");
         renderPassTransfer(batch);
     }

@@ -416,7 +446,7 @@ void GLBackend::render(const Batch& batch) {
     }
 #endif
     {
-        PROFILE_RANGE(render_gpu_gl_detail, _stereo.isStereo() ? "Render Stereo" : "Render");
+        GL_PROFILE_RANGE(render_gpu_gl_detail, _stereo.isStereo() ? "Render Stereo" : "Render");
         renderPassDraw(batch);
     }
 #ifdef GPU_STEREO_DRAWCALL_INSTANCED

libraries/gpu-gl-common/src/gpu/gl/GLBackend.h

@@ -54,153 +54,8 @@
 #define GPU_STEREO_CAMERA_BUFFER
 #endif

-//
-// GL Backend pointer storage mechanism
-// One of the following three defines must be defined.
-// GPU_POINTER_STORAGE_SHARED
-
-// The platonic ideal, use references to smart pointers.
-// However, this produces artifacts because there are too many places in the code right now that
-// create temporary values (undesirable smart pointer duplications) and then those temp variables
-// get passed on and have their reference taken, and then invalidated
-// GPU_POINTER_STORAGE_REF
-
-// Raw pointer manipulation.  Seems more dangerous than the reference wrappers,
-// but in practice, the danger of grabbing a reference to a temporary variable
-// is causing issues
-// GPU_POINTER_STORAGE_RAW
-
-#if defined(USE_GLES)
-#define GPU_POINTER_STORAGE_SHARED
-#else
-#define GPU_POINTER_STORAGE_RAW
-#endif
-
 namespace gpu { namespace gl {

-#if defined(GPU_POINTER_STORAGE_SHARED)
-template <typename T>
-static inline bool compare(const std::shared_ptr<T>& a, const std::shared_ptr<T>& b) {
-    return a == b;
-}
-
-template <typename T>
-static inline T* acquire(const std::shared_ptr<T>& pointer) {
-    return pointer.get();
-}
-
-template <typename T>
-static inline void reset(std::shared_ptr<T>& pointer) {
-    return pointer.reset();
-}
-
-template <typename T>
-static inline bool valid(const std::shared_ptr<T>& pointer) {
-    return pointer.operator bool();
-}
-
-template <typename T>
-static inline void assign(std::shared_ptr<T>& pointer, const std::shared_ptr<T>& source) {
-    pointer = source;
-}
-
-using BufferReference = BufferPointer;
-using TextureReference = TexturePointer;
-using FramebufferReference = FramebufferPointer;
-using FormatReference = Stream::FormatPointer;
-using PipelineReference = PipelinePointer;
-
-#define GPU_REFERENCE_INIT_VALUE nullptr
-
-#elif defined(GPU_POINTER_STORAGE_REF)
-
-template <typename T>
-class PointerReferenceWrapper : public std::reference_wrapper<const std::shared_ptr<T>> {
-    using Parent = std::reference_wrapper<const std::shared_ptr<T>>;
-
-public:
-    using Pointer = std::shared_ptr<T>;
-    PointerReferenceWrapper() : Parent(EMPTY()) {}
-    PointerReferenceWrapper(const Pointer& pointer) : Parent(pointer) {}
-    void clear() { *this = EMPTY(); }
-
-private:
-    static const Pointer& EMPTY() {
-        static const Pointer EMPTY_VALUE;
-        return EMPTY_VALUE;
-    };
-};
-
-template <typename T>
-static bool compare(const PointerReferenceWrapper<T>& reference, const std::shared_ptr<T>& pointer) {
-    return reference.get() == pointer;
-}
-
-template <typename T>
-static inline T* acquire(const PointerReferenceWrapper<T>& reference) {
-    return reference.get().get();
-}
-
-template <typename T>
-static void assign(PointerReferenceWrapper<T>& reference, const std::shared_ptr<T>& pointer) {
-    reference = pointer;
-}
-
-template <typename T>
-static bool valid(const PointerReferenceWrapper<T>& reference) {
-    return reference.get().operator bool();
-}
-
-template <typename T>
-static inline void reset(PointerReferenceWrapper<T>& reference) {
-    return reference.clear();
-}
-
-using BufferReference = PointerReferenceWrapper<Buffer>;
-using TextureReference = PointerReferenceWrapper<Texture>;
-using FramebufferReference = PointerReferenceWrapper<Framebuffer>;
-using FormatReference = PointerReferenceWrapper<Stream::Format>;
-using PipelineReference = PointerReferenceWrapper<Pipeline>;
-
-#define GPU_REFERENCE_INIT_VALUE
-
-#elif defined(GPU_POINTER_STORAGE_RAW)
-
-template <typename T>
-static bool compare(const T* const& rawPointer, const std::shared_ptr<T>& pointer) {
-    return rawPointer == pointer.get();
-}
-
-template <typename T>
-static inline T* acquire(T*& rawPointer) {
-    return rawPointer;
-}
-
-template <typename T>
-static inline bool valid(const T* const& rawPointer) {
-    return rawPointer;
-}
-
-template <typename T>
-static inline void reset(T*& rawPointer) {
-    rawPointer = nullptr;
-}
-
-template <typename T>
-static inline void assign(T*& rawPointer, const std::shared_ptr<T>& pointer) {
-    rawPointer = pointer.get();
-}
-
-using BufferReference = Buffer*;
-using TextureReference = Texture*;
-using FramebufferReference = Framebuffer*;
-using FormatReference = Stream::Format*;
-using PipelineReference = Pipeline*;
-
-#define GPU_REFERENCE_INIT_VALUE nullptr
-
-#endif
-
 class GLBackend : public Backend, public std::enable_shared_from_this<GLBackend> {
     // Context Backend static interface required
     friend class gpu::Context;
@@ -583,13 +438,13 @@ protected:

             BufferState& operator=(const BufferState& other) = delete;
             void reset() {
-                gpu::gl::reset(buffer);
+                gpu::reset(buffer);
                 offset = 0;
                 size = 0;
             }
             bool compare(const BufferPointer& buffer, GLintptr offset, GLsizeiptr size) {
                 const auto& self = *this;
-                return (self.offset == offset && self.size == size && gpu::gl::compare(self.buffer, buffer));
+                return (self.offset == offset && self.size == size && gpu::compare(self.buffer, buffer));
             }
         };


libraries/gpu-gl-common/src/gpu/gl/GLBackendOutput.cpp

@@ -73,7 +73,7 @@ void GLBackend::do_advance(const Batch& batch, size_t paramOffset) {
 }

 void GLBackend::do_clearFramebuffer(const Batch& batch, size_t paramOffset) {
-    if (_stereo.isStereo() && !_pipeline._stateCache.scissorEnable) {
+    if (_stereo.isStereo() && !_pipeline._stateCache.flags.scissorEnable) {
         qWarning("Clear without scissor in stereo mode");
     }

@@ -140,7 +140,7 @@ void GLBackend::do_clearFramebuffer(const Batch& batch, size_t paramOffset) {
     }

     // Apply scissor if needed and if not already on
-    bool doEnableScissor = (useScissor && (!_pipeline._stateCache.scissorEnable));
+    bool doEnableScissor = (useScissor && (!_pipeline._stateCache.flags.scissorEnable));
     if (doEnableScissor) {
         glEnable(GL_SCISSOR_TEST);
     }

libraries/gpu-gl-common/src/gpu/gl/GLBackendState.cpp

@@ -100,17 +100,17 @@ void GLBackend::do_setStateCullMode(int32 mode) {
 }

 void GLBackend::do_setStateFrontFaceClockwise(bool isClockwise) {
-    if (_pipeline._stateCache.frontFaceClockwise != isClockwise) {
+    if (_pipeline._stateCache.flags.frontFaceClockwise != isClockwise) {
         static GLenum  GL_FRONT_FACES[] = { GL_CCW, GL_CW };
         glFrontFace(GL_FRONT_FACES[isClockwise]);
         (void)CHECK_GL_ERROR();

-        _pipeline._stateCache.frontFaceClockwise = isClockwise;
+        _pipeline._stateCache.flags.frontFaceClockwise = isClockwise;
     }
 }

 void GLBackend::do_setStateDepthClampEnable(bool enable) {
-    if (_pipeline._stateCache.depthClampEnable != enable) {
+    if (_pipeline._stateCache.flags.depthClampEnable != enable) {
 #if !defined(USE_GLES)
         if (enable) {
             glEnable(GL_DEPTH_CLAMP);
@@ -118,13 +118,13 @@ void GLBackend::do_setStateDepthClampEnable(bool enable) {
             glDisable(GL_DEPTH_CLAMP);
         }
         (void)CHECK_GL_ERROR();
-        _pipeline._stateCache.depthClampEnable = enable;
+        _pipeline._stateCache.flags.depthClampEnable = enable;
 #endif
     }
 }

 void GLBackend::do_setStateScissorEnable(bool enable) {
-    if (_pipeline._stateCache.scissorEnable != enable) {
+    if (_pipeline._stateCache.flags.scissorEnable != enable) {
         if (enable) {
             glEnable(GL_SCISSOR_TEST);
         } else {
@@ -132,12 +132,12 @@ void GLBackend::do_setStateScissorEnable(bool enable) {
         }
         (void)CHECK_GL_ERROR();

-        _pipeline._stateCache.scissorEnable = enable;
+        _pipeline._stateCache.flags.scissorEnable = enable;
     }
 }

 void GLBackend::do_setStateMultisampleEnable(bool enable) {
-    if (_pipeline._stateCache.multisampleEnable != enable) {
+    if (_pipeline._stateCache.flags.multisampleEnable != enable) {
 #if !defined(USE_GLES)
         if (enable) {
             glEnable(GL_MULTISAMPLE);
@@ -146,13 +146,13 @@ void GLBackend::do_setStateMultisampleEnable(bool enable) {
         }
         (void)CHECK_GL_ERROR();

-        _pipeline._stateCache.multisampleEnable = enable;
+        _pipeline._stateCache.flags.multisampleEnable = enable;
 #endif
     }
 }

 void GLBackend::do_setStateAntialiasedLineEnable(bool enable) {
-    if (_pipeline._stateCache.antialisedLineEnable != enable) {
+    if (_pipeline._stateCache.flags.antialisedLineEnable != enable) {
 #if !defined(USE_GLES)
         if (enable) {
             glEnable(GL_LINE_SMOOTH);
@@ -161,7 +161,7 @@ void GLBackend::do_setStateAntialiasedLineEnable(bool enable) {
         }
         (void)CHECK_GL_ERROR();

-        _pipeline._stateCache.antialisedLineEnable = enable;
+        _pipeline._stateCache.flags.antialisedLineEnable = enable;
 #endif
     }
 }
@@ -206,7 +206,7 @@ void GLBackend::do_setStateDepthTest(State::DepthTest test) {
         if (CHECK_GL_ERROR()) {
             qCDebug(gpulogging) << "DepthTest" << (test.isEnabled() ? "Enabled" : "Disabled")
                 << "Mask=" << (test.getWriteMask() ? "Write" : "no Write")
-                << "Func=" << test.getFunction()
+                << "Func=" << (uint16_t)test.getFunction()
                 << "Raw=" << test.getRaw();
         }
         _pipeline._stateCache.depthTest = test;
@@ -264,7 +264,7 @@ void GLBackend::do_setStateStencil(State::StencilActivation activation, State::S
 }

 void GLBackend::do_setStateAlphaToCoverageEnable(bool enable) {
-    if (_pipeline._stateCache.alphaToCoverageEnable != enable) {
+    if (_pipeline._stateCache.flags.alphaToCoverageEnable != enable) {
         if (enable) {
             glEnable(GL_SAMPLE_ALPHA_TO_COVERAGE);
         } else {
@@ -272,7 +272,7 @@ void GLBackend::do_setStateAlphaToCoverageEnable(bool enable) {
         }
         (void)CHECK_GL_ERROR();

-        _pipeline._stateCache.alphaToCoverageEnable = enable;
+        _pipeline._stateCache.flags.alphaToCoverageEnable = enable;
     }
 }

@@ -317,7 +317,7 @@ void GLBackend::do_setStateColorWriteMask(uint32 mask) {
             mask & State::ColorMask::WRITE_ALPHA);
         (void)CHECK_GL_ERROR();

-        _pipeline._stateCache.colorWriteMask = mask;
+        _pipeline._stateCache.colorWriteMask = (State::ColorMask)mask;
     }
 }


libraries/gpu-gl-common/src/gpu/gl/GLShared.cpp

@@ -174,17 +174,17 @@ void getCurrentGLState(State::Data& state) {
     {
         GLint winding;
         glGetIntegerv(GL_FRONT_FACE, &winding);
-        state.frontFaceClockwise = (winding == GL_CW);
+        state.flags.frontFaceClockwise = (winding == GL_CW);
 #if defined(USE_GLES)
-        state.multisampleEnable = glIsEnabled(GL_MULTISAMPLE_EXT);
-        state.antialisedLineEnable = false;
-        state.depthClampEnable = false;
+        state.flags.multisampleEnable = glIsEnabled(GL_MULTISAMPLE_EXT);
+        state.flags.antialisedLineEnable = false;
+        state.flags.depthClampEnable = false;
 #else
-        state.multisampleEnable = glIsEnabled(GL_MULTISAMPLE);
-        state.antialisedLineEnable = glIsEnabled(GL_LINE_SMOOTH);
-        state.depthClampEnable = glIsEnabled(GL_DEPTH_CLAMP);
+        state.flags.multisampleEnable = glIsEnabled(GL_MULTISAMPLE);
+        state.flags.antialisedLineEnable = glIsEnabled(GL_LINE_SMOOTH);
+        state.flags.depthClampEnable = glIsEnabled(GL_DEPTH_CLAMP);
 #endif
-        state.scissorEnable = glIsEnabled(GL_SCISSOR_TEST);
+        state.flags.scissorEnable = glIsEnabled(GL_SCISSOR_TEST);
     }
     {
         if (glIsEnabled(GL_POLYGON_OFFSET_FILL)) {
@@ -247,7 +247,7 @@ void getCurrentGLState(State::Data& state) {
         state.sampleMask = mask;
     }
     {
-        state.alphaToCoverageEnable = glIsEnabled(GL_SAMPLE_ALPHA_TO_COVERAGE);
+        state.flags.alphaToCoverageEnable = glIsEnabled(GL_SAMPLE_ALPHA_TO_COVERAGE);
     }
     {
         GLboolean isEnabled = glIsEnabled(GL_BLEND);
@@ -272,10 +272,10 @@ void getCurrentGLState(State::Data& state) {
     {
         GLboolean mask[4];
         glGetBooleanv(GL_COLOR_WRITEMASK, mask);
-        state.colorWriteMask = (mask[0] ? State::WRITE_RED : 0)
+        state.colorWriteMask = (State::ColorMask)((mask[0] ? State::WRITE_RED : 0)
             | (mask[1] ? State::WRITE_GREEN : 0)
             | (mask[2] ? State::WRITE_BLUE : 0)
-            | (mask[3] ? State::WRITE_ALPHA : 0);
+            | (mask[3] ? State::WRITE_ALPHA : 0));
     }

     (void)CHECK_GL_ERROR();

libraries/gpu-gl-common/src/gpu/gl/GLState.cpp

@@ -56,11 +56,11 @@ const GLState::Commands makeResetStateCommands() {
     return {
         std::make_shared<Command1I>(&GLBackend::do_setStateFillMode, DEFAULT.fillMode),
         std::make_shared<Command1I>(&GLBackend::do_setStateCullMode, DEFAULT.cullMode),
-        std::make_shared<Command1B>(&GLBackend::do_setStateFrontFaceClockwise, DEFAULT.frontFaceClockwise),
-        std::make_shared<Command1B>(&GLBackend::do_setStateDepthClampEnable, DEFAULT.depthClampEnable),
-        std::make_shared<Command1B>(&GLBackend::do_setStateScissorEnable, DEFAULT.scissorEnable),
-        std::make_shared<Command1B>(&GLBackend::do_setStateMultisampleEnable, DEFAULT.multisampleEnable),
-        std::make_shared<Command1B>(&GLBackend::do_setStateAntialiasedLineEnable, DEFAULT.antialisedLineEnable),
+        std::make_shared<Command1B>(&GLBackend::do_setStateFrontFaceClockwise, DEFAULT.flags.frontFaceClockwise),
+        std::make_shared<Command1B>(&GLBackend::do_setStateDepthClampEnable, DEFAULT.flags.depthClampEnable),
+        std::make_shared<Command1B>(&GLBackend::do_setStateScissorEnable, DEFAULT.flags.scissorEnable),
+        std::make_shared<Command1B>(&GLBackend::do_setStateMultisampleEnable, DEFAULT.flags.multisampleEnable),
+        std::make_shared<Command1B>(&GLBackend::do_setStateAntialiasedLineEnable, DEFAULT.flags.antialisedLineEnable),

         // Depth bias has 2 fields in State but really one call in GLBackend
         CommandPointer(depthBiasCommand),
@@ -75,7 +75,7 @@ const GLState::Commands makeResetStateCommands() {

         std::make_shared<Command1U>(&GLBackend::do_setStateSampleMask, DEFAULT.sampleMask),

-        std::make_shared<Command1B>(&GLBackend::do_setStateAlphaToCoverageEnable, DEFAULT.alphaToCoverageEnable),
+        std::make_shared<Command1B>(&GLBackend::do_setStateAlphaToCoverageEnable, DEFAULT.flags.alphaToCoverageEnable),

         std::make_shared<CommandBlend>(&GLBackend::do_setStateBlend, DEFAULT.blendFunction),


libraries/gpu/CMakeLists.txt

@@ -4,3 +4,4 @@ setup_hifi_library()
 link_hifi_libraries(shared ktx shaders)

 target_nsight()
+target_json()

libraries/gpu/src/gpu/Batch.cpp

@@ -45,7 +45,7 @@ size_t Batch::_dataMax{ BATCH_PREALLOCATE_MIN };
 size_t Batch::_objectsMax{ BATCH_PREALLOCATE_MIN };
 size_t Batch::_drawCallInfosMax{ BATCH_PREALLOCATE_MIN };

-Batch::Batch(const char* name) {
+Batch::Batch(const std::string& name) {
     _name = name;
     _commands.reserve(_commandsMax);
     _commandOffsets.reserve(_commandOffsetsMax);
@@ -64,7 +64,7 @@ Batch::~Batch() {
     _drawCallInfosMax = std::max(_drawCallInfos.size(), _drawCallInfosMax);
 }

-void Batch::setName(const char* name) {
+void Batch::setName(const std::string& name) {
     _name = name;
 }

@@ -96,7 +96,7 @@ void Batch::clear() {
     _textureTables.clear();
     _transforms.clear();

-    _name = nullptr;
+    _name.clear();
     _invalidModel = true;
     _currentModel = Transform();
     _drawcallUniform = 0;

libraries/gpu/src/gpu/Batch.h

@@ -89,14 +89,14 @@ public:
     void captureDrawCallInfo();
     void captureNamedDrawCallInfo(std::string name);

-    Batch(const char* name = nullptr);
+    Batch(const std::string& name = "");
     // Disallow copy construction and assignement of batches
     Batch(const Batch& batch) = delete;
     Batch& operator=(const Batch& batch) = delete;
     ~Batch();

-    void setName(const char* name);
-    const char* getName() const { return _name; }
+    void setName(const std::string& name);
+    const std::string& getName() const { return _name; }
     void clear();

     // Batches may need to override the context level stereo settings
@@ -440,6 +440,18 @@ public:
         };
     };

+    using CommandHandler = std::function<void(Command, const Param*)>;
+
+    void forEachCommand(const CommandHandler& handler) const {
+        size_t count = _commands.size();
+        for (size_t i = 0; i < count; ++i) {
+            const auto command = _commands[i];
+            const auto offset = _commandOffsets[i];
+            const Param* params = _params.data() + offset;
+            handler(command, params);
+        }
+    }
+
     typedef Cache<BufferPointer>::Vector BufferCaches;
     typedef Cache<TexturePointer>::Vector TextureCaches;
     typedef Cache<TextureTablePointer>::Vector TextureTableCaches;
@@ -519,7 +531,7 @@ public:
     bool _enableSkybox { false };

 protected:
-    const char* _name;
+    std::string _name;

     friend class Context;
     friend class Frame;

libraries/gpu/src/gpu/Buffer.h

@@ -149,7 +149,8 @@ protected:
     Size _end{ 0 };
     Sysmem _sysmem;

-
+    friend class Serializer;
+    friend class Deserializer;
     friend class BufferView;
     friend class Frame;
     friend class Batch;

libraries/gpu/src/gpu/Context.cpp

@@ -47,10 +47,7 @@ Context::Context(const Context& context) {
 }

 Context::~Context() {
-    for (auto batch : _batchPool) {
-        delete batch;
-    }
-    _batchPool.clear();
+    clearBatches();
     _syncedPrograms.clear();
 }

@@ -97,6 +94,12 @@ FramePointer Context::endFrame() {
     return result;
 }

+void Context::executeBatch(const char* name, std::function<void(Batch&)> lambda) const {
+    auto batch = acquireBatch(name);
+    lambda(*batch);
+    executeBatch(*batch);
+}
+
 void Context::executeBatch(Batch& batch) const {
     PROFILE_RANGE(render_gpu, __FUNCTION__);
     batch.flush();
@@ -117,28 +120,27 @@ void Context::executeFrame(const FramePointer& frame) const {
     PROFILE_RANGE(render_gpu, __FUNCTION__);

     // Grab the stats at the around the frame and delta to have a consistent sampling
-    ContextStats beginStats;
+    static ContextStats beginStats;
     getStats(beginStats);

     // FIXME? probably not necessary, but safe
     consumeFrameUpdates(frame);
     _backend->setStereoState(frame->stereoState);
-    {
-        Batch beginBatch("Context::executeFrame::begin");
-        _frameRangeTimer->begin(beginBatch);
-        _backend->render(beginBatch);

-        // Execute the frame rendering commands
-        for (auto& batch : frame->batches) {
-            _backend->render(*batch);
-        }
-
-        Batch endBatch("Context::executeFrame::end");
-        _frameRangeTimer->end(endBatch);
-        _backend->render(endBatch);
+    executeBatch("Context::executeFrame::begin", [&](Batch& batch){
+        batch.pushProfileRange("Frame");
+        _frameRangeTimer->begin(batch);
+    });
+    // Execute the frame rendering commands
+    for (auto& batch : frame->batches) {
+        _backend->render(*batch);
     }
+    executeBatch("Context::executeFrame::end", [&](Batch& batch){
+        batch.popProfileRange();
+        _frameRangeTimer->end(batch);
+    });

-    ContextStats endStats;
+    static ContextStats endStats;
     getStats(endStats);
     _frameStats.evalDelta(beginStats, endStats);
 }
@@ -381,6 +383,16 @@ void Context::processProgramsToSync() {
     }
 }

+std::mutex Context::_batchPoolMutex;
+std::list<Batch*> Context::_batchPool;
+
+void Context::clearBatches() {
+    for (auto batch : _batchPool) {
+        delete batch;
+    }
+    _batchPool.clear();
+}
+
 BatchPointer Context::acquireBatch(const char* name) {
     Batch* rawBatch = nullptr;
     {
@@ -393,8 +405,10 @@ BatchPointer Context::acquireBatch(const char* name) {
     if (!rawBatch) {
         rawBatch = new Batch();
     }
-    rawBatch->setName(name);
-    return BatchPointer(rawBatch, [this](Batch* batch) { releaseBatch(batch); });
+    if (name) {
+        rawBatch->setName(name);
+    }
+    return BatchPointer(rawBatch, [](Batch* batch) { releaseBatch(batch); });
 }

 void Context::releaseBatch(Batch* batch) {
@@ -406,7 +420,7 @@ void Context::releaseBatch(Batch* batch) {
 void gpu::doInBatch(const char* name,
                     const std::shared_ptr<gpu::Context>& context,
                     const std::function<void(Batch& batch)>& f) {
-    auto batch = context->acquireBatch(name);
+    auto batch = Context::acquireBatch(name);
     f(*batch);
     context->appendFrameBatch(batch);
 }
